Mini tracked dumper

Advertisement

Quick Links

Translated from German to English - www.onlinedoctranslator.com
MD-800HPRO
Art.No. MD800HPRO
09/2020
original operating
instructionsinstructions
D
mini tracked dumper MD-800HPER, hydraulict i l t a b l e
Model: MD-800HPER
Serial number:
Both the model number and the serial number can be found on the rating plate on the machine.
You should keep both numbers in a safe place for future reference. This manual explains the
basic functions and uses of the machine.
Read the operating instructions before using the device. Please note the safety and warning
instructions!
www.lumag-maschinen.de

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MD-800HPRO and is the answer not in the manual?

Questions and answers

Summary of Contents for Lumag MD-800HPRO

  • Page 1 Translated from German to English - www.onlinedoctranslator.com MD-800HPRO Art.No. MD800HPRO 09/2020 original operating instructionsinstructions mini tracked dumper MD-800HPER, hydraulict i l t a b l e Model: MD-800HPER Serial number: Both the model number and the serial number can be found on the rating plate on the machine.
  • Page 2: Table Of Contents

    CONTENTS General Information about the operating instructions limitation of liability copyright protection Intended Use safety instructions warnings General safety instructions work and danger area Personal Safety Safe handling of fuel Use and maintenance of the machine maintenance Special safety instructions electrical system 3.10 residual risks and protective measures 3.11 Behavior in an Emergency...
  • Page 3: General

    Information about the operating instructions This operating manual provides important information on how to use the MINI TRACKED DUMPER MD-800HPRO. The prerequisite for safe working is correct compliance with all specified safety instructions and handling instructions. In addition, the local accident prevention regulations and general safety regulations applicable to the area of application of the machine must be observed.
  • Page 4: Intended Use

    INTENDED USE SAFETY INSTRUCTIONS INTENDED USE The MINI TRACKED DUMPER is a motorized wheelbarrow, hand-held and has a four-speed gearbox with two gears. Thanks to its efficient reduction gear, the machine is able to move in any situation and under any load. The machine is suitable for small loading and transport tasks in gardening, landscaping and agriculture, taking into account the specifications and safety instructions listed in this manual.
  • Page 5 SECURITY 3. SECURITY This section provides a comprehensive overview of all important safety aspects for adequate protection of the operator and for safe and trouble-free operation. Failure to follow the instructions and safety information contained in this manual may result in significant hazards.
  • Page 6: General Safety Instructions

    SECURITY General safety instructions Familiarize yourself with the machine. Proper training is a prerequisite for working safely with this device. Incorrect operation or operation by untrained personnel can be dangerous. Read the operating instructions for this machine carefully and observe the labels on the machine.
  • Page 7: Work And Danger Area

    SECURITY work and danger area DANGER Internal combustion engines pose a particular danger during operation and when refueling. Always read and observe the warnings and the additional safety instructions listed further down in this manual. Failure to observe these instructions could result in serious or even fatal injuries.
  • Page 8: Safe Handling Of Fuel

    SECURITY – Safety shoes or boots with steel capsto protect against uneven, sharp-edged surfaces or falling objects. The safety footwear also ensures a secure footing. – protective helmetto protect the head from falling parts and swinging loads. It can also protect against injuries in confined situations. Inspect your machine before using it.
  • Page 9: Use And Maintenance Of The Machine

    SECURITY live parts and connections to avoid sparking or arcing. These events could ignite smoke or fumes. Always stop the engine and allow it to cool before filling the fuel tank. Never remove the fuel cap or add fuel when the engine is hot or running. Never operate the machine with known leaks in the fuel system.
  • Page 10: Maintenance

    SECURITY Service Center or our service team using original spare parts; otherwise, accidents may occur to the user. Maintain the machine. Make sure that all moving and fixed parts are in the correct position, that there are no broken parts or other defects that may affect the smooth operation of the machine.
  • Page 11: Electrical System

    SECURITY during assembly, installation and commissioning, maintenance, repair or laying. Ensure that spectators, children and animals are kept at least 22 Meter. If you approach, switch off the machine immediately. Do not climb onto the tipping trough or transport any persons. Never place the machine, especially when loaded, on an unstable Ground that could give way.
  • Page 12: 3.10 Residual Risks And Protective Measures

    SECURITY 3.10 residual risks and protective measures Mechanical residual hazards Squeeze Careless operation of the machine can result in serious injuries. → Be particularly careful on uneven terrain or slopes. Make sure that secure footing. neglect of ergonomic principles Negligent use of personal protective equipment (PPE) Careless use or omission of personal protective equipment can result in serious injury.
  • Page 13: Behavior In An Emergency

    SECURITY Danger from vibration whole-body vibration Prolonged work with the machine can lead to physical impairments due to vibrations. → Take regular breaks. Other hazards Slipping, tripping or falling of persons On unstable surfaces, you may be injured by tripping. →...
  • Page 14: Symbols

    SYMBOLS SYMBOLS Symbols are provided on the machine to provide important information about the product and instructions for use. DANGER! This is about your safety. The symbol indicates a danger, warningor cautionary statement. Before commissioning, read and observe the operating instructions and safety information carefully.
  • Page 15 SYMBOLS RISK OF TOLLING! If the maximum permitted incline is exceeded, there is a risk of tipping over. Under no circumstances should the maximum slope of 10% be exceeded. Never tip the container on soft ground or at an angle. WARNING! Danger of flying objects.
  • Page 16: Scope Of Delivery + Assembly

    SCOPE OF DELIVERY SCOPE OF DELIVERY + ASSEMBLY The all-terrain MINI TRACKED DUMPER with tipping trough (hydraulically tiltable forward) and petrol engine is delivered pre-assembled on a steel pallet. 1) Pre-assembled device unit with handlebar & petrol engine 4)mounting kit 2) tipping trough After unpacking, check the contents of the box or transport box for —...
  • Page 17: Functions And Controls

    FUNCTIONS AND CONTROLS FUNCTIONS AND CONTROLS tipping trough clutch lever gearshift gearbox crawler track engine switch ejector lever engine switch (2) The engine switch turns the ignition system on and off. The engine switch must be in the ON position for the engine to run. Turning the engine switch to the OFF position will turn the engine off.
  • Page 18 FUNCTIONS AND CONTROLS gear lever (7) This lever controls the forward and backward movements of the machine. gears (13) In addition, the manual transmission has two gears: “LOW” for slow and “HIGH” for fast. lever control valve (6) The tipping of the trough is done via the hydraulic pump and the hydraulic cylinder. You can raise and lower the tipping trough using the lever.
  • Page 19: Commissioning

    COMMISSIONING COMMISSIONING DANGER! You may only carry out the work described in this chapter after you have read and understood Chapter 3, “SAFETY”. It concerns your personal safety! Please note that the service life and operational reliability of the engine are largely dependent on the running-in period.
  • Page 20: Refill Hydraulic Oil

    COMMISSIONING Check engine oil level Unscrew the engine oil filler plug. Wipe the dipstick with a clean cloth and reinsert it, do not screw in. Remove the dipstick again and read the oil level, if necessary, top up the engine oil to the level mark Top up at the “UPPER LEVEL”.
  • Page 21: Refueling

    COMMISSIONING 4. Hydraulic oil must be refilled at half level at the latest to ensure safe use of the machine. 5. Before each start-up, check whether there is sufficient hydraulic oil in the tank. 6. The connections and screw joints must be checked regularly for leaks and tightened if necessary.
  • Page 22 COMMISSIONING Tank volume: 6.5 liters Refuel in a well-ventilated area with the engine stopped. If the engine has been running immediately before, allow it to cool down first. Never refuel the engine in a building where gasoline vapors can be reached by flames or sparks. Gasoline is extremely flammable and explosive.
  • Page 23: Operation

    OPERATION OPERATION DANGER! Check that every nut and screw is absolutely tight before using the machine. The machine vibrates heavily during operation. Screws that are not tightened tightly can come loose and get lost, leading to dangerous situations! DANGER Do not start the engine in enclosed spaces. The exhaust fumes contain carbon monoxide, which is very toxic if inhaled! CAUTION Be careful with hot engine parts!
  • Page 24: Idle

    OPERATION If the gear does not engage immediately, slowly release the clutch lever and repeat the process. This will cause the machine to start moving. A NOTICE The operator has the option of regulating the affected gears in two gear stages “LOW”...
  • Page 25: Manual Transmission

    OPERATION manual transmission The machine has a four-speed gearbox with two gears. manual transmission and gear ratios Raising and lowering the tipping trough The tipping and lowering of the trough is done via the hydraulic pump and the hydraulic cylinder. Be careful of damage to the hydraulics, especially the hose lines! Otherwise, the troughs falling down during the tipping process can cause serious injury to people and materials.
  • Page 26: Operating Instructions

    OPERATION Lever control valve (6) for raising and lowering the tipping trough operating instructions ■ The steering sensitivity increases proportionally to the speed and load of the machine: if the machine is unloaded, a light pressure on the lever is sufficient to produce a steering movement.
  • Page 27: Maintenance

    They must be aware of all dangers and risks associated with the device. Further work not described in this operating manual may only be carried out by your LUMAG specialist workshop or authorized specialist workshops. Before carrying out any cleaning, maintenance or repair work, switch off the engine, Wait until the machine has come to a standstill and then remove the spark plug connector.
  • Page 28: Adjusting The Clutch Cable

    MAINTENANCE Adjusting the clutch cable As the V-belts become worn, the response may change and proper operation may no longer be possible. In this case, the cable must be adjusted and the lever returned to its original position by operating the adjuster and adjusting the lock nut accordingly. Setting up the controls If the device is difficult to steer, the steering levers must be adjusted using the adjusting screw.
  • Page 29: Tensioning The Crawler Tracks

    MAINTENANCE refill transmission oil The oil filler plug is located on the left side of the gearbox, directly below the brake rod. It is unscrewed using the same hexagon socket wrench as the oil control screw. Then you have to fill the transmission oil via a hose or a special pump. There is enough oil in it if oil runs out of the opening again.
  • Page 30: Replacing The Crawler Tracks

    MAINTENANCE 3. Tighten screw B until the correct tension is restored. 4. Lock screw B by carefully tightening lock nut A. 5. Return the tipping trough to its original position and secure it. Adjusting the tracks affects the brakes. Please proceed with great caution as an over-tensioned chain will result in a loss of braking effect.
  • Page 31: Engine Maintenance

    MAINTENANCE Danger of crushing! When removing or installing the chains, be careful not to trap your fingers between the chain and the wheel. engine maintenance For information on engine maintenance, refer to the Engine Manual provided with your unit. This Engine Manual provides you with detailed information and a maintenance schedule to help you perform the appropriate tasks.
  • Page 32: Storage

    STORAGE 10. STORAGE DANGER Do not store the machine with fuel in an unventilated area where fuel vapors can come into contact with flames, sparks, pilot lights or other sources of ignition. Storing the machine for a month or longer. Thoroughly remove dust, dirt and deposits from the engine and machine.
  • Page 33: Transport

    TRANSPORT 11. TRANSPORT Before transporting or moving the device or storing it indoors: ■ To avoid burns and to eliminate the risk of fire, switch off the machine's engine and allow it to cool down. ■ Disconnect the spark plug connector. ■...
  • Page 34: Troubleshooting

    TROUBLESHOOTING 12. TROUBLESHOOTING Disturbance Caused remedy Securely attach the spark plug spark plug connector removed connector to the spark plug Lack of fuel or old fuel Fill with clean, fresh gasoline Push the choke lever into the The engine doesn'tstart Choke is not activated choke position fuel line blocked...
  • Page 35: Technicaldata

    TECHNICAL DATA 13. TECHNICAL DATA Model MD-800HPRO drive motor 1 cylinder 4-stroke OHV engine LONCIN G390F engine power 8.2 kW (at 3,000 rpm) displacement 389 cm³ transmission 6 forward gears / 2 reverse gears starting device recoil starter drive gear transmission...
  • Page 36: 14. Environment

    TECHNICAL DATA Dimensions in mm The values given are emission values and do not necessarily represent safe workplace values. Although there is a correlation between emission and immission levels, this cannot be used to reliably determine whether or not additional precautionary measures are necessary. Factors that influence the current immission level at the workplace include the nature of the work area, other noise sources, e.g.
  • Page 37: Warranty / Guarantee / Customer Service

    Please label the shipping box clearly with the SERVICE NUMBER to ensure quick identification. ensure. Warranty work is carried out exclusively by our LUMAG service workshop. Defects that occur within the warranty period due to material or manufacturing defects must be remedied by repair if they have occurred despite proper use and care of the device.
  • Page 38: Ec Declaration Of Conformity

    Telephone: +49 / (0)8571 / 92 556-0 Fax: +49 / (0)8571 / 92 556-19 that the product Designation: MINI-TRACKED DUMPER Type designation: MD-800HPRO meets the essential protection requirements of the above-mentioned EC directives. Conformity is based on the following standards: EN ISO 12100:2010...
  • Page 39: Components Of The Machine

    COMPONENTS OF THE MACHINE 17. COMPONENTS OF THE MACHINE brake lever: clutch lever:...
  • Page 40 COMPONENTS OF THE MACHINE Chassis:...
  • Page 41 COMPONENTS OF THE MACHINE Centrifugal clutch:...
  • Page 42 COMPONENTS OF THE MACHINE operating handle:...
  • Page 43 COMPONENTS OF THE MACHINE Trough:...
