ETC Sensor IQ Installation Manual

ETC Installation Guide
Sensor IQ Main Breaker Kits
Overview
The Sensor IQ panel ships standard with main lugs. If your installation requires
a main breaker, several types of Main Breaker Kits are available from ETC.
These instructions cover main breaker kits for 120 V or 277 V Sensor IQ
panels. Models vary depending on panel mounting orientation (top or bottom
wire feed location), feed type, current rating, and short circuit current rating.
Refer to the Sensor IQ Installation Manual
details. ETC manuals are available for free download at the
(etcconnect.com).
WARNING:
AVERTISSEMENT :
Corporate Headquarters
Global Offices
New York, NY | Orlando, FL | Los Angeles, CA | Austin, TX | © 2025 Electronic Theatre Controls, Inc.
Web
Trademark and patent info:
Product information and specifications subject to change. ETC intends this document to be provided in its entirety.
7131M2180 Rev H Released 2025-03
RISK OF DEATH BY ELECTRIC SHOCK! Failure to disconnect all power to the
panel before working inside the panel could result in serious injury or
death.
RISQUE DE MORT PAR ÉLECTROCUTION! Travailler à l'intérieur du panneau
sans avoir déconnecté le courant peut entrainer des blessures graves, voire
mortelles.
De-energize main feed to relay panel and follow appropriate Lockout/
Tagout procedures as described in NFPA Standard 70E. It is important to
note that electrical equipment such as relay panels can present an arc flash
safety hazard if improperly serviced. This is due to available large short
circuit currents on the feeders of the equipment. Any work on energized
equipment must comply with OSHA Electrical Safe Working Practices.
Middleton, WI, USA | +1 608 831 4116

London, UK | Rome, IT | Holzkirchen, DE | Paris, FR | Hong Kong | Dubai, UAE | Singapore

etcconnect.com | Support support.etcconnect.com
etcconnect.com/ip
or your ETC project manager for
ETC website
| Contact etcconnect.com/contactETC
| Third-party license agreement info:
Main Breaker Kit (including
