- Page 1 GCW341UC...
-
Page 3: Table Of Contents
Contents Safety precaution ..........4 For the user Description of the appliance ......5 Gas burner control ..........6 Cleaning and Maintenance ........ 9 Troubleshooting guide.........12 For installation Installation instruction ........13 technician Connecting the hob to the mains .......16 Gas connection .......... - Page 4 Built-in gas hob This built-in gas hob is manufactured for household use. Our Dear Buyer, appliances are packed in environmentally friendly materials which may be recycled, deposited or destroyed without any hazard to the environment. Such packaging materials are also labeled accordingly.
-
Page 5: For The User Safety Precaution
Safety precautions • To avoid any possible hazard, the appliance must be installed by Registered Gas Installer employed by Registered Gas Contractors only. • During the operation of gas burners the room may be filled with extra heat and humidity, so it is necessary to assure adequate ventilation by keeping the natural air vents and by activating the mechanical aeration device (suction hood or ventilating fan). -
Page 6: Description Of The Appliance
Description of the appliance Description of the hob 1. Wok burner – 4.00kW 2. Cast iron cooking grating 3. Burner control button Control buttons Wok burner model Gas faucet closed High power Low power 23.3.2015202033... -
Page 7: Gas Burner Control
The location of grating 1. Cast iron cooking grating. 2. Centering – setting pin of the grating. · The cast iron cooking grating is heated up during appliance operation and remains hot during some time even after extinction of the gas burners. Therefore be always careful (also at manipulation with the control knobs), to prevent burning! ·... - Page 8 Wok burner: a) 1. Burner crown cap 2. Burner crown 3. Thermal probe 4. Ignition plug 5. Nozzle Ignition and operation of Wok burner model: burners · Cooking burner is controlled with the burner control button. These are marked with small flame and large flame symbols (see section ‘Description of the appliance’).
- Page 9 Always push the button in before starting to turn it! Burner type Dish diameter Wok (4.00k W) 220 - 260mm · To ignite the burner, press the burner control button and turn it anti-clockwise to the maximum power position Electric spark from the ignition device ignites the gas. ·...
-
Page 10: Cleaning And Maintenance
Cookware · Selection of the adequate dish size ensures optimized cooking time and consumption of gas. · The flame reaching over the edge of the small diameter dish may destroy the dish, while the consumption of gas increases. · Gas needs oxygen for burning. In case of excessively large dish diameter the oxygen supply is insufficient, reducing the burning capacity. - Page 11 Never use such cleaners for cleaning of aluminum. Clean plastic and coated surfaces should be cleaned with non-abrasive cleaning agents and soft cloth. Cooktop burners · The cast iron cooking grating, glass surface, burner crown cap and other accessories should be cleaned with warm cap and other accessories should be cleaned with warm cap and other accessories should be cleaned with warm water and mild detergent for manual washing of dishes.
- Page 12 Pattern marks on glass surface can become dull and rough, bottom of the cookware can also be damaged by the use of aggressive cleansing agents (fig. 2). Minor stains can be removed with moist soft cloth; after that the surface should be wiped to dry (fig. 3). Water stains should be removed with gentle vinegar solution.
-
Page 13: Troubleshooting Guide
Troubleshooting guide Repairs must be done by Registered Gas Installers only. Any unskilled attempt to repair the appliance is extremely dangerous. Before attempting any repairs, disconnect the appliance from the mains by removing the fuse or unplugging the mains lead from the mains socket. -
Page 14: Installation Instruction
Installation instructions Attention! According to the Gas Safety Ordinance of Hong Kong, any gas installation works including the installation of appliances and connection tubing, must be undertaken by registered gas installers who are registered for that appropriate classes and be employed by registered gas contractors. Use approved gas tubing bearing EMSD approval marking (such as : EMSD APPROVAL GTXXXX) for connection to appliances, or other appropriate methods accepted by EMSD. - Page 15 · The appliance must be installed in worktop with a thick- ness from 30 mm to 50 mm (see Installation Procedure). · Bottom kitchen element must not have a drawer. It must be fitted with a horizontal plate 150 mm away from the worktop bottom surface.
- Page 16 When installing several glassceramic hobs it is necessary to Installation of several separate them with intermediary short strip (to be purchased glass-ceramic hobs separately: parts no. 286696). 286696 23.3.201520201313...
-
Page 17: Connecting The Hob To The Mains
Connecting the hob to the mains · Connections must be carried out by a registered gas installer only. The earthing protection must comply with the standing regulations. · Connection terminals are revealed when the connection box cover is removed. · Prior any attempted connection check that the voltage indicated on the rating plate is in line with your home power supply. - Page 18 · Improper connection may damage parts of the appliance. Such damages are not covered by warranty! · Before attempting any connections check whether voltage indicated on the rating plate agrees with the installation in your home. Registered gas installers must check the user connection voltage (220 - 240 V against N) with the voltage meter! ·...
-
Page 19: Gas Connection
Gas connection Safety precautions · Connections must be carried out by a registered gas installer only. · The appliance must be connected in accordance with the standing regulations, and it may be used only in well venti- lated rooms. Before any attempt to connect the appliance read carefully the instructions! ·... - Page 20 Check sealing of all joints and couplings after connection. Gas connection joint A EN 10226 R1/2 connection B Non-metal gasket of 2 mm thickness After connection check whether the burners function properly. Hob burners Large and auxiliary burner a) 1. Burner crown cap 2.
-
Page 21: Nozzle Chart
Nozzle chart - gas ceramic hob... -
Page 22: Technical Information
Technical Information WE RESERVE THE RIGHT TO ALTER THE SPECIFICATIONS WITH NO INFLUENCE ON THE OPERATION OF THE APPLIANCE. - Page 24 2017 08 01 NO GCW341UC...
