Shark POWERDETECT NEVERTOUCH RV2800WD Series Owner's Manual page 3

WHAT'S INCLUDED
1. Odor Cartridge Assembly (1X)
Note: Not included
on all models
3. Robot (1X)
5. Ramp (1X)
OR
5. NeverTouch™ Base (1X)
OR
s h a r kc l e a n . c o m
2. Side Brush (2X)
Note: Side brush design may vary.
Some models include a spare.
4. Mopping Pads (quantity varies)
6. Shark® Multi-Surface Cleaner
12 oz. (355 mL) Bottle (1X)
SET-UP YOUR SHARK® ROBOT & NEVERTOUCH
Insert Odor Cartridge Assembly
1
Note: Not included on all models
INSERT CARTRIDGE
ROTATE UNTIL CLICK
ASSEMBLY INTO BASE
Note: Make sure the odor cartridge assembly
is installed in the base before using the robot.
Set Up Base
2
1. Remove all plastic wrap
and foam.
2. Place the base on a flat,
level hard-floor surface
1 ft.
in a location with strong
1 ft.
Wi-Fi signal, with two feet
2 ft.
of clearance in front and a
foot on either side.
3. Ensure the base is not
placed in area with direct
sunlight.
4. Plug in the base. The
LED will turn green
when it is powered on.
Install Ramp On Base
3
1. Align the flat side of the
ramp with the bottom of
the base.
2. Lift the ramp slightly
above the base, align,
and press down until the
ramp clicks into place.
3. Leave at least 2 ft. of
hard floor space in front
of the base, starting from
the end of the ramp.
Do not place the base
within 2 feet of carpet.
Fill The Clean Water Tank
4
1. Lift the water tank off the
front of the base.
2. Add 12 oz. of cleaning
solution. Fill the rest
of the tank with room-
temperature water up
to the MAX fill line, then
reinstall the tank.
BASE
™
Attach a Side Brush
5
to Bottom of Robot
1. The side brush can be
Side Brush
found inside the robot
box.
2. Align the hole in the
brush over the peg on the
bottom of the robot, then
press down on the brush
until it clicks into place.
Slide Robot Onto Base
6
1. Align the robot with the
Shark logo upside down,
then slide it up the ramp,
onto the base.
2. The LEDs on the base
will turn green when the
robot is charging.
3. After 10 to 15 seconds,
the robot will begin to
evacuate dust and debris
into the base.
Download & Explore
7
SharkClean App
™
or press the Dry icon on your robot
to start a dry clean.
App Features
Mapping
✔
Scheduling
✔
No-Go Zones
✔
Cleaning Reports
✔
s h a r kc l e a n . c o m
