Summary of Contents for Bells Of Steel Sisyphean Stepper
- Page 1 SISYPHEAN STEPPER MANUAL STAIR CLIMBER SKU: MAN-CLIMBER INSTALLATION GUIDE BELLSOFSTEEL Stuck? Scan the QR code for the assembly video www.bellsofsteel.com | www.bellsofsteel.us | Telephone: 1-888-718-7997...
- Page 2 STRENGTH, ONE BOLT AT A TIME. Welcome to Bells of Steel, you’ve made an excellent choice. First off I want to say thank you for supporting my I’ve done my best to keep the setup of your new gear small business.
- Page 3 A GUIDE TO SAFETY We know you are excited to use your new Bells of Steel gear, but please read through this Guide to Safety to ensure you do not hurt yourself or others while exercising. It is your responsibility to ensure that all users of the equipment are informed of all warnings and instructions in this manual.
-
Page 4: Safety Precautions
SAFETY PRECAUTIONS Setup • Ensure the Sisyphean Stepper - Manual Stair Climber is stable, with all four feet securely placed on the ground. Maintain a safety clearance of 2000mm x 1000mm (79 inches × 39 inches) at the machine’s entrance. - Page 5 Instructions for Use: Stand on the Sisyphean Stepper - Manual Stair Climber and grasp the red handle to start the machine. Releasing the red handle will stop the machine immediately. Adjust resistance using the red magnetic adjustment lever on the right handrail: •...
-
Page 6: Bill Of Materials
Sisyphean Stepper-0400 Left Handrail Sisyphean Stepper-5600 Left Handle Sisyphean Stepper-5700 Right Handle Sisyphean Stepper-3700 Bracket Sisyphean Stepper-4700 Brake Band with Micro Adjustment Assembly M5*30 Round Head Hexagon Socket Bolt M10*20 Flat Countersunk Head Hexagon Socket Bolt Sisyphean Stepper-3900 Handle Adjustment Assembly... - Page 7 Detailed Assembly Steps: 1. First, place the machine in the appropriate area where it will be used. 2. Insert No. 11 and No. 12 sequentially onto the main frame fixing plate, and thread the brake band from No. 12 into the main frame opening.
- Page 8 1. Take out No. 13, No. 14, and No. 15. Install No. 15 onto No. 13 and No. 14 as shown above. • Secure them with bolts (No. 7 and No. 8 washers) using a 6mm L-shaped hex key wrench, then insert them into No.
- Page 9 1. First, install No. 19 into the opening above both handrails. • Secure it with bolts (No. 20, No. 26, and No. 27 copper bushings and washers) using a 17-19 open-end wrench (repeat for both sides). 2. After securing No. 19, coordinate No. 22 and No. 23 with the brake band. •...
-
Page 10: Maintenance
Maintenance Daily Inspection: • Inspect the frame for rust, bubbling, or paint chips during cleaning. Salt in perspiration can damage unpainted surfaces. • Check the transmission parts and tighten or replace any loose components. Testing: • Test the gear adjustment after maintenance to ensure proper speed control. Out-of-Service Marking: •... - Page 11 YOU’RE FINISHED! WANT TO LEARN MORE ABOUT THE MANUAL STAIR CLIMBER? CHECK OUT THE OVERVIEW VIDEO: VISIT OUR SHOWROOMS Calgary - HQ Toronto - Showroom Indianapolis - Showroom Corporate Headquarters 7880 66 St SE, Calgary, AB, Canada U.S.A. Headquarters 5925 W 71st St, Indianapolis, IN, U.S.A. Toronto Store 39 Haist Ave # 2, Woodbridge, ON, Canada support@bellsofsteel.com | 1-888-718-7997...
