ROBOT BASE SET-UP
1 ft.
1 ft.
2 ft.
• Place the base with its back against a wall. Select a level surface on a BARE FLOOR in a central area with a
strong Wi-Fi signal. Do not place it against baseboard heaters or other heating elements. Ensure the base
is not placed in area with direct sunlight.
• Select a permanent location for the Robot Base because every time you relocate it, your robot will have
to re-map your space. Remove any packaging from both the robot and the base.
• Remove any objects that are closer than 1 foot from either side of the base or closer than 2 feet from the
front of the base. Ensure any carpeted floor is 4 feet away from the front of the base, or more.
• Plug in the base. The indicator light will illuminate green when the base has power.
INSTALLING THE SIDE BRUSH
INSTALLING THE ODOR NEUTRALIZER TECHNOLOGY
1. Open the packaged Odor Cartridge assembly.
2. Flip up the handle on the odor dial.
3. Align the arrows.
4. Insert the assembly into the slot on the top right side of the base.
5. To lock and engage the Odor Cartridge assembly, rotate it
counterclockwise until it clicks at least once.
6. Continue to rotate the dial toward the high position to increase the intensity.
The Odor Neutralizer Technology is not included with all models.
NOTE:
s h a r kc l e a n . c o m
Attach the side brush to the post on the
bottom of the robot.
Side brush design may vary.
NOTE:
ROBOT INDICATOR LIGHTS
When cleaning, the remaining battery level is
indicated by the number of LED lights illuminated.
At full battery power, 5 indicator lights will be
illuminated. At 80% battery, 4 indicator lights will
be illuminated, and so on.
DirtDetect detects hidden debris and automatically boosts power until no more dirt is detected. When the
robot detects a mess, the lights on the robot will turn PURPLE to indicate that DirtDetect is enabled. The
robot will deep-clean in a 3' x 3' pattern.
When your robot activates ActiveLift to better navigate your home, your indicator lights will flash ORANGE to
indicate that it has activated.
Low Battery
LEFT NOTIFICATION BATTERY WI-FI RIGHT
LEFT LED pulsing RED
Charging
LEFT NOTIFICATION BATTERY WI-FI RIGHT
BATTERY LED pulsing RED for low, YELLOW for medium,
GREEN for high
If your robot is low on battery power, the left LED
light will pulse RED. Manually place the robot on the
base to begin charging. When the robot is charging,
the battery indicator light will pulse, based on the
current battery charge level: RED for low, YELLOW
for medium, GREEN for high.
DIRTDETECT
ACTIVELIFT
