- Page 1 ™ Robot Vacuum 2300S/2300AE OWNER’S GUIDE R O B O T S E L F - E M P T Y R O B O T...
-
Page 2: Important Safety Instructions
For non-app users, use a boundary to screws, or coins). 35. For Shark Matrix Self-Empty XL dock be cleaned. block off an unsafe boundary. d) Large quantities of dust (drywall dust,... - Page 3 GETTING TO KNOW YOUR SHARK MATRIX™ GETTING TO KNOW YOUR SHARK MATRIX™ Indicator Lights SELF-EMPTY BASE Front Bumper FRONT DOCK Button CLEAN Button Base Dust Bin LIDAR Module Indicator Light Post-Motor Filter Access Door Debris Intake Charging Contacts Cliff Sensors...
- Page 4 LIVING WITH YOUR ROBOT PREP YOUR HOME Your robot uses an array of sensors to navigate around walls, furniture legs, and other obstacles while it Questions? For how-to videos, FAQs, troubleshooting, and tips & tricks, call 1-888-228-5531 for robot support or visit: cleans.
-
Page 5: Installing The Side Brush
SELF-EMPTY BASE SETUP ROBOT INDICATOR LIGHTS Charging LEFT, MIDDLE, and RIGHT LEDs flashing white in succession Low Battery LEFT and RIGHT LEDs flashing red If your robot is low on battery, the left and right indicator lights will flash red. Manually place the robot on the base to begin charging. -
Page 6: Clean Button
CHARGING DOCK AND CLEAN BUTTONS IMPORTANT: Be sure to charge the robot completely before its first cleaning so that it can explore, map, and CLEAN BUTTON clean as much of your home as possible. It may take up to 6 hours to fully charge your robot. If the robot is on the base, press the CLEAN button for a whole-home clean. - Page 7 USING THE SHARKCLEAN® APP AND VOICE CONTROLS website. Search for "Shark Skill". Select the Shark Skill to open the detail page, then select the Enable Skill option. Once enabled, you can ask Alexa to control your robot (i.e., "Alexa, tell Shark to start cleaning").
-
Page 8: Troubleshooting
It is normal for your robot to temporarily lose connectivity when it goes under furniture, or moves far from your router. Your Shark robot will automatically reconnect to Wi-Fi. If the robot does not reconnect on its own, remove the unit from the Self-Empty Base. Power the robot off, wait 10 seconds, and place it back on the base. -
Page 9: Maintenance
MAINTENANCE MAINTENANCE MAINTAINING THE BASE DUST BIN CAUTION: Turn off power before performing any maintenance. To turn the robot power off, press the DOCK button on the robot for 5-7 seconds. EMPTYING THE ROBOT DUST BIN Depending on the size of the base, empty the base To empty the bin, hold it over the trash, then press dust bin every 30 to 60 days or as needed. - Page 10 MAINTENANCE MAINTENANCE CLEANING SENSORS AND CHARGING CONTACTS CLEANING THE ROBOT'S FILTER CLEAN SENSORS AND CHARGING CONTACTS AS NEEDED. With a dry cloth, gently dust off the sensors For optimal suction power, after each use, clean the filter inside the robot's dust bin. and contacts located on the bottom of the robot and on the Self-Empty Base.
-
Page 11: Brush Roll
MAINTENANCE MAINTENANCE BRUSHROLL TROUBLESHOOTING If any error lights are illuminated or flashing on your Shark Matrix™, see the error code chart below: ERROR ERROR CODE SOLUTION NUMBER Side brush is stuck. Remove any debris from around the side brush so it moves freely. -
Page 12: Replacement Parts
MAINTENANCE REPLACEMENT PARTS CLEANING THE WHEELS NOTE: To order replacement parts visit sharkaccessories.com. CLEAN FRONT WHEEL HOUSING PERIODICALLY. See sharkaccessories.com for replacement parts. REPLACEMENT PARTS: ROBOT Robot Dust Bin Brushroll* Battery Brushroll Door* Side Brush* Self-Empty Base Rotate the front wheel while lightly brushing away Periodically clean the drive wheels and the housing dirt and debris. - Page 13 EULA and can be viewed at the following URL: http://www.sharkninja.com/privacypolicy. Download and install youtube.com/shark 5. THIRD-PARTY APPLICATION LIBRARIES AND EMBEDDED SOFTWARE. the SharkClean® app 5.1 You acknowledge that Ayla Networks, Inc. (“Ayla”) has provided certain application libraries that have been embedded into SN APPS (“Ayla Application Libraries”) and enables SN Devices to connect to the Ayla...
-
Page 14: One (1) Year Limited Warranty
END-USER LICENSE AGREEMENT FOR SHARKNINJA SOFTWARE 5.6 You will not use the Ayla Application Libraries or Ayla Embedded Software to attempt to gain unauthorized access to or use of the systems/services of SharkNinja’s other licensors; nor will You transmit ONE (1) YEAR LIMITED WARRANTY viruses, worms, Trojan horses, time bombs, spyware, malware, cancelbots, passive collection mechanisms, robots, data mining software, or any other malicious or invasive code or program into the systems/services of SharkNinja’s other licensors. -
Page 15: Register Your Purchase
Expected runtime: 60 minutes Expected charging time: 6 hours PLEASE READ CAREFULLY AND KEEP FOR FUTURE REFERENCE. This Owner's Guide is designed to help you keep your Shark Matrix™ running at peak performance. SharkNinja Operating LLC US: Needham, MA 02494... - Page 16 NOTES NOTES s h a r kc l e a n . c o m s h a r kc l e a n . c o m...
-
Page 17: Fcc Warnings
© 2023 SharkNinja Operating LLC. SHARK and SHARKCLEAN are registered trademarks of SharkNinja Operating LLC. AI LASER NAVIGATION and SHARK MATRIX are trademarks of SharkNinja Operating LLC. RBRC is a trademark of Rechargeable Battery Recycling Corporation. APPLE, the Apple logo, and iPhone are trademarks of Apple Inc., registered in the U.S.
Need help?
Do you have a question about the Matrix 2300S and is the answer not in the manual?
Questions and answers
how to start my dish matrix robot
To start the Shark Matrix 2300S robot:
1. Remove all plastic wrap and foam from the robot and base.
2. Place the self-empty base on a flat surface with a strong Wi-Fi signal.
3. Attach the side brush to the robot.
4. Place the robot on the self-empty base—when correctly placed, it will turn on, and the dock LED will turn blue while charging.
5. Download the SharkClean app by scanning the QR code and complete the robot setup through the app.
You can also start the robot using voice commands with Amazon Alexa or Google Assistant after enabling the Shark Skill. For example:
- "Alexa, ask Shark to start vacuuming."
- "Hey Google, start vacuuming."
This answer is automatically generated
What do the Green lights mean on the Matrix robot?
The green light on the Shark Matrix 2300S robot's dock indicates that the base is powered on.
This answer is automatically generated
How long does it take to charge
It takes up to 6 hours to fully charge the Shark Matrix 2300S.
This answer is automatically generated
What does error number nine mean?
Does this modelRV2300S have the self cleaning brush role?
