Shimadzu CBM-20A Quick Manual

Quick Guide for Connection of CBM-20A(lite) and SPD-M20A
This guide describes how to connect the CBM-20A(lite) and
the SPD-M20A to the network and make the settings to
enable control from PC.
Prepare LAN cable, a hub, and PC in order to make
communication setting for CBM-20A(lite) and SPD-M20A
that are at the state of shipment.
Make the settings with the following procedure.
■ PC settings
IP address setting
Subnet mask setting
■ Internet Explorer setting
Amount of disk space to use
Adding CBM-20A(lite) to local intranet zone
Adding SPD-M20A to local intranet zone
"Run ActiveX controls and plug-ins" setting
"Script ActiveX controls marked safe for scripting"
setting
"Active scripting" setting
"Access data sources across domains" setting
"File download" setting
Bypassing proxy server
"Display a notification about every script error" setting
"Print background colors and images " setting
■ CBM-20A(lite)/ SPD-M20A settings
IP address setting
Subnet mask setting
System name setting
Group name setting
Master Name setting
Communication Mode setting
Interface setting
Set time from PC clock
[With CBM-20Alite only] CBM LINK setting
Items
*Procedure
1) Setting IP address for PC
2) Changing browser setting for PC
3) Setting IP address and group name of the
CBM-20A(lite)
4) Setting IP address and master server of the
SPD-M20A.
5) Changing IP address of the PC when necessary
. .
. .
□done
□done
□done
□done
□done
□done
□done
□done
□done (Only when using a proxy server)
□done
□done
CBM-20A
. . .
. . .
□LCsolution □CLASS-VP
□
□Ethernet □RS-232C
□Opt-Link(PAC)
□done
□done
1
223-00950C
.
.
SPD-M20A
. . .
. . .
