- Page 1 STICK AUTO-DARKENING WELDING HELMET PLASMA GRIND OPERATING MANUAL ARCMASTER XC30 CIGWELD OPERATING MANUAL ARCMASTER XC30 V1-2023 4 ARC HIGH QUAD 1 XTRA CLARITY SENSORS IMPACT RATING LENS 65mm VIEWING AREA...
- Page 2 CIGWELD is the Market Leading Brand of Arc Welding Products is backed by our extensive warranty and world-wide service for ESAB. We are a mainline supplier to major welding industry network. To locate your nearest distributor or accredited sectors in the Asia Pacific and emerging global markets service provider call +1300 654 674, or visit us on the web at including;...
- Page 3 ARCMASTER XC30 AUTO DARKENING WELDING HELMET Where Purchased: Published by: Purchase Date: CIGWELD Pty Ltd CIGWELD An ESAB Brand 71 Gower Street, Preston VIC 3072 Australia CUSTOMER CARE: Tel: 1300 654 674 | Intl Tel: +61 3 9474 7400 Email: enquiries@cigweld.com.au CIGWELD.COM.AU ©...
-
Page 4: Table Of Contents
ARCMASTER XC30 AUTO-DARKENING WELDING HELMET OPERATING MANUAL TABLE OF CONTENTS SECTION 1: SECTION 6: ARC WELDING SAFETY HARNESS ADJUSTMENT INSTRUCTIONS AND WARNINGS SECTION 7: 1.01 SAFETY INSTRUCTIONS INSTALLATION OF 1.02 DECLARATION OF CONFORMITY MAGNIFICATION LENS 1.03 LIMITED WARRANTY (OPTIONAL) SECTION 2: SECTION 8: INTRODUCTION CHANGING OF FRONT AND REAR... -
Page 5: Arc Welding Safety Instructions And Warnings
OPERATING MANUAL ARCMASTER XC30 AUTO-DARKENING WELDING HELMET SECTION 1: ARC WELDING SAFETY INSTRUCTIONS AND WARNINGS WARNING ARC WELDING can be hazardous. Protect yourself and others from possible serious injury or death. Keep children away. Do not lose these instructions. Read operating manual before installing, operating or servicing this product. Welding products and welding processes can cause serious injury or death, or damage to other equipment or property, if the operator does not strictly observe all safety rules and take precautionary actions. - Page 6 ARCMASTER XC30 AUTO-DARKENING WELDING HELMET OPERATING MANUAL ELECTRIC SHOCK FLYING SPARKS AND HOT METAL WARNING WARNING ELECTRIC SHOCK can kill. FLYING SPARKS AND HOT METAL can cause injury. Touching live electrical parts can cause fatal Chipping and grinding cause flying metal. As welds shocks or severe burns.
-
Page 7: Declaration Of Conformity
OPERATING MANUAL ARCMASTER XC30 AUTO-DARKENING WELDING HELMET CYLINDERS Examine devices and make sure the battery compartment is correctly secured, e.g. that the screw or other mechanical fastener is tightened. Do not use if WARNING compartment is not secure. CYLINDERS can explode if damaged. Dispose of used button batteries immediately and safely. -
Page 8: Limited Warranty
CIGWELD/ESAB This warranty is provided in addition to other rights and remedies you have under... -
Page 9: Introduction
OPERATING MANUAL ARCMASTER XC30 AUTO-DARKENING WELDING HELMET SECTION 2: INTRODUCTION 2.01 HOW TO USE THIS MANUAL 2.02 EQUIPMENT IDENTIFICATION This Operating Manual usually applies to just the underlined The product identification number is printed on the outer specification or part numbers listed. If none are underlined, shipping carton. -
Page 10: General Information
This product will perform as per the information contained herein when installed, operated, maintained and repaired in The CIGWELD Arcmaster XC30 Auto-Darkening Welding Helmet is accordance with the instructions provided. This equipment a sophisticated and modern helmet specifically engineered for must be checked periodically. -
Page 11: Personal Protection
OPERATING MANUAL ARCMASTER XC30 AUTO-DARKENING WELDING HELMET SECTION 4: PERSONAL PROTECTION 4.01 PROTECTING YOURSELF WHILST WELDING WARNING WARNING Prior to welding check operation of the filter lens, The indicated filter lens shade numbers are if the lens does not darken DO NOT COMMENCE minimum. - Page 12 ARCMASTER XC30 AUTO-DARKENING WELDING HELMET OPERATING MANUAL RECOMMENDED PROTECTIVE FILTERS FORELECTRIC WELDING Description of Process Approximate Range of Welding Minimum Shade Current in Amps Number of Filter(s) Air - Arc Gouging Less than or equal to 400 Less than or equal to 300 300 to 400 Flux-cored Arc Welding (FCAW) - with or without shielding gas...
- Page 13 OPERATING MANUAL ARCMASTER XC30 AUTO-DARKENING WELDING HELMET CIGWELD.COM.AU...
-
Page 14: Specifications
ARCMASTER XC30 AUTO-DARKENING WELDING HELMET OPERATING MANUAL SECTION 5: SPECIFICATIONS 5.01 ARCMASTER HELMET & LENS NOTE 1 SPECIFICATIONS Due to variations that can occur in manufactured products, claimed performance, voltages, ratings, all capacities, measurements, dimensions and Description weights quoted are approximate only. Achievable Auto-Darkening Filter capacities and ratings in use and operation will Lens - Ultra View True... -
Page 15: Harness Adjustment
OPERATING MANUAL ARCMASTER XC30 AUTO-DARKENING WELDING HELMET SECTION 6: HARNESS ADJUSTMENT Prior to use, the Welding Helmet must be adjusted for maximum stud out of the hole in the band. Slide the two portions of the comfort and protection. The Helmet should be adjusted such band to a greater or less width as required and push the locking that it is effectively positioned over the eyes and face to ensure stud through the nearest hole. -
Page 16: Installation Of
ARCMASTER XC30 AUTO-DARKENING WELDING HELMET OPERATING MANUAL SECTION 7: INSTALLATION OF MAGNIFICATION LENS (OPTIONAL) CIGWELD magnification lenses magnify the work area substantially to assist the welder in maintaining the high standard required. WARNING Before installing the magnification lens, ensure that the rear cover lens is in place. Magnification Lens Frame Installing Magnification Lens Magnification lens frame shown on left without... - Page 17 OPERATING MANUAL ARCMASTER XC30 AUTO-DARKENING WELDING HELMET Magnification Lens installed Removing Magnification Lens Once the lens is installed it should sit firmly in place as To remove the magnification lens slide the magnification shown in the picture on the left. lens from the bottom edge in an upwards motion until the magnification lens becomes free from the magnification lens frame.
-
Page 18: Changing Of Front And Rear Cover Lenses
ARCMASTER XC30 AUTO-DARKENING WELDING HELMET OPERATING MANUAL SECTION 8: CHANGING OF FRONT AND REAR COVER LENSES If any of the Cover Lenses are broken, plainly worn, distorted or contaminated they should be replaced immediately with a genuine CIGWELD replacement part. REPLACING FRONT COVER LENS REPLACING REAR COVER LENS To replace the front cover lens unclip the auto-darkening filter... -
Page 19: Arcmaster Xc20 Auto- Darkening Filter Lens Controls
OPERATING MANUAL ARCMASTER XC30 AUTO-DARKENING WELDING HELMET SECTION 9: ARCMASTER XC30 AUTO-DARKENING FILTER LENS CONTROLS For your protection and maximum efficiency of your product, please study this information carefully before use. Figure 9-1 Welding/Grinding Mode Variable Shade Control The Welding/Grinding mode switch is used to change The Variable Shade Control is used to adjust the shade level between 9-13. -
Page 20: Batteries And Battery Compartment
ARCMASTER XC30 AUTO-DARKENING WELDING HELMET OPERATING MANUAL SECTION 10: BATTERIES AND BATTERY COMPARTMENT BATTERY COMPARTMENT To replace batteries remove the lithium batteries from the The battery life is extended when the welding helmet is exposed control/battery housing on each side. This can be done by to UV light from sunlight or welding. -
Page 21: Spare Parts
OPERATING MANUAL ARCMASTER XC30 AUTO-DARKENING WELDING HELMET SECTION 11: SPARE PARTS WARNING CIGWELD cannot be held responsible for the continuing performance of this Welding Helmet if non-genuine spare parts are used. Figure 11-2 Exploded View of ArcMaster Auto-Darkening Welding Helmet SPARE PARTS –... -
Page 22: Basic Troubleshooting
ARCMASTER XC30 AUTO-DARKENING WELDING HELMET OPERATING MANUAL SECTION 12: BASIC TROUBLESHOOTING FAULT CAUSE REMEDY 1. Irregular darkening dimming. A. Headband has been set unevenly and A. Reset the headband to reduce the there is an uneven distance from the difference to the filter eyes to the filter lens. ... -
Page 23: Notes
OPERATING MANUAL ARCMASTER XC30 AUTO-DARKENING WELDING HELMET SECTION 13: NOTES CIGWELD.COM.AU...
