- Page 1 Line Interactive UPS PowerWalker VI 650 LCD/UK PowerWalker VI 850 LCD/UK PowerWalker VI 1000 LCD/UK PowerWalker VI 1500 LCD/UK PowerWalker VI 2000 LCD/UK Quick Start Guide...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS – This manual contains important instructions for models PowerWalker VI 650/850/1000/1500/2000 LCD /UK that should be followed during installation and maintenance of the UPS and batteries. This product is specially designed for PCs and it is not recommended for use in any life- supporting system and other specific important equipment. - Page 3 Servicing of batteries should be performed or supervised by personnel knowledgeable of batteries and the required precautions. Keep unauthorized personnel away from batteries. When replacing batteries, replace with the same type and number of the sealed lead-acid batteries. ...
-
Page 4: Package Contents
1. Introduction PowerWalker VI series is an intelligent and compact line interactive UPS (Uninterruptible Power Supply) which is designed to protect your personal computer or sensitive electronic equipments from all forms of power interference, including complete power failures. It is equipped with many features that allow any attached equipment to operate longer and more reliability. -
Page 5: Product Overview
4. Product Overview Front Panel: LCD Panel: LCD panel Input voltage Load level indicator, flashing Output voltage indicates overload Power switch AC mode indicator Battery capacity indicator, flashing Battery mode indicator indicates low battery Back Panel: VI 650/850 LCD/UK VI 1000 LCD/UK... -
Page 6: Installation And Initial Startup
4. Installation and Initial Startup Before installation, please inspect the unit. Be sure that nothing is damaged. I: Placement & Storage Conditions Install the UPS in a protected area that is free of excessive dust and has adequate air flow. Please place the UPS away from other units at least 20 cm to avoid interference. -
Page 7: Software Installation On Your Pc
NEVER connect a laser printer or scanner to the UPS unit, because in-rush current generated by motor’s devices may cause the damage of the unit. VI: Turn On/Off the Unit Turn on the UPS unit by pressing the power switch. Turn off the UPS unit by pressing again the power switch. -
Page 8: Specifications
8. Specifications Model VI 650 LCD/UK VI 850 LCD/UK CAPACITY 650 VA / 360 W 850 VA / 480 W INPUT Voltage 220~240 VAC Voltage Range 162~290 VAC Frequency Range 50/60Hz±1Hz OUTPUT Voltage Regulation +/-10% Transfer Time Typical 2-6 ms, 10 ms max.
