DEMO MANUAL SCP-ADP7142-EVALZ
PARTS LIST
ITEM
QTY
REFERENCE
1
1
PCB
2
2
C1, C2
3
1
C3
4
1
C4
5
1
INPUT
6
1
OUTPUT
7
1
P1
8
1
R1
9
1
R2
10
1
R3
11
1
R4
12
2
R5, R6
13
1
U1
Note 1. These items are not stuffed (DNI).
4
PART DESCRIPTION
PCB
CAP 4.7UF 50V CER X7R 1206
CAP 1nF 100V CER X7R 0805
CAP 0.1uF 50V CER X7R 0805
CONN-PCB MALE 3POS 2.54MM PITCH R/A
CONN FEMALE 3POS 2.54MM PITCH R/A
CONN-PCB 3POS HEADER WIRE TO BRD WAFER ASSY STRAIGHT
2MM PITCH (Note 1)
RES 187k 1% THICK FILM 0805
RES 107k 1% THICK FILM 0805
RES 1.00k 1% THICK FILM 0805
RES 1.00M 1% THICK FILM 0805
RES THICK FILM 0805 (Note 1)
IC-ADI LOW NOISE, CMOS LDO LINEAR REGULATOR
MANUFACTURER/PART NUMBER
ANALOG DEVICES 08_051388b
SAMSUNG CL31B475KBHNNNE
AVX CORPORATION 08051C102KAT2A
AVX CORPORATION 08055C104JAT2A
SULLINS PBC03SBAN
SULLINS PPPC031LGBN-RC
MOLEX 53253-0370
PANASONIC ERJ-6ENF1873V
YAGEO RC0805FR-07107KL
VISHAY CRCW08051K00FKEAHP
YAGEO RC0805JR-071ML
N/A
ANALOG DEVICES ADP7142ACPZN-R7
Rev. 0
