Combined and gas built-in cooking hob

Advertisement

Quick Links

Instructions for use, installation,
MT
IE
GB
and connection
Combined and gas built-in cooking hob

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GC650KR and is the answer not in the manual?

Questions and answers

Summary of Contents for Gorenje GC650KR

  • Page 1 Instructions for use, installation, and connection Combined and gas built-in cooking hob...
  • Page 2: Table Of Contents

    Combined and gas built-in cooking hob Dear customer! Combined and gas built-in hob is intended for use in households. Our products are packed in environment-friendly materials which can be recycled, disposed of, or destroyed without imposing any burden on the environment. Instructions for use Instructions for use are intended for the user.
  • Page 3: Important - Read Before Using

    Important - Read before using the appliance Safety percautions • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or metal capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • Page 4 • The appliance is not connected to a fl ue or a ventilation opening. The appliance should be installed and connected in compliance with the relevant regulations on connection. Heat, moisture, and combustion by-products are released during the use of the cooking appliance in the room where it is installed. Make sure your kitchen is adequately ventilated, especially during the use of appliance.
  • Page 5: Appliance Description

    Appliance description (equipment - depending on the model) Upper side of a combined cooker with Upper side of a combined cooker with gas and electric cooking zones gas cooking zones 1. Cooking zone rear left 2. Cooking zone rear right 3.
  • Page 6: Cooking Zones

    Cooking zones A) Electric cooking zones Before using the Turn on the cooking zones for 3 to 5 minutes and select the appliance for the fi rst maximum power level; some fumes may be discharged from the time hob. This way, the protective cover on the cooking hob will reach its maximum solidness.
  • Page 7 Energy saving • Pan bottom diameters should match the diameter of the cooking zone. If the pan is too small, some heat is wasted; furthermore, using a too small pan can damage the cooking zone. • Whenever possible given the cooking process, use a lid. •...
  • Page 8 Cookware • Correctly selected cookware will enable optimum cooking time and gas consumption. Pan diameter is the most important parameter. • Flames that reach over the edge of a pan that is too small, can damage the cookware; furthermore, gas consumption is higher in such cases.
  • Page 9: Operating The Electric Cooking Zones

    Operating the electric cooking zones • Operate the cooking zones using the knobs, built into the control panels. • When at least one cooking zone is turned on, the yellow LED is lit up. • Power levels are indicated with the numbers from 1 to 6 on the control knobs.
  • Page 10: Operating The Gas Burners

    Operating the gas burners Ignition and operation of Models with two gas burners: the burners • Operate the gas burners using the knobs on the hob. Power levels are indicated on the knobs by large and small fl ame symbols (see section Appliance description). •...
  • Page 11: Cleaning And Maintenance

    Cleaning and maintenance Cleaning After each use of the glass-ceramic hob, wait for it to cool down and clean it; otherwise, even the smallest food residue will be burnt onto the hot surface next time you use the appliance. For regular cleaning and maintenance of the glass-ceramic surface, use special conditioning agents which form a protective layer on the surface, shielding it from dirt.
  • Page 12: Special Warnings And Fault Reporting

    residues or use of cookware made of materials such as aluminum or copper; these stains are diffi cult to remove. Warning: All damage described above predominantly relates to the aesthetics, i.e. appearance of the appliance and do not affect its functionality directly.
  • Page 13: Installation

    What happened...? Possible cause What to do? The burners will not burn Flame is uneven due to a Have an expert check he gas The fl ame is uneven / unstable wrong gas power setting. pipeline! The fl ame from the burners Wrongly assembled parts of the Assemble the burner correctly.
  • Page 14 • Use of massive wood decoration plates or boards on the worktops behind the cooking hob is permitted, if the minimum distance remains the same as indicated in the installation drawings. • Minimum distance between the built-in cooking hob and the rear wall is indicated on the installation drawing.
  • Page 15 • Only type EVP4.., EVP2.., ovens fi tted with a cooling fan may be installed underneath this cooking hob. • Before installing an oven, the rear wall of the kitchen furniture element should be removed in the area of the cooking hob cutout.
  • Page 16: Connecting The Appliance To The Power Mains

    Connecting the appliance to the power mains Important warnings • The appliance may only be connected by an authorized skilled technician. • Electric system protection should comply with all relevant regulations. • The connection clips can be accessed when the connection clip covers are opened / removed. •...
  • Page 17: Connecting The Cooking Hob To The Gas Supply

    NOTE: Connection bridges are already installed on their respective places on the clip. Screws of the connection terminals are open, which means they do not have to be unfastened or unscrewed any further. When fastening the screws, you may hear a slight ‘click’, which means that the screws should be fastened / screwed in completely.
  • Page 18 • For sealing of the connection joints, use a non-metal approved gaskets and approved sealants. • The gaskets should only be used once. The thickness of the fl at non-metal gaskets should not be deformed more than by 25 percent. •...
  • Page 19 Cooker burner 1 Burner crown cover 2 Burner crown with cover support 3 Thermo-element (only in protected burners, only available in some models) 4 Spark plug 5 Nozzle Adjustment elements To leave the adjustment elements accessible, please observe the following instructions: •...
  • Page 20: Nozzle Table

    Nozzle table gas type, pressure Auxiliary burner Normal burner Large burner Natural gas H Nom. therm. load (kW) 0,36 1,75 0,46 0,76 Wo=45,7÷54,7 MJ/ m Consumption (l/h) 95,21 34,4 166,62 4308 285,64 72,4 Natural gas E , Nozzle type (1/100mm) Natural gas E+ Nozzle code Wo=40,9÷54,7 MJ/m...
  • Page 21: Technical Characteristics

    H Factory settings for gas type WE RESERVE THE RIGHT TO MAKE ANY CHANGES THAT DO NOT AFFECT THE FUNCTIONALITY OF THE APPLIANCE. Instructions for use of the appliance can also be found on our website at www.gorenje.com / < http://www.gorenje.com />...
  • Page 24 PVK,KVK62S en (01-14)
