PART IDENTIFICATION CHART

Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following
the key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see
whether it has been preassembled. Extra parts may be included.
M8 x 13mm
Screw (82)–4
M10 x 25mm
Screw (92)–2
M8 x 22mm
Washer (13)–2
M8 x 20mm
Screw (94)–2
M8 x 28mm
Washer (97)–2
M8 x 20mm Flat
Head Screw (31)–2
M10 x 115mm Screw
(104)–4
6
M4 x 16mm
Screw (101)–16
M8 x 41mm Screw
(96)–4
