- Page 1 Installation Guide RE 2 Post Rack System RE 2 Post Rack Assembly and Installation Guide Issue 1...
- Page 2 TABLE OF CONTENTS SAFETY WARNINGS Frame Assembly Guide 4 - 6 Vertical Cable Manager Assembly Guide 7 + 8 Adjustable Cable Spools 9 + 10 Vertical Cable Basket Earth Bonding RE 2 Post Rack Assembly and Installation Guide Issue 1...
- Page 3 1. SAFETY WARNINGS This manual contains important instructions that you should follow during installation and main- tenance of the RE 2 Post Rack system. Please read all instructions before operating the equip- ment and save this manual for future reference.
- Page 4 RE 2 POST VERTICAL MOUNTING RAIL RE 2 POST BOTTOM ANGLE RE 2 POST TOP ANGLE M8 SHAKEPROOF WASHER M8 x 20mm HEX HEAD BOLTS BRACKET ASSEMBLY FOR PDU & CABLE BASKET RE 2 Post Rack Assembly and Installation Guide Issue 1...
- Page 5 M8 washers and 2 x M8 x 20 Hex Head bolts, then FINGER TIGHTEN. Item 1 Step - 4 Turn the rack over and repeat Steps 2 and 3. Figure - 2 RE 2 Post Rack Assembly and Installation Guide Issue 1...
- Page 6 If required, install the 2 Cable Basket / PDU brackets to the RE 2 Post Rack vertical mounting rail side or, using cage nuts, to the 19” rail. Once secured to the floor the rack is now ready for equipment installation.
- Page 7 3. RE 2 Post Rack Vertical Cable Manager Assembly Guide ITEM DESCRIPTION RE 2 POST FRAME RE CABLE MANAGER M10 x 20 HEX HEAD BOLTS M10 WASHER M10 HEX FULLNUTS RE 2 Post Rack Assembly and Installation Guide Issue 1...
- Page 8 Position the Cable Manager and Tighten all fixings to 12 Nm (tolerance +/- 2 Nm) Step - 4 Repeat step 1-2 on the opposite side of the RE 2 Post rack RE 2 Post Rack Assembly and Installation Guide Issue 1...
- Page 9 Installation Guide 4. RE 2 Post Rack Adjustable Cable Spools ITEM DESCRIPTION RE 2 POST RACK ADJUSTABLE CABLE SPOOL 5 PER KIT M5 THUMB NUTS 2 PER SPOOL RE 2 Post Rack Assembly and Installation Guide Issue 1...
- Page 10 Offer up a cable spool to the 2 holes in the vertical rail (Note there are 5 positions available on the rail). Thread on and tighten the thumb nuts. Step - 3 Repeat step 1-2 where required. RE 2 Post Rack Assembly and Installation Guide Issue 1...
- Page 11 Please note; 300mm Cable Basket is supplied with bracket assembly RE2PRCBPDUBA as detailed above. To mount 100mm or 200mm Cable Bas- kets in this way additional brackets RE2PRCBPDUBA will need to be ordered separately. RE 2 Post Rack Assembly and Installation Guide Issue 1...
- Page 12 Installation Guide 6. RE 2 Post Rack Earth Bonding. The RE 2 Post Rack vertical mounting rails have earth bonding holes at both top and bottom. This enables easy earth bonding from above or below. Step - 1 1 serrated nut and bolt kit is supplied as standard for the purpose of earth bonding (see Fig 1).
- Page 13 Only order confirmations and technical docu- mentation by Eaton is binding. Photos and pictures also do not warrant a specific layout or functionality. Their use in whatever form is subject to prior approval by Eaton. The same applies to Trademarks (especially Eaton, Moeller, and Cutler-Hammer).
