iFIT NordicTrack AIRGLIDE 14i User Manual
iFIT NordicTrack AIRGLIDE 14i User Manual

iFIT NordicTrack AIRGLIDE 14i User Manual

Advertisement

Quick Links

nordictrack.com
Model No. NTEL71423.5
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
REGISTER YOUR
PRODUCT
To register your product and
activate your warranty today,
go to my.nordictrack.com.
MEMBER CARE
For service at any time, go to
my.iFIT.com or scan the QR code.
Please do not contact the store.
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Keep this
manual for future reference.
USER'S MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the NordicTrack AIRGLIDE 14i and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for iFIT NordicTrack AIRGLIDE 14i

  • Page 1 To register your product and activate your warranty today, go to my.nordictrack.com. MEMBER CARE For service at any time, go to my.iFIT.com or scan the QR code. Please do not contact the store. CAUTION Read all precautions and instructions in this manual before using this equipment.
  • Page 2 This decal is on both sides NORDICTRACK and IFIT are registered trademarks of iFIT Inc. Google Maps is a trademark of Google LLC. The Bluetooth word mark and logos are registered trademarks of Bluetooth SIG, Inc. and are used under license.
  • Page 3 To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your elliptical before using your elliptical. iFIT assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
  • Page 4 18. The elliptical does not have a freewheel; the 20. Over exercising may result in serious injury pedals will continue to move until the fly- or death. If you feel faint, if you become short wheel stops. Reduce your pedaling speed in of breath, or if you experience pain while a controlled way.
  • Page 6 BEFORE YOU BEGIN Thank you for selecting the revolutionary reading this manual, please see the front cover of this NORDICTRACK AIRGLIDE 14I elliptical. The manual. To help us assist you, note the product model ® AIRGLIDE 14I elliptical provides an impressive selec- number and serial number before contacting us.
  • Page 7 PART IDENTIFICATION CHART Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly.
  • Page 8 ASSEMBLY • Assembly requires two persons. • Assembly can be completed using the included tools. Note: Your own rubber mallet • Place all parts in a cleared area and remove may also be helpful; however, be careful to the packing materials. Do not dispose of the not break plastic parts with the rubber mallet.
  • Page 9 3. Attach the Rear Stabilizer Cover (15) with three M4 x 18mm Machine Screws (155); start all three Machine Screws, and then tighten them. Then, remove the packing materials from under the rear of the Frame (1). Remove the packing materials 4.
  • Page 10 6. Using a plastic bag to keep your fingers clean, apply a thin coat of the included grease to the axle on the right Crank Arm (20). Next, identify the Right Roller Arm (59) and Left Side orient it so the welded tube (C) is on top and the Roller (51) is facing the elliptical.
  • Page 11 8. Connect the Upright Wire (157) to the Main Wire (110). IMPORTANT: The wire connectors should slide together easily and snap into place with an audible click. You must connect the wires properly for your elliptical to function properly. See the lower right drawing. Insert the wire connectors into the left side of the Upright (4).
  • Page 12 10. Identify the Right Pedal Arm (58) and orient it as shown. Next, apply a thin coat of grease to the axle on the Right Pedal Arm (58). Then, insert the axle on the Right Pedal Arm (58) into the Right Roller Arm (59). IMPORTANT: Do not hit the Side Cap (87) with a rubber mallet to insert the axle;...
  • Page 13 12. To prevent the Upright (4) from rocking during use, FIRMLY tighten the four M10 x 25mm Screws (92). These are the Screws that you started in step 7. FIRMLY tighten the Screws (92) 13. Have a second person hold the Console (7) near the Console Bracket (128).
  • Page 14 15. Orient the Lower Console Cover (152) as shown, and snap it onto the back of the Console (7). Note: It may be helpful to pivot the Console out of the way. See the lower right drawing. Orient the Upper Console Cover (153) as shown, and snap it onto the back of the Console (7).
  • Page 15 17. Identify the Right Upper Body Arm (61) and have a second person hold it near the Right Upper Use the OPEN Body Leg (60). END of the included See the left inset drawing. Locate the wire tie wrench to (J) and the wire pull (K) attached to the Right FIRMLY tighten Control Wire (134).
  • Page 16 19. Do not pinch the wire. Identify a Lower Tray Cover (81) and hold it under the right side of the Accessory Tray (37). See the lower right drawing. Make sure that the Right Control Wire (134) is in the cutouts (F) in the Lower Tray Cover (81).
  • Page 17 21. Identify the Right Leg Inner Cover (83). Insert the post (H) on the Right Leg Inner Cover into the Right Upper Body Leg (60). Next, identify the Right Leg Outer Cover (69), press it onto the Right Leg Inner Cover (83), and attach it with an M4 x 16mm Screw (101).
  • Page 18 HOW TO USE THE ELLIPTICAL A temporary HOW TO PLUG IN THE POWER CORD adapter (C) may This product must be grounded. If it should mal- be used to con- function or break down, grounding provides a path of nect the power least resistance for electric current to reduce the risk cord to a 2-pole of electric shock.
  • Page 19 HOW TO MOVE THE ELLIPTICAL HOW TO LEVEL THE ELLIPTICAL If the elliptical rocks slightly on your floor during use, Due to the size and weight of the elliptical, mov- turn one or both of the leveling feet (J) beneath the rear ing it requires two persons.
  • Page 20 HOW TO EXERCISE ON THE ELLIPTICAL To mount the elliptical, hold the handlebars (M) or the upper body arms (N) and step onto the pedal (O) that is in the lower position. Then, step onto the other pedal. Push the pedals until they begin to move with a continuous motion.
  • Page 21 Each workout automatically con- trols the resistance of the pedals and the incline of While you exercise, the console will display continuous the frame as an iFIT trainer guides you through an exercise feedback. You can even monitor your heart effective exercise session.
  • Page 22 HOW TO TURN ON THE CONSOLE HOW TO TURN OFF THE CONSOLE When you are finished exercising, press the power IMPORTANT: If the elliptical has been exposed to switch to the off position and unplug the power cord. cold temperatures, allow it to warm to room tem- perature before you turn on the console.
  • Page 23 Take time to explore the console to learn 1. Connect to your wireless network. how new settings and features work. To use iFIT workouts and to use several other features of the console, the console must be con- 5. Calibrate the incline system.
  • Page 24 Note: After you press a button, it will take a HOW TO USE THE MANUAL MODE moment for the pedals to reach the selected resis- tance level or for the ramp to reach the selected 1. Touch the screen or press any button on the incline level.
  • Page 25 (heart symbol). You must can manually override the setting by pressing the be logged into your iFIT account to save a featured Resistance buttons or the Ramp buttons (see step workout (see step 3 on page 28).
  • Page 26 If the smart adjust feature is enabled, the console If the active pulse feature is enabled, the console will scale the intensity level of the workout auto- will scale the intensity level of the workout auto- matically based on your manual overrides of the matically based on your heart rate when you wear resistance settings.
  • Page 27 To use a draw-your-own-map workout, you must be The screen will display the elevation and distance logged into your iFIT account (see step 3 on page statistics for the workout. 28) and the console must be connected to a wireless network (see HOW TO CONNECT TO A WIRELESS 4.
  • Page 28 (three horizontal lines symbol) on the screen a future date. Simply view the overview or work- and then touch Log in to log in to your iFIT account. out summary of the desired iFIT workout, touch Follow the prompts on the screen to enter your Schedule, and then select the desired date on the username and password.
  • Page 29 If a settings menu is selected, touch the back but- ton (arrow symbol) to return to the home screen. For more information about iFIT, go to iFIT.com. Then, touch the menu button (three horizontal lines symbol) on the screen, and then touch Settings.
  • Page 30 wireless network. The update will begin auto- 3. Customize workout settings. matically. IMPORTANT: To avoid damaging the To customize workout settings and enable work- elliptical, do not turn off the console while the out features, touch In Workout and then touch the firmware is being updated.
  • Page 31 HOW TO CONNECT TO A WIRELESS NETWORK and an 802.11b/g/n router with SSID broadcast To use iFIT workouts and to use several other features enabled (hidden networks are not supported). of the console, the console must be connected to a wireless network.
  • Page 32 HOW TO USE THE FAN HOW TO USE AN OPTIONAL HEART RATE MONITOR The fan has several speed settings, including an auto Whether your mode. While the auto mode goal is to is selected, the speed of the burn fat or to fan will automatically increase strengthen your or decrease as your pedaling speed increases or...
  • Page 33 FCC INFORMATION This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 34 IMPORTANT: To avoid damage a wireless network or if you are having problems with your iFIT account or iFIT workouts, go to my.iFIT.com. to the console, keep liquids away from the console and keep the console out of direct sunlight.
  • Page 35 HOW TO ADJUST THE DRIVE BELT HOW TO ADJUST THE REED SWITCH If the pedals slip while you are pedaling, even while If the console does not display correct feedback, the resistance is adjusted to the highest level, the drive the reed switch should be adjusted.
  • Page 36 EXERCISE GUIDELINES Aerobic Exercise—If your goal is to strengthen your WARNING: cardiovascular system, you must perform aerobic Before beginning this exercise, which is activity that requires large amounts or any exercise program, consult your physi- of oxygen for prolonged periods of time. For aerobic cian.
  • Page 37 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch; never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
  • Page 38 NOTES...
  • Page 39 PART LIST Model No. NTEL71423.5 R0424A Key No. Qty. Description Key No. Qty. Description Frame Roller Rear Stabilizer Left Pedal Handle Access Cover Roller Arm Cover Upright Pivot Spacer M4 x 19mm Screw Retainer Front Stabilizer Roller Arm Bushing Console Pedal Arm Bearing Assembly Roller Guide Right Pedal Arm...
  • Page 40 Key No. Qty. Description Key No. Qty. Description M4 x 16mm Screw Right Hand Grip/Control Wire M8 Locknut M6 x 26mm Washer M8 x 23mm Washer Lower Rear Shield M10 x 115mm Screw Right Pedal Handle M8 x 16mm Hex Screw Pedal Pin Lower Motor Cover Pedal Spring...
  • Page 41 EXPLODED DRAWING A Model No. NTEL71423.5 R0424A...
  • Page 42 EXPLODED DRAWING B Model No. NTEL71423.5 R0424A...
  • Page 43 EXPLODED DRAWING C Model No. NTEL71423.5 R0424A...
  • Page 44 USA, (3) if any instruction or warning in this manual is not followed, (4) iftheproductisabusedorimproperlyorabnormallyused,(5)iftheproductismodifiedtoalterfunctional- ity or capability without the written permission of iFIT, or (6) if the product is used for commercial or rental purposes.NootherwarrantybeyondthatspecificallysetforthaboveisauthorizedbyiFIT.
