MANTICORE
ASSEMBLY GUIDE
ASSEMBLY INSTRUCTIONS
BELLSOFSTEEL
www.bellsofsteel.com | www.bellsofsteel.us | Telephone: 1-888-718-7997

Advertisement

loading
Need help?

Need help?

Do you have a question about the MANTICORE COLLEGIATE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bells Of Steel MANTICORE COLLEGIATE

Summary of Contents for Bells Of Steel MANTICORE COLLEGIATE

  • Page 1 MANTICORE ASSEMBLY GUIDE ASSEMBLY INSTRUCTIONS BELLSOFSTEEL www.bellsofsteel.com | www.bellsofsteel.us | Telephone: 1-888-718-7997...
  • Page 2 STRENGTH, ONE BOLT AT A TIME. Welcome to Bells of Steel, you’ve made an excellent choice. I’ve done my best to keep the setup of your new gear First off I want to say thank you for supporting my small business.
  • Page 3 A GUIDE TO SAFETY We know you are excited to use your new Bells of Steel gear, but please read through this Guide to Safety to ensure you do not hurt yourself or others while exercising. It is your responsibility to ensure that all users of the equipment are informed of all warnings and instructions in this manual.
  • Page 4 Choose the type of Manticore rack you have from the diagrams below. Refer to the pages indicated for the assembly instruction. A. MANTICORE B. MANTICORE D. MANTICORE COLLEGIATE 4 POST 6 POST (page 7-9) (page 10-13) (page 14-16) D. MANTICORE E.
  • Page 5 Choose the type of Manticore rack you have from the diagrams below. Refer to the pages indicated for the assembly instruction. G. MANTICORE H. MANTICORE HALF RACK with POWER RACK with 54” FLAT FOOT 54” FLAT FOOT (page 25-27) (page 28-30) J.

  • Page 6: Assembly Tips

    Assembly Tips Choose an appropriate location: Ensure you have sufficient space around the rack before starting assembly. Assemble the rack in the location where it will be used to avoid unnecessary movement after setup. Two-person assembly recommended: Due to the size and weight of the components, having two people for assembly is strongly recommended to ensure safety and ease of installation.
  • Page 7 A. MANTICORE COLLEGIATE TOOLS REQUIRED PARTS LIST 36mm M24x120mm bolt, M24 washer, Wrench M24 spring washer, M24 nut x24 M24x110mm bolt, M24 washer, M24 spring washer, M24 nut x4 M12x75mm included Anchor bolt x10 PAGE 7 OF 40...
  • Page 8 A. ASSEMBLY Assemble the uprights. Fix with M24x120mm bolt, M24 washer, M24 spring washer, M24 nut (1). Make 2. Attach rear crossmember and front support. Fix with M24x120mm bolt, M24 washer, M24 spring washer, M24 nut (1). PAGE 8 OF 40...
  • Page 9 A. ASSEMBLY Attach logo plate. Fix with M24x110mm bolt, M24 washer, M24 spring washer, M24 nut (2). Attach side crossmembers. Fix with M24x120mm bolt, M24 washer, M24 spring washer, M24 nut (1). If anchoring to the ground install anchor bolts. Level uprights and crossmembers before fully tigthening.

  • Page 10: Parts List

    B. MANTICORE 4 POST TOOLS REQUIRED PARTS LIST 36mm M24x120mm bolt, M24 washer, Wrench M24 spring washer, M24 nut x24 M24x110mm bolt, M24 washer, M24 spring washer, M24 nut x4 M12x75mm included Anchor bolt x8 PAGE 10 OF 40...
  • Page 11 B. ASSEMBLY Assemble the uprights. Fix with M24x120mm bolt, M24 washer, M24 spring washer, M24 nut (1). Make 2. Attach rear crossmember and front support. Fix with M24x120mm bolt, M24 washer, M24 spring washer, M24 nut (1). PAGE 11 OF 40...
  • Page 12 B. ASSEMBLY Attach logo plate. Fix with M24x110mm bolt, M24 washer, M24 spring washer, M24 nut (2). Attach side crossmembers. Fix with M24x120mm bolt, M24 washer, M24 spring washer, M24 nut (1). ③ PAGE 12 OF 40...
  • Page 13 B. ASSEMBLY Attach front support. Fix with M24x120mm bolt, M24 washer, M24 spring washer, M24 nut (1). If anchoring to the ground install anchor bolts. Level uprights and crossmembers before fully tigthening. PAGE 13 OF 40...
  • Page 14 C. MANTICORE 6 POST TOOLS REQUIRED PARTS LIST 36mm M24x120mm bolt, M24 washer, Wrench M24 spring washer, M24 nut x24 M24x110mm bolt, M24 washer, M24 spring washer, M24 nut x4 Not included M24x130mm bolt, M24 washer, M12x75mm M24 spring washer, M24 nut x8 Anchor bolt x12 PAGE 14 OF 40...
  • Page 15 C. ASSEMBLY Assemble the uprights and crossmembers. Fix with M24x130mm bolt (3), M24x120 (1) M24 washer, M24 spring washer, M24 nut. M24x120 M24x130 Make 2. Connect the uprights using crossmembers and front support. Fix with M24x120, M24 washer, M24 spring washer, M24 nut (1). PAGE 15 OF 40...
  • Page 16 C. ASSEMBLY Attach middle support. Fix with M24x110mm bolt, M24 washer, M24 spring washer, M24 nut (2). If anchoring to the ground install anchor bolts. Level uprights and crossmembers before fully tigthening. PAGE 16 OF 40...
  • Page 17 D. MANTICORE FOLDING HALF RACK TOOLS REQUIRED PARTS LIST 36mm M24x140mm bolt, M24 washer, Wrench M24 spring washer, M24 nut x4 M24x120mm bolt, M24 washer, M24 spring washer, M24 nut x8 Not included 25 magnet pin x6 M10x75mm Anchor bolt x8 PAGE 17 OF 40...
  • Page 18 D. ASSEMBLY Assemble the uprights and crossmembers. Fix with M24x120mm bolt (1), M24x120 (2) M24 washer, M24 spring washer, M24 nut. M24x140 M24x120 Connect the uprights using front support. Fix with 25 magnet pin. PAGE 18 OF 40...
  • Page 19 D. ASSEMBLY Install bracket so cross member retains the top clearance to prevent friction. If anchoring to the wall install anchor bolts. Level uprights and crossmembers before fully tigthening. PAGE 19 OF 40...
  • Page 20 E. MANTICORE FOLDING 4 POST TOOLS REQUIRED PARTS LIST 36mm M24x140mm bolt, M24 washer, Wrench M24 spring washer, M24 nut x4 M24x130mm bolt, M24 washer, M24 spring washer, M24 nut x8 Not included M24x120mm bolt, M24 washer, M10x75mm M24 spring washer, M24 nut x8 Anchor bolt x8 25 magnet pin x6 PAGE 20 OF 40...
  • Page 21 E. ASSEMBLY Assemble the uprights and crossmembers. Fix with M24x130mm bolt (2), M24x120 (3) M24 washer, M24 spring washer, M24 nut. M24x130 M24x120 Attach front support. Fix with 25 magnet pin (5). PAGE 21 OF 40...
  • Page 22 E. ASSEMBLY Attach rear end. Fix with M24x140mm bolt (1), M24 washer, M24 spring washer, M24 nut. If anchoring to the wall install anchor bolts. Install bracket so cross member retains the top clearance to prevent friction. PAGE 22 OF 40...
  • Page 23 F. MANTICORE SQUAT STAND with 54” FLAT FOOT TOOLS REQUIRED PARTS LIST 36mm M24x120mm bolt, M24 washer, M24 spring washer, M24 nut x16 Wrench Not included M12x75mm Anchor bolt x4a PAGE 23 OF 40...
  • Page 24 F. ASSEMBLY Assemble the base with crossmember. Fix with M24x120mm bolt, M24 washer, M24 spring washer, M24 nut(1). M24x120 Attach front support. Fix with M24x120mm bolt, M24 washer, M24 spring washer, M24 nut (1). If anchoring to the ground install anchor bolts. PAGE 24 OF 40...
  • Page 25 G. MANTICORE HALF RACK with 54” FLAT FOOT TOOLS REQUIRED PARTS LIST 36mm M24x120mm bolt, M24 washer, M24 spring washer, M24 nut x32 Wrench Not included M12x75mm Anchor bolt x4 PAGE 25 OF 40...
  • Page 26 G. ASSEMBLY Assemble the base. Fix with M24x120mm bolt, M24 washer, M24 spring washer and M24 nut (1). Attach base plates at first, then install the uprights and center support. Fix one side then the other side using M24x120mm bolt, M24 washer, M24 spring washer and M24 nut (1).
  • Page 27 G. ASSEMBLY Attach side crossmembers. Fix with M24x120mm bolt, M24 washer, M24 spring washer and M24 nut (1). If anchoring to the ground install anchor bolts. PAGE 27 OF 40...
  • Page 28 H. MANTICORE POWER RACK with 54” FLAT FOOT TOOLS REQUIRED PARTS LIST 36mm M24x120mm bolt, M24 washer, M24 spring washer, M24 nut x32 Wrench Not included M12x75mm Anchor bolt x4 PAGE 28 OF 40...
  • Page 29 H. ASSEMBLY Assemble the uprights. Fix with Fix base plates first to the base, M24x120mm bolt, M24 washer, then uprights. Fix with M24x120mm M24 spring washer and M24 nut (1). bolt, M24 washer, M24 spring washer and M24 nut (1). Make 2 Make 2 30”...
  • Page 30 H. ASSEMBLY Attach rear crossmember and front support. Fix with M24x120mm bolt, M24 washer, M24 spring washer and M24 nut (1). If anchoring to the ground install anchor bolts. PAGE 30 OF 40...
  • Page 31 I. MANTICORE SQUAT STAND WITH 63” FLAT FOOT TOOLS REQUIRED PARTS LIST 36mm M24x120mm bolt, M24 washer, M24 spring washer, M24 nut x16 Wrench Not included M12x75mm Anchor bolt x4 PAGE 31 OF 40...
  • Page 32 I. ASSEMBLY Assemble base with rear crossmember. Attach lower base support at first, Fix with M24x120mm bolt, then add uprights and front support. M24 washer, M24 spring Fix with M24x120mm bolt, M24 washer, washer, M24 nut (1). M24 spring washer, M24 nut (1). If anchoring to the ground install anchor bolts.
  • Page 33 J. MANTICORE HALF RACK WITH 63” FLAT FOOT TOOLS REQUIRED PARTS LIST 36mm M24x120mm bolt, M24 washer, Wrench M24 spring washer, M24 nut x32 Not included M12x75mm Anchor bolt x4 PAGE 33 OF 40...
  • Page 34 J. ASSEMBLY Assemble base with rear crossmember. Fix with M24x120mm bolt, M24 washer, M24 spring washer, M24 nut (1). Attach lower base support at first, then add uprights and front support. Fix with M24x120mm bolt, M24 washer, M24 spring washer, M24 nut (1). 24”...
  • Page 35 J. ASSEMBLY Attach side crossmember. Fix with M24x120mm bolt, M24 washer, M24 spring washer, M24 nut (1). If anchoring to the ground install anchor bolts. Level uprights and crossmembers before fully tigthening. PAGE 35 OF 40...
  • Page 36 K. MANTICORE POWER RACK WITH 63” FLAT FOOT TOOLS REQUIRED PARTS LIST 36mm M24x120mm bolt, M24 washer, Wrench M24 spring washer, M24 nut x32 Not included M12x75mm Anchor bolt x4 PAGE 36 OF 40...
  • Page 37 K. ASSEMBLY Assemble base with crossmember. Refer to next page for depth option. Fix with M24x120mm bolt, M24 washer, M24 spring washer, M24 nut (1). Make 2. Attach the base. Install lower base support at first, then add uprights. Fix with M24x120mm bolt, M24 washer, M24 spring washer, M24 nut (1).
  • Page 38 K. ASSEMBLY 43” DEPTH OPTIONS 24” DEPTH OPTIONS 30” DEPTH OPTIONS PAGE 38 OF 40...
  • Page 39 K. ASSEMBLY Attach side crossmember. Fix with M24x120mm bolt, M24 washer, M24 spring washer, M24 nut (1). If anchoring to the ground install anchor bolts. Level uprights and crossmembers before fully tigthening. PAGE 39 OF 40...
  • Page 40 YOU’RE FINISHED! WANT TO LEARN MORE ABOUT THE MANTICORE RACK? CHECK OUT THE OVERVIEW VIDEO: VISIT OUR SHOWROOMS Calgary - HQ Toronto - Showroom Indianapolis - Showroom Corporate Headquarters 7880 66 St SE, Calgary, AB, Canada U.S.A. Headquarters 5925 W 71st St, Indianapolis, IN, U.S.A. Toronto Store 39 Haist Ave # 2, Woodbridge, ON, Canada support@bellsofsteel.com | 1-888-718-7997 PAGE 40 OF 40...
