- Page 1 Manual PowerWalker VI RLP Series 1000-3000...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS This manual contains important instructions. Please read and follow all instructions carefully during installation and operation of the unit. Read this manual thoroughly before attempting to unpack, install, or operate the UPS. CAUTION! The UPS must be connected to a grounded AC power outlet with fuse or circuit breaker protection. DO NOT plug the UPS into an outlet that is not grounded. -
Page 3: Basic Operation
BASIC OPERATION UPS FRONT/REAR PANEL DESCRIPTION Power On/Off Button Master ON/OFF for the UPS. Function Buttons Scroll up, scroll down, select, and cancel LCD menu in setting mode. Multifunction LCD Readout Indicate status information, settings, and events. Input Circuit Breaker Provide input overload and fault protection. - Page 4 DEFINITIONS FOR OTHER ICONS MUTE: This icon appears whenever the UPS is in silent mode. The alarm does not beep during silent mode until the battery reaches low capacity. EBM: Indicate the numbers of external battery module. SCHEDULE: Users can setup the schedule to turn on and shut down the computer and UPS through PowerMaster Management software.
-
Page 5: Lcd Display
LCD DISPLAY 1.Press the display key “UP/DOWN” to indicate the different item Item Description LCD display AC input 1st (default) AC output Battery remaining time Load capacity Battery capacity Temperature Output1 status Output2 status 5-7th Output3-8 status same to 4th 2.Press the “UP/DOWN”... -
Page 6: Lcd Settings Configuration
In setting mode, press this button to confirm selection ENTER In line mode, bypass mode, battery mode, press the button3 seconds to enable or disable the buzzer LCD SETTINGS CONFIGURATION There are 9 UPS settings that can be configured by the user. Press the "SETUP"... - Page 7 Battery Month test [EnA]/[dIS] Power on delay [EnA]/[dIS] Reset [yES]/[no] Event ID Descriptions Event ID Description of Case Remedy INV soft Start Fail INV Volt High Restart the UPS, if the fault is still, please contact Technical Support. INV Volt Low INV Short Your attached equipment may have problems, please remove them, and check again.
-
Page 8: Technical Specifications
TECHNICAL SPECIFICATIONS Model 1000R 2000R 3000R Configuration Capacity (VA) 1000VA 2000VA 3000VA Capacity (Watts) 900W 1800W 2700W Form Factor Rack/Tower Input Input Voltage 165 VAC ~290VAC Range Input Frequency 45~65Hz Range Input Power Factor 0.98 Cold Start Output Output Waveform Pure Sine Wave Output Voltage 230Vac ±10%... -
Page 9: Trouble Shooting Trouble Shooting
Step1 Step2 Step3 Step4 TROUBLE SHOOTING TROUBLE SHOOTING TROUBLE SHOOTING Problem Possible Cause Solution Warning Your equipment requires more power than the Shut off non-essential equipment. If this solves UPS can provide. If the UPS is in Line Mode, then O/P Overload the overload problem, the UPS will transfer to it will transfer to Bypass Mode;... - Page 10 INDIVIDUAL OUTLET CONTROL Method 1: Through LCD setting: Setting item 001-008 Method 2: Through PowerMaster+ Local: [UPS SETTING->CONFIGURATION] Method 3: Trough SNMP Card 2 Webpage: [UPS->Outlet Action->Outlet Management]...
-
Page 11: Software Download
Power Master+ management software provides a user-friendly interface for your power systems. The graphic user-interface is intuitive and displays essential power information at a glance. Please follow procedure below to install the software. Installation procedure: https://powerwalker.com/software/#powermaster Download PowerMaster from the website Double-click the file and follow the installation steps.
