UNDERSTANDING THE ROBOT USER INTERFACE
If any lights are illuminated or flashing on your robot, refer to the chart below to understand why:
LED COMBINATION
ALL LEDS (WHITE) - FLASHING
ALL LEDS (WHITE) - SOLID
ALL LEDS (GREEN) - SOLID
4 LEDS (GREEN) – SOLID
RIGHT LED (OFF)
LEFT LED (YELLOW) + NOTIFICATION
LED (YELLOW) + BATTERY LED
(YELLOW)
LEFT LED (YELLOW) + NOTIFICATION
LED (YELLOW)
LEFT LED (RED) - SOLID
ALL LEDS (GREEN) - BREATHE
LEDS COMPLETE CELEBRATION
SEQUENCE
WIFI LED (BLUE) – BREATHE
LEDS COMPLETE CELEBRATION
SEQUENCE
ALL LEDS (GREEN) - BREATHE
BATTERY LED (RED) - SOLID
ALL LEDS (WHITE) – FLASH x2
ALL LEDS (PURPLE) – FLASH
BATTERY LED:
• GREEN BREATHE: 66-100%
• YELLOW BREATHE: 33-65%
• RED BREATHE: 5-32%
ALL LEDS (TURQUOISE) - FLASH
ALL LEDS (TURQUOISE) - BREATHE
ALL LEDS (TURQUOISE) – FILL FROM
ONE SIDE TO OTHER
LEFT NOTIFICATION BATTERY WI-FI RIGHT
s h a r kc l e a n . c o m
FUNCTIONALITY
Robot is booting up.
Robot finishes booting up and enters standby
mode. Robot is waiting for commands.
Battery level 80%-100%.
Battery level 60%-79%.
Battery level 40%-59%.
Battery level 20%-39%.
Battery level 0%-19%.
Robot is making its way back to the base.
Robot returns to base successfully.
Robot is connecting to WIFI.
WIFI connection is successful.
Robot is evacuating dry debris into
the base dust bin.
Robot has low battery.
Robot has been paused.
Robot has enabled DirtDetect mode.
Robot is on the base and charging.
Robot is activating pad shift during a wet
cleaning mission along a wall.
Robot is saturating the pad at the start of a
wet cleaning mission.
The base is refilling the robot's water tank
before a wet cleaning mission.
COMMON ERROR CODES
If any error lights are illuminated or flashing on your robot, refer to the error code chart below:
ERROR
ERROR CODE
NUMBER
BATTERY LED (RED)
+ WIFI LED (RED)
NOTIFICATION LED (RED)
+ WIFI LED (RED) + RIGHT LED
(YELLOW) - ALL FLASHING
NOTIFICATION LED (RED)
+ RIGHT LED (YELLOW)
BATTERY LED (RED) + WIFI
LED (RED) + RIGHT LED
(YELLOW)
WIFI LED (RED)
+ RIGHT LED (YELLOW)
NOTIFICATION LED (RED)
+ WIFI LED (RED)
BATTERY LED (RED)
+ RIGHT LED (YELLOW)
WIFI LED (RED)
NOTIFICATION LED (RED)
NOTIFICATION LED (RED)
+ BATTERY LED (RED)
+ WIFI LED (RED)
LEFT LED (RED) FLASHING
NOTIFICATION LED (RED)
+ BATTERY LED (RED)
+ WIFI LED (RED) + RIGHT LED
(YELLOW)
RIGHT LED (RED) FLASHING
LEFT LED (PINK)
+ RIGHT LED (PINK)
- ALL FLASHING
For all other issues, please visit support.sharkclean.com or call Customer Service at +1-888-668-9600.
LEFT NOTIFICATION BATTERY WI-FI RIGHT
SOLUTION
Side brush is stuck. Remove any debris from
2
around the side brush so it moves freely.
Suction motor failure. Remove and empty the
3
dust bin, clean the filters, remove the brushroll
and brushroll door, and remove blockages.
Blockage in brushroll. Remove any debris from
4
around and inside the brushroll so that it can
spin freely.
A drive wheel is stuck. Clean the wheels and
5
remove any debris wrapped around the axles so
they can move freely.
Front bumper may be jammed. Clean the bumper
6
and make sure it moves in and out freely.
Cliff sensor error. Move your robot to a new
7
location and clean its cliff sensors.
Robot dust bin needs to be reinstalled. Insert
9
the dust bin until it clicks in place.
Robot may be stuck on an obstacle. Move robot
10
to a new location on a level surface.
Robot is stuck. Move your robot to a new
16
location and make sure the front bumper moves
in and out freely.
Robot cannot find the base. Please make sure the
23
base is powered ON and is free of all obstacles.
Battery is critically low and needs recharging.
Please pick up your robot and place it on the
24
base. Make sure the base indicator light turns
blue to confirm your robot is placed on the base
and charging.
Blockage in dust bin. Check the evacuation
port on the base and robot dust bin for clogs.
26
Clear any debris and reinstall the base dust bin,
ensuring that it clicks into place.
There may be a blockage with Active Lift. Turn
off the robot and ensure that there is nothing
33
blocking the wheel suspension from moving up
and down
There may be a blockage in the base. Unplug the
36
base and ensure that there is nothing blocking
the space where the robot sits in the base.
