  • Page 1 Original operating manual Sliding frame VR 2 SmartLearning www.amazone.de...
  • Page 2 Please enter the identification data of the implement. The identification data can be found on the rating plate.

  • Page 3: Table Of Contents

    Positions of the warning symbols 7 Using the machine 4.4.2 Layout of the warning symbols Using the implement 4.4.3 Description of the warning symbols Rating plate on the implement More information on the implement 29 MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...
  • Page 4 Disconnecting the hydraulic hose lines 11 Loading the implement 11.1 Loading the implement with a crane 12 Disposing of the implement 13 Appendix 13.1 Bolt tightening torques 13.2 Other applicable documents 14 Directories 14.1 Glossary MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 5: About This Operating Manual

    WARNING Indicates a possible threat with moderate risk for severe physical injury or death. CAUTION Indicates a threat with low risk for light or moderately severe physical injuries. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 6: Further Instructions

    Example: 1. Instruction 1 2. Instruction 2 1.2.3.2 Instructions and responses CMS-T-005678-B.1 Reactions to instructions are marked with an arrow. Example: 1. Instruction 1 Reaction to instruction 1 2. Instruction 2 MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...
  • Page 7 CMS-T-00013932-B.1 WORKSHOP WORK Identifies maintenance work that must be performed at a workshop that is adequately equipped in terms of agricultural technology, safety and environmental technology by specialist personnel with appropriate training. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 8: Lists

    A list of other applicable documents can be found in the Appendix. 1.4 Digital operating manual CMS-T-00002024-B.1 The digital operating manual and e-learning can be downloaded from the Info Portal on the AMAZONE website. 1.5 Your opinion is important CMS-T-000059-D.1 AMAZONEN-WERKE H. Dreyer &...

  • Page 9: Safety And Responsibility

    2.1.2.1.1 Requirements for persons working with the implement CMS-T-00002310-C.1 If the implement is used improperly, people can be injured or killed: To prevent accidents due to improper use, every person who works with MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...
  • Page 10 Farmers are basically familiar with working with agricultural implements and can instruct agricultural helpers in how to use the implements if necessary. They can perform odd tasks and simple maintenance and repair work on agricultural implements themselves. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...
  • Page 11 Passengers can fall, be run over and severely injured or killed due to machine movements. Ejected objects can hit and injure passengers. Do not let anybody ride on the machine. Do not let anybody climb onto the driving machine. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...
  • Page 12 Non-observance of the technical limits values of the machine can result in accidents and serious personal injury or even death. Moreover, the machine can be damaged. The technical limit values can be found in the Technical Data. Comply with the technical limit values. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...
  • Page 13 Missing warning symbols increase the risk of serious and lethal personal injury. Clean dirty warning symbols. Immediately replace any damaged and illegible warning symbols. Put the intended warning symbols on spare parts. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 14: Knowing And Preventing Dangers

    If the universal joint shaft is angled down too strongly: Switch off the universal joint shaft drive. If you do not need the universal joint shaft: Switch off the universal joint shaft drive. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...
  • Page 15 When the drives are switched off, machine parts can continue running and cause serious personal injury or death. Before approaching the machine, wait until any machine parts that are still running have come to a stop. Only touch machine parts that are standing still. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...
  • Page 16 This also applies for quick checking work. Risk of falling between the hoeing elements When you are moving between the hoeing elements to adjust the implement, be very careful. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 17: Safe Operation And Handling Of The Machine

    Use only suitable tractors for coupling and transporting the implement. When the implement is coupled onto the tractor, make sure that the tractor's connecting device meets the implement requirements. Couple the implement properly to the tractor. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...
  • Page 18 Use the warning beacon in compliance with the national regulations. Switch off the work lights. Lock the tractor control units. Follow the instructions in the section "Preparing the implement for road travel". MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 19: Safe Maintenance And Modification

    To ensure that the operating permit remains valid in accordance with national and international regulations, ensure that the specialist workshop only uses conversion parts, spare parts and special equipment approved by AMAZONE. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...
  • Page 20 Remove the ignition key and carry it with you. Wait until all parts that are still running come to a stop and until hot parts cool down. Do not stand on moving parts. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...
  • Page 21 Never modify safety-related components. Never drill out existing holes. Perform all maintenance work at the prescribed maintenance intervals. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...
  • Page 22 2.1.5.3 Operating materials CMS-T-00002324-C.1 Unsuitable operating materials Operating materials that do not meet AMAZONE requirements can cause implement damage and accidents. Only use operating material that meet the requirements in the Technical Data. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 23: Safety Routines

    CMS-T-00002325-B.1 Special equipment, accessories, and spare parts Special equipment, accessories, and spare parts that do not meet AMAZONE requirements can impede the operational safety of the implement and cause accidents. Only use original parts or parts that meet AMAZONE requirements.
  • Page 24 2 hands and one foot or 2 feet and one hand on the implement. When climbing up and down, never hold onto the control elements. When climbing down, never jump off of the implement. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 25: Intended Use

    AMAZONE. Uses other than those specified under the intended use are considered as improper. The manufacturer is not liable for any damage resulting from improper use, solely the operator is responsible. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 26: Product Description

    Camera adjustment rail with camera Support wheel Stabilisation disc Rating plate on the implement 4.2 Function of the implement CMS-T-00014792-A.1 The implement pushes the towed hoeing machine transverse to the direction of travel, to guide the MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 27: Special Equipment

    The following equipment is considered special equipment: Preparation for Section Control Stabilisation disc Extension set for the support wheels Wheel scraper MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 28: Warning Symbols

    A warning symbol consists of two fields: Field 1 shows the following: A pictogram depicting the danger area, CMS-I-00000416 surrounded by triangular safety symbol The order number Field 2 shows a pictogram depicting how to avoid the danger. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 29: Description Of The Warning Symbols

    Maintain an adequately safe distance from electrical transmission lines, especially when folding or unfolding implement parts. CMS-I-000692 Please note that the voltage can flash over when the distance is too small. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...
  • Page 30 If you are injured by hydraulic oil, consult a doctor immediately. CMS-I-000216 MD 100 Risk of accidents due to improperly attached lifting gear Only attach the lifting gear at the marked positions. CMS-I-000089 MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...
  • Page 31 CMS-I-00002253 MD 199 Risk of accident if the hydraulic system pressure is too high Only couple the implement to tractors with a maximum tractor hydraulic pressure of 210 bar. CMS-I-00000486 MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 32: Rating Plate On The Implement

    MD278 CMS-I-00007679 4.5 Rating plate on the implement CMS-T-00004505-J.1 Implement number Vehicle ID number Product Permissible technical implement weight Model year Year of manufacture CMS-I-00004294 MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 33: More Information On The Implement

    4.6.1 Information picture for the hydraulic oil filter CMS-T-00015868-A.1 The information picture marks the position of the hydraulic oil filter. MD153 CMS-I-00003489 4.7 Document holder CMS-T-00014822-A.1 The document holder contains the following items: Documents Aids CMS-I-00009552 MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 34: Technical Data

    Tractor pump output for front tank FT-P at least 30 l/min at 150 bar HLP 68 DIN 51524-2 Implement hydraulic oil The hydraulic fluid is suitable for the combined hydraulic fluid circuits of all standard tractor brands. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 35: Noise Development Data

    The workplace-related emission sound pressure level is lower than 70 dB(A), measured in operating condition at the ear of the tractor driver with the cab closed. The emission sound pressure level mainly depends on the vehicle used. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 36: Preparing The Machine

    Total weight of front-mounted implement or front ballast Permissible total weight of rear-mounted implement or rear ballast Distance between the centre of gravity of the front-mounted implement or the front ballast and the centre of the front axle MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...
  • Page 37 T b 0,2 T b Vmin Vmin Vmin CMS-I-00000513 2. Calculate the actual front axle load. × × - × G a b T b G c + d Vtat Vtat Vtat CMS-I-00000516 MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...
  • Page 38 Tyre load according to according to capacity for two tractor operating calculation tractor tyres manual ≤ Minimum front ballasting ≤ Total weight ≤ ≤ Front axle load ≤ ≤ Rear axle load MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 39: Coupling The Implement

    CMS-I-00000121 Type of actuation Hydraulic function Symbol Latching Permanent hydraulic oil circulation Hydraulic oil flow until action is Momentary executed Free hydraulic oil flow in the tractor Floating control unit MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...
  • Page 40 Connect the pressureless hydraulic return flow to the intended coupling. Depending on the implement equipment: couple the leakage oil line in the intended coupling. Install the supplied coupling sleeve on the pressureless hydraulic oil return. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 41: Coupling The Isobus Lines

    If the hoeing machine to be coupled onto the sliding frame is an implement with hydraulically lifting parallelograms and without band sprayer and front tank: perform steps 3 and 4, otherwise continue with step 5. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...
  • Page 42 If the hoeing machine to be coupled onto the sliding frame is an implement with hydraulically lifting parallelograms and with band sprayer and front tank: perform steps 12 to 16. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 43: Coupling The Three-Point Mounting Frame

    2. Couple the lower links from the tractor seat. 3. Couple the top link 2 . 4. Check whether the top link catch hooks 3 and lower link catch hooks 4 are correctly locked. CMS-I-00001225 MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 44: Removing The Parking Support

    Enough space must remain between the implement and the hoeing machine so that the supply lines can be coupled without obstructions. 2. Drive the implement towards the hoeing machine, leaving a sufficient distance. CMS-I-00009585 MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...
  • Page 45 Lift the implement from the tractor seat. 7. Close the locking mechanisms for the lower link catch hooks. 8. Check whether the locking mechanisms of the lower link catch hooks are correctly locked. CMS-I-00009614 MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...
  • Page 46 If the hoeing machine is equipped with a front tank and band sprayer: Couple the hydraulic hose lines marked in red 1 for the pump of the front tank onto the couplings. CMS-I-00009661 MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 47: Preparing The Implement For Operation

    MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 48: Adjusting The Working Position Sensors

    2. Lift the implement to the desired lifting height. The guide arm 6 is pressed down. CMS-I-00009641 3. Slide the plastic sleeve 7 to a level area of the top link. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 49: Shifting The Camera Bracket

    6.6 Preparing the machine for road travel CMS-T-00014843-A.1 1. Align the hoeing machine centred behind the tractor using the camera terminal. 2. Lock the tractor control unit for the sliding hydraulic system. 3. Switch off the camera terminal. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 50: Using The Machine

    1. Follow the section "Turning on the headlands" in the instructions for the hoeing machine. 2. Lift the hoeing machine over the crops. The camera system automatically shifts the sliding frame in the centre position. 3. Turn around. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 51: Turning On The Headlands

    5. Manually align the hoeing machine on the rows using the camera terminal. 6. Lower the implement. 7. Drive. The camera system controls the sliding frame. 8. Check whether the camera system is working properly. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 52: Eliminating Faults

    Properly adjust the tilt and insufficient. height of the camera, see camera system operating manual. If the weed population is too high or the crop too tall: control the sliding frame manually. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...
  • Page 53 Use narrow tyres. A stabilisation disc is not installed. Install a stabilisation disc on the sliding frames. The stabilisation disc does not Adjust the stabilisation disc, penetrate into the soil. see page 43. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 54: Repairing The Machine

    Thoroughly clean the grease nipples and the grease gun. Only grease the implement with the lubricants listed in the technical data. CMS-I-00002270 Press the dirty grease completely out of the bearings. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 55: Overview Of Lubrication Points

    9 | Repairing the machine Lubricating the implement 9.1.1 Overview of lubrication points CMS-T-00014800-A.1 CMS-I-00009634 Every 20 operating hours CMS-I-00009635 CMS-I-00009636 CMS-I-00004533 CMS-I-00005776 MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 56: Maintaining The Implement

    3. Retighten loose bolted connections. Hydraulic hose lines must not be more than 6 years old. 4. Check the manufacturing date 1 . CMS-I-00000532 WORKSHOP WORK 5. Replace worn, damaged or aged hydraulic hose lines. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 57: Checking The Lower Link Pins And Top Link Pins

    Do not exceed a water pressure of 120 bar. 1. Only blow off the implement with compressed air. 2. Remove heavy soiling on the tools with a high- pressure cleaner or a hot water high-pressure cleaner. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 58: Parking The Machine

    Uncouple the hydraulic hose lines marked in red 1 for the pump of the front tank and hang them in the hose cabinet of the front tank. CMS-I-00009661 MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...
  • Page 59 Enough space must remain between the implement and the hoeing machine so that the supply lines can be uncoupled without obstructions. 9. Drive the implement away from the hoeing machine, leaving a sufficient distance. CMS-I-00009585 MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...
  • Page 60 13. Close the locking mechanisms for the lower link catch hooks. CMS-I-00009624 MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 61: Putting On The Parking Support

    There must be enough space between the tractor and implement so that the supply lines can be uncoupled without obstructions. Drive the tractor away from the implement, leaving a sufficient distance. CMS-I-00004045 MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 62: Uncoupling The Isobus Lines

    3. Disconnect the hydraulic hose lines 1 . 4. Put the dust caps on the hydraulic sockets. CMS-I-00001065 5. Hang the hydraulic hose lines 1 in the hose cabinet. CMS-I-00001250 MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 63: Loading The Implement

    Only attach the slings for lifting at the CMS-I-00009583 marked lashing points. 1. Attach the slings for lifting on the intended lashing points. 2. Slowly lift the implement. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 64: Disposing Of The Implement

    2. Return batteries to the distributor Dispose of batteries at a collection point. 3. Put recyclable materials in the recycling. 4. Treat operating materials like hazardous waste. WORKSHOP WORK 5. Dispose of the coolant. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 65: Appendix

    380 Nm 290 Nm 405 Nm 485 Nm 27 mm M18x1.5 325 Nm 460 Nm 550 Nm 410 Nm 580 Nm 690 Nm 30 mm M20x1.5 460 Nm 640 Nm 770 Nm MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 66: Other Applicable Documents

    2.4 Nm 112 Nm 4.9 Nm 174 Nm 8.4 Nm 242 Nm 20.4 Nm 342 Nm 40.7 Nm 470 Nm 70.5 Nm 589 Nm 13.2 Other applicable documents CMS-T-00015861-A.1 Tractor operating manual MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...

  • Page 67: Directories

    Tractor In this operating manual, the designation tractor is always used, even for other agricultural tractor units. Implements are mounted on the tractor or towed by the tractor. MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...
  • Page 68 Digital operating manual Dimensions loading Document holder Description Loads calculation Documents Lower link pin checking Eliminating faults lubricating Front axle load Maintenance calculation Mounting categories Front ballasting calculation Noise development data MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...
  • Page 69 Eliminating faults Workshop work Road travel preparing Special equipment Description Stabilisation disc adjustment Position Support wheels adjustment Position Technical data Dimensions Noise development data Performance characteristics of the tractor Permitted mounting categories MG7894-EN-GB | A.1 | 12.11.2024 | © AMAZONE...
