Owner's Manual
Heavy-Duty
Tilt Flat Screen Wall Mount
CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY. SERIOUS INJURY OR PROPERTY
DAMAGE MAY OCCUR!
50x50 / 75x75 / 100x100 / 100x150
100x200 / 150x100 / 150x150 / 200x100
200x200 / 200x400 / 300x200 / 300x300
350x350 / 400x200 / 400x300 / 400x400
Este manual está disponible en español en la página de Eaton:
Tripplite.Eaton.com/support
Ce manuel est disponible en français sur le site Web de Eaton :
Tripplite.Eaton.com/support
Русскоязычная версия настоящего руководства представлена на веб-сайте компании
Eaton по адресу: Tripplite.Eaton.com/support
Dieses Handbuch ist in deutscher Sprache auf der Eaton-Website verfügbar:
Tripplite.Eaton.com/support
70"
MAX
PRODUCT REGISTRATION
Register your product today for a
chance to win an ISOBAR
surge
®
protector in our monthly drawing!
Tripplite.Eaton.com/warranty
Model:
DWT2670XE
165 lb.
165 lb.
(75 kg)
(75 kg)
MAX
MAX
1
Advertisement
Related Manuals for Eaton TRIPP LITE DWT2670XE
Summary of Contents for Eaton TRIPP LITE DWT2670XE
- Page 1 350x350 / 400x200 / 400x300 / 400x400 Este manual está disponible en español en la página de Eaton: Tripplite.Eaton.com/support Ce manuel est disponible en français sur le site Web de Eaton : Tripplite.Eaton.com/support Русскоязычная версия настоящего руководства представлена на веб-сайте компании...
-
Page 2: Important Safety Instructions
PRODUCT REGISTRATION Visit Tripplite.Eaton.com/warranty today to register your new product. You’ll be automatically entered into a drawing for a chance to win a FREE Eaton Tripp Lite series product!* * No purchase necessary. Void where prohibited. Some restrictions apply. See website for details. -
Page 3: Component Checklist
Component Checklist IMPORTANT: Ensure you have received all parts according to the component checklist prior to installing. If any parts are missing or faulty, visit Tripplite.Eaton.com/support for service. (x2) (x2) (x1) (x1) (x4) (x3) Package M M5x14 M6x14 M6x25 M8x25... - Page 4 Installation 60mm O 10mm 55mm O 4.5mm (2.4") (O 3/8") (O 3/16") (2.2")
- Page 5 Installation WARNING • Make sure that mounting screws are anchored into the center of the studs. Use of a stud finder is highly recommended. • When installing wall mounts onto a concrete masonry unit (also known as a CMU or “cinder block”), verify that the actual concrete thickness is at least 35 mm (1-3/8”) in order to hold the concrete anchors.
- Page 6 Installation Too Long Too Short Note: Choose appropriate screws, washers and spacers (if necessary) according to the type of screen. • Position the adapter brackets as close as possible to the center of the display. • Firmly secure the adapter brackets onto the display using the screws and any other necessary hardware components included with the unit.
- Page 7 Tighten the two screws of the adapter brackets to secure the unit. Maintenance • Check that the bracket is secure and safe to use at regular intervals (at least every three months). • Please visit Tripplite.Eaton.com/support if you have any questions.
- Page 8 Eaton 1000 Eaton Boulevard Cleveland, OH 44122 United States Eaton.com © 2024 Eaton Eaton is a registered trademark. All Rights Reserved Publication No. 23-06-342 / 93-41A4_RevB All trademarks are property March 2024 of their respective owners.
