HIP THRUST MACHINE SKU: HPT2-MA ASSEMBLY INSTRUCTIONS BELLSOFSTEEL Stuck? Scan the QR code for the assembly video www.bellsofsteel.com | www.bellsofsteel.us | Telephone: 1-888-718-7997...
Page 2
STRENGTH, ONE BOLT AT A TIME. Welcome to Bells of Steel, you’ve made an excellent choice. I’ve done my best to keep the setup of your new gear First off I want to say thank you for supporting my small business.
Page 3
A GUIDE TO SAFETY We know you are excited to use your new Bells of Steel gear, but please read through this Guide to Safety to ensure you do not hurt yourself or others while exercising. It is your responsibility to ensure that all users of the equipment are informed of all warnings and instructions in this manual.
PARTS LIST M10 x 80mm bolt M10 x 90mm bolt M10 nut, M10 Washer M10 nut, M10 Washer 10 x 80 10 x 90 M10 x 80mm bolt M10 x 85mm bolt M10 nut, M10 Washer M10 nut, M10 Washer 10 x 80 10 x 85 M10 x 25mm bolt...
Page 5
PARTS LIST Assemble base support. Fix using M10x Link base supports. Fix using 85mm bolt, M10 washer and M10 nut (3). M10x 20mm bolt, M10 washer (6). Attach upright support. Fix from bottom using M10x 80mm bolt, M10 washer and M10 nut (1).
Page 6
PARTS LIST Assemble front. Fix using the indicated M10x 20mm bolt sets (1) and (3). M10 x 85 bolt M10 Nut, M10 washer M10 x 80 bolt M10 Nut, M10 washer Assemble rear. Fix using M10x 90mm bolt, M10 washer and M10 nut (2). PAGE 6 OF 9...
Page 7
PARTS LIST Mount the long pin shaft (15) and short pin shaft (16). Add (13 and 14) together and fix with M10x16 bolt and M10 washer (12). M10x16mm Install other parts as shown. Fix upper part with M10 x 30mm screw and M10 washer (8). Fix the lower parts with M10 x 20 bolt and M10 washer (6).
Page 8
PARTS LIST Mount pad. Fix top with M10 x 25mm bolt, M10 nut and M10 Washer (9). Fix pad with M10 x 65mm bolt and M10 Washer (7), and M10 x 20mm bolt and M10 Washer (11). M10x16mm M10x65mm M10x20mm Snap and fasten the pad.
Page 9
YOU’RE FINISHED! WANT TO LEARN MORE ABOUT THE HIP THRUST MACHINE? CHECK OUT THE OVERVIEW VIDEO: VISIT OUR SHOWROOMS Calgary - HQ Toronto - Showroom Indianapolis - Showroom Corporate Headquarters 7880 66 St SE, Calgary, AB, Canada U.S.A. Headquarters 5925 W 71st St, Indianapolis, IN, U.S.A. Toronto Store 39 Haist Ave # 2, Woodbridge, ON, Canada support@bellsofsteel.com | 1-888-718-7997...
