MAINTENANCE OVERVIEW
To purchase parts and accessories, visit: https://www.sharkclean.com/sharkus/parts_accessories.
Component
Base Maintenance
BEFORE PERFORMING ANY MAINTENANCE, TURN OFF POWER
TO YOUR BASE BY UNPLUGGING IT FROM ITS POWER SOURCE.
Base Dust Bin
or 60 days, depending
NOTE: Capacity varies
depending on the model.
Base Pre-Motor Filter
Base Post-Motor Filter
(HEPA)
Base Ramp
Odor Neutralizer
Technology
NOTE: The Odor
Neutralizer Technology
is not included with
all models.
Clean Water Tank
or before every refill
Grey Water Tank
NOTE: Not all models
include a grey water tank.
s h a r kc l e a n . c o m
Frequency Replacement Part(s)
XDRV28LXD
XDRV28LXDO
Every 30
XDRV28XLDC
XDRV28XLD1
on the model
XDRV28XLDO
XDRV28XLD2
Every 30 days,
XBPFRV2500
or as needed
Every 6 months,
XPSFRV2500
or as needed
XDRV2800RPL
Every 3 months,
or as needed
XDRV2800RP
Every 6 months,
268ZQ3000
or as needed
XDRV28LCWT
Every 30 days,
XDRV28XLCW
Every 30 days,
XDRV28XLDW
or as needed
MAINTENANCE OVERVIEW
To purchase parts and accessories, visit: https://www.sharkclean.com/sharkus/parts_accessories.
Component
Robot Maintenance
BEFORE PERFORMING ANY MAINTENANCE, POWER OFF YOUR ROBOT.
TO DO THIS, PRESS AND HOLD THE DOCK ICON ON THE ROBOT FOR 5-7 SECONDS.
REMOVE THE ROBOT WATER TANK.
Brushroll
Filter
Mop Pad
NOTE: After a wet clean mission,
the NEVERTOUCH PRO™ base
will automatically wash the
robot mop pad. Regardless, it
is recommended to clean the
mop pad in the washing machine
or replace the pad every three
months or as needed.
Sensors and Charging Contacts
Side Brush
Sensor Name
Cliff Sensor
Lidar Sensor
3D Sensor
Wall Follow Sensor
Frequency Replacement Part(s)
Every 30 days,
278KKU2800
or as needed
Every 30 days,
XPRFRV2500
or as needed
PADRV28WDA
Every 3 months,
or as needed
PADRV28WD
Every 30 days,
N/A
or as needed
As needed 102KY1000
Functional Description
Cliff sensors monitor the cliff to avoid falling by way
of infrared ranging. If there is a downward stair in
front (e.g. the height of the white ground
is greater than 50mm, or the black ground is greater
than 30mm), the reading value of the sensor exceeds
the preset value, then robot stop moving forward.
Lidar sensor help robot map through laser ranging.
Detective distance is 8m.
With 2 line-lasers and an IR camera, the 3D sensor
scans the objects to identify the image through
algorithms. FOV: H=100°, V=78.7°.
Wall follow sensor detects the distance between
the objects and the left side of the robot by the TOF
ranging. Detective distance is 30mm.
