PC Configuration
PC Configuration
For correct operation of the emulator, your computer must have the minimal configuration:
• Windows 7, 10, 11
• CrossCore Embedded Studio 2.12.0 (or higher)
Emulator Installation
Perform the following tasks to install your emulator safely. Follow the instructions in presented order to ensure cor-
rect operation of your software and hardware.
•
Installing the Emulator Software
•
ICE-1500: Configuring Operating Voltage of the JTAG/SWD Interface
•
Verifying Driver Installation and Attaching to an Emulation Target
•
Applying Power to the Emulator
Installing the Emulator Software
1. Install CCES 2.12.0 (or higher) on your computer. The software installation includes the USB driver needed
for the emulator hardware.
ADDITIONAL INFORMATION: If you connect to the ICE before installing the software, the Windows driver
wizard may not find the emulator driver.
ICE-1500: Configuring Operating Voltage of the JTAG/SWD Interface
1. Determine the operating voltage of the JTAG/SWD interface for the target processor.
ADDITIONAL INFORMATION: The ICE-1500 emulator ships configured to connect to a 3.3V target. The
jumpers are installed on positions 1 and 2 of P6 by default. Refer to the Operating Voltage table and P6 Pin-
out figure for other voltage configurations.
Table 2-1: Operating Voltage
Target Voltage
3.3 V
1.8 V
Verifying Driver Installation and Attaching to an Emulation Target
Before using the emulator, verify that the driver software is installed properly.
1. Open the Windows Device Manager and verify that the ICE-1500 emulator appears under CrossCore Tools, as
shown in the Verifying Driver Installation figure.
2–2
P6 Settings (Installed Jumpers)
1 and 2(default)
2 and 3
ICE-1500 Emulator
