SSV Works X32-PHZ4A Installation Instructions Manual page 5

SSV WORKS, 4610 Calle Quetzal, Camarillo, CA 93012
www.SSVworks.com | Phone: 818-991-1778 | Fax: 866-293-6751
WARRANTY INFORMATION:
All SSV Works enclosures are covered by a limited lifetime warranty against defects
in material or workmanship. All SSV Works Electronics are covered by a limited 1 year
warranty against defects in material or workmanship. Labor for replacement of defective
components is not covered. Contact SSV Works for further warranty information.
TOOLS NEEDED FOR INSTALLATION
- 10mm, 13mm, 16mm and
18mm Sockets & Wrenches
PARTS LIST IMAGES
1. X32-DUS10 Enclosure
5. Large washers x 2
9. Seat Spacer x 1
- T-30 & T-40 - 1½" Hole Saw
Torx Driver
2. M6 x 16mm Screws &
Washers x 10 (T-30 torx)
6. C-Bracket
10. Small Spacer x 1
Under Seat Subwoofer Enclosure
!
- Hole Punch / - Ratchet & Extension
Scribe Tool
Triangular
end
3. Thread Rolling Screw x 2
7. A-Bracket x 1
11. M6 Locking Hex Nut
PARTS LIST
10" Driver Side
Please read and understand these
instructions completely before
installation to avoid possible injury, or
damage to the accessory or vehicle.
- #3 Phillips
Screwdriver
4. M6 x 25mm Screw x 1
8. Large Bracket
12. Foam Strips x 5
5
