  • Page 1 Water Cooler Truck Mount SKU: MOUNT-WCT1 Instruction Manual Assembly Video & Product Info www.vivo-us.com/products/mount-wct1...
  • Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
  • Page 3 Package Contents A (x1) B (x2) C (x1) D (x1) Main Bracket Strap Upper Bracket Lower Bracket Included Hardware S-A (x10) S-B (x3) S-C (x3) S-D (x3) S-E (x3) M6x10mm Flathead M10 Washer M10 Nut M10x30mm Screw ST10x30mm Screw Screw Tools Needed: Weight Capacity: 44lbs...

  • Page 4: Assembly Steps

    ASSEMBLY STEPS STEP 1 Connect the Lower Bracket (D) to the Main Bracket (A) using the M6x10mm Flathead Screws (S-A). Tighten screws using a 4mm Allen Wrench.
  • Page 5 STEP 2 Connect the Upper Bracket (C) to the Main Bracket (A) using the M6x10mm Flathead Screws (S-A). Tighten screws using a 4mm Allen Wrench.
  • Page 6 STEP 3 Metal Rail/Plate Installation: Hold the bracket assembly up to your desired mounting location and mark hole using a marker. Drill through holes using a 7/16” (11mm) drill bit. Attach the assembly using M10x30mm Screws (S-D), M10 Washers (S-B), and M10 Nuts (S-C). Tighten using a 17mm wrench.
  • Page 7 STEP 4 Thread the Straps (B) through the Main Bracket (A) and secure up to 5 gallon water jugs.
  • Page 8 LAST UPDATED: 01/08/24 REV1 v1.0 Need Help? Get In Touch Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303 Chat live with an agent! FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us...
