LETTO OSPEDALIERO MANUALE
MANUAL HOSPITAL BED
LIT MÉDICALISÉ MANUEL
CAMA DE HOSPITAL MANUAL
MANUALE D'USO – USER MANUAL – MODE D'EMPLOI – MANUAL DE USO
• È necessario segnalare qualsiasi incidente grave verificatosi in relazione al dispositivo medico da noi fornito al fabbricante e
all'autorità competente dello Stato membro in cui si ha sede.
• All serious accidents concerning the medical device supplied by us must be reported to the manufacturer and competent
authority of the member state where your registered office is located.
• Il est nécessaire de signaler tout accident grave survenu et lié au dispositif médical que nous avons livré au fabricant et à
l'autorité compétente de l'état membre où on a le siège social.
• Es necesario informar al fabricante y a la autoridad competente del Estado miembro en el que se encuentra la sede sobre
cualquier incidente grave que haya ocurrido en relación con el producto sanitario que le hemos suministrado.
Gima 44740
Jiangsu Saikang Medical Equipment Co.,Ltd
No. 35 Lehong Road, Modern Agriculture Demonstration Park,
Zhangjiagang City, Jiangsu Province, China
Made in China
V2K5C
Sungo Europe B.V.
Fascinatio Boulevard 522,
Unit 1.7, 2909VA
Capelle aan den IJssel,
The Netherlands
Gima S.p.A.
Via Marconi, 1 - 20060 Gessate (MI) Italy
gima@gimaitaly.com - export@gimaitaly.com
www.gimaitaly.com
85%
106kPa
+40˚C
%
-10˚C
70kPa
0%
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Gima V2K5C
Summary of Contents for Gima V2K5C
- Page 1 Zhangjiagang City, Jiangsu Province, China Made in China 106kPa +40˚C V2K5C Gima S.p.A. -10˚C 70kPa Sungo Europe B.V. Via Marconi, 1 - 20060 Gessate (MI) Italy Fascinatio Boulevard 522, gima@gimaitaly.com - export@gimaitaly.com Unit 1.7, 2909VA www.gimaitaly.com Capelle aan den IJssel, The Netherlands...
-
Page 2: Manual Introduction
Please carefully read this manual and strictly follow the steps before installing and using. We require all users to have the knowledge of user’s manual and all the cautions. • This manual is applicable to V2K5C manual hospital bed. It contains the installation method, operating instructions and maintenance check points. •... - Page 3 ENGLISH Φ16-19mm/off white hook IV pole Bed leg 587*245 Bed platform 2115*890 Packing for Refer to Table a.2 bed frame Screw Refer to Table a.3 Table a.2: Name Picture Specification QTY' Unit Head board 990*460 Foot board 990*460 V21 first 733*903/PP/white platform V21 Second...
- Page 4 ENGLISH Table a.3: Name Picture Specification Unit Ø 10-M8 Hexagon screw Hexagon screw M8*20 Φ 8 Flat washer Φ 8 Spring washer 30-50 drainage 30-50 (plastic) hook Hexagon screw M8×20 Hexagon socket M8×50 flat head screws Φ 16 Flat washer Plastic flat washer Φ...
- Page 5 ENGLISH Φ 15.3x184 Pipe 184 Plastic flat washer Φ 12 (white) Hexagon screw M8×60 Hexagon screw M10×25 Φ 10 Flat washer Φ 10 Spring washer CASTERS INSTALLATION Lay a protective pad and put the bed body upside down; Remove the screw as shown below, and use a 17- inch hex wrench.
- Page 6 ENGLISH BED FRAME INSTALLATION Place the bed upright and install the bed plate.
- Page 7 ENGLISH SIDE GUARDRAILS INSTALLATION Place the bed upright and install the guardrail; (The picture may not exactly match the real product, this is only for installation instructions) Remove the screw as shown below, and use a 14-inch hex wrench.
- Page 8 ENGLISH HEADBOARD & FOOTBOARD ASSEMBLY METHOD (The picture does not exactly match the real product, only for the installation instructions) The vertical rod used for the head of the bed is Φ 15.3x154, and the vertical rod used for the end of the bed is Φ 15.3x184.
- Page 9 ENGLISH 1-IV pole 2-Head board 3-Guardrail 4-Bed surface board 5-Foot board 6-Leg frame 7-Drainage hook 8-Shows holder 9-Caster Length 1925±10 Width 900±10 Bed surface size The height of the bed above 500±10 the ground Length 2130±10 Dimensions Width 995±10 Height 500±10 Back board 0-70±5°...
- Page 10 ENGLISH USE METHOD OF GUARDRAILS Raising and lowering the guardrail Raise the guardrail: Hold the red gun of the guardrail and lift it up. When you hear the sound of “click”, it means the guardrail is locked. Lower the guardrail: Hold the guardrail red gun and slowly lay down. USE METHOD OF DRAINAGE HOOKS The drainage hooks as shown in the figure.
- Page 11 ENGLISH USE METHOD OF IV POLE Adjusting the height of the IV pole: 1. Loosen the outer sleeve counter clock carefully, insert the inner tube of the IV pole into the outer sleeve, and then adjust the length of the extension rod up and down;...
-
Page 12: Bed-Maintenance
ENGLISH Use 2pcs 17-inch Allen wrenches to unscrew the telescopic rocker knot, take out the bolt, and replace the rocker. When the replacement is completed, install the bolts in the order shown in the figure, and use the wrench to tighten the knot. FAULTS EXCLUSION Common failures Probable reasons... -
Page 13: Bed-Cleaning
ENGLISH breeding. If water adheres, wipe it off immediately. 5. When the bed frame ages and it reaches a certain servicing time, which the metal part of the bed and the plastic parts of the headboard or footboard, guardrail can be recycle. BED-CLEANING 1. -
Page 14: Spare Part List
ENGLISH please contact our after-sales service department or authorized dealer provide by our company. Every time the brakes are replaced, the brake performance of the casters must be retested. GUARDRAIL-MAINTENANCE 1. Please check whether the side rails are installed correctly to prevent the lying patient from shifting and rolling down. 2. -
Page 15: Packaging, Transport, Storage
ENGLISH Name card GPSL101TS184 First platform GPSL101TS610 733*903 Second platform GPSL101TS611 333*903 Third platform GPSL101TS613 373*903 Fourth platform GPSL101TS614 473*903 Drainage hook BYKBGKM02806 30-50 Note: Due to product updates, parts of the original product may not be available for life. (The company ensures that the sold products can provide the parts that need to be replaced within 6 years after the end of their production) PACKAGING, TRANSPORT, STORAGE 1. -
Page 16: After Sales Service
Data di fabbricazione Lot number Medical Device Caution: read instructions Atmospheric pressure limit Humidity limit (warnings) carefully Rappresentante autorizzato Temperature limit Imported by nella Comunità europea Serial number Unique identifier GIMA WARRANTY TERMS The Gima 12-month standard B2B warranty applies.
