Shimadzu SPD-M30A Quick Manual page 3

2
Setting Internet Explorer for PC (For Windows XP)
* Please refer to P.7 when you use Windows Vista or Windows 7.
■ Setting of the Amount of disk space to use (for IE7 or
IE8, Disk space to use)
1) Click on the Settings button of the Temporary Internet
files (for IE7 or IE8, Browsing history) in the General
tab to display the setting dialog.
2) Set the Amount of disk space to use (for IE7 or IE8,
Disk space to use) to "100" and click on the OK button.
■ Security setting (1)
1) Select [Local intranet] in the Security tab and click on
the Sites button.
2) Click on the Advanced button.
3) Add URLs of CBM-20A(lite) and SPD-M20A/
SPD-M30A.
4) Input "http://192.168.200.*" and press the Add button.
After input, click on the OK button to confirm the set
contents.
■ Security setting (2)
Click on the Custom Level button in the Security tab.
Set the following items from the setting list.
Items
Run ActiveX control and plug-ins
Script ActiveX controls marked
safe for scripting
Active scripting
Access data source across domains
File download
You may be warned with a message saying "Are you sure
you want to change the security setting for this zone?"
Select Yes in that case.
■ Bypassing proxy server
Click on the LAN settings button in the Connections
tab. When using a proxy server in your LAN, configure
the following settings. If no proxy server is used, this
setting is unnecessary.
1) Check the "Bypass proxy server for local addresses"
check box.
1) Click the Advanced button and add the system
controller' s URL(192.168.200.*) in "Exceptions".
* When the IP addresses of the CBM-20A(lite) and SPD-M20A/SPD-M30A are changed, change the Security setting(1) so that new IP
addresses are included in the intranet zone.
Setting description
"Enable"
"Enable"
"Enable"
"Enable" or "Prompt"
"Enable"
[Setting the disk capacity]
[Setting Security (1)]
[Security Setting (2)]
[Bypassing proxy server]
■ Advanced
1) Display the Advanced tab.
2) Browse to the checkbox "Display a notification about
every script error" and select this option.
3) Browse to the checkbox "Print background colors and
images" and select this option.
[Advanced]
3 / 8
