- Page 1 LEG PRESS / HACK SQUAT SKU: LPHSQ-MA ASSEMBLY INSTRUCTIONS BELLSOFSTEEL Stuck? Scan the QR code for the assembly video www.bellsofsteel.com | www.bellsofsteel.us | Telephone: 1-888-718-7997...
- Page 2 STRENGTH, ONE BOLT AT A TIME. Welcome to Bells of Steel, you’ve made an excellent choice. I’ve done my best to keep the setup of your new gear First off I want to say thank you for supporting my small business.
- Page 3 A GUIDE TO SAFETY We know you are excited to use your new Bells of Steel gear, but please read through this Guide to Safety to ensure you do not hurt yourself or others while exercising. It is your responsibility to ensure that all users of the equipment are informed of all warnings and instructions in this manual.
-
Page 4: Parts List
PARTS LIST • Hardware Package 12x95 12x90 12x160 M12 x 95 bolt M12 x 90 bolt M12 x 160 bolt 10x85 12x85 12x75 12x70 M12 x 85 bolt M12 x 75 bolt M12 x 70 bolt M10 x 85 bolt 10x20 10x70 10x60... - Page 5 PARTS LIST • Preassembled 7050 foot M4 x 8 cover 20 x 6 magnetic 12-19-24 podwer countersunk bolt bearing x8 2550 5070 tube plug tube plug tube plug 5070 foot 50 foot cover cover x1 5045 tube plug tube plug tube plug handle tube bushing...
- Page 6 PARTS LIST PAGE 6 OF 16...
- Page 7 PARTS LIST PAGE 7 OF 16...
-
Page 8: Tools Required
PARTS LIST 67 x1 68 x2 69 x4 70 x2 TOOLS REQUIRED (included) Allen Keys 17mm 15mm Box wrench (X2) Box wrench (X1) You can use an impact/ 19mm Box wrench (X2) socket wrench but not required. PAGE 8 OF 16... - Page 9 ASSEMBLY Pro tips: For easier assembly, group the hardware together for each step. Group the bolts, washers and nuts according to sizes. Attach (44) to (42) using M12 x 95 bolt (2), M12 washers (19) and M12 nut (16). Both sides. Attach (48) to base you assembled in step 1 and fix using M12 x 75 bolt (5), M12 washers (19) and M12 nut (16).
- Page 10 ASSEMBLY Attach (46) and (47) on both sides. Fix the top with M10 x 20 bolt (10), M10 washers (20). Add (45) at the bottom before fixing it to the base. Secure with M12 x 75 bolt (5), M12 washers (19) and M12 nut (16).
- Page 11 ASSEMBLY Fix the base with M12 x 160 bolt (2), M12 washers (19) and M12 nut (16). Install (70) and fix the M8 x 100 bolt (11) and M8 washer (21). Attach (51) and fix the M10 x 85 bolt (7), M10 washers (20) and M10 nut (17).
- Page 12 ASSEMBLY Install one end of (65), then slide in (62/63) - install the other (65) to lock it. Fix with M10 x 70 bolt (8), M10 washers (20) and M10 nut (17). Move and adjust (69) to install (52). Fix it with M8 x 16 semicircle head bolt (13).
- Page 13 ASSEMBLY Slide (59) to (52) and lock it with (14). Assemble (54), (40) and (41) and Install (60) and (61) and fix with M10 x fix it to the base with M12 x 70 70 bolt (8), M10 washers (20) and M10 bolt (6), M12 washers (19) and nut (17).
- Page 14 ASSEMBLY Attach (55) fix with M10 x 60 bolt (9), M10 washers (20) and M10 nut (17). Assemble (56) and (58), fix with Install (56), fix with M12 x 85 M12 x 85 bolt (4), M12 washers bolt (4), M12 washers (19) and (19) and M12 nut (16).
- Page 15 ASSEMBLY Attach (64) with (40). Install (68) Attach (66) fix with 12 x 12 and fix with M8x45 bolt (12) and shoulder bolt (15). M8 washer (21). Attach (67) fix with M10x20 bolt (10) and M10 washer (20). PAGE 15 OF 16...
- Page 16 YOU’RE FINISHED! WANT TO LEARN MORE ABOUT THE LEG PRESS / HACK SQUAT? CHECK OUT THE OVERVIEW VIDEO: VISIT OUR SHOWROOMS Calgary - HQ Toronto - Showroom Indianapolis - Showroom Corporate Headquarters 7880 66 St SE, Calgary, AB, Canada U.S.A. Headquarters 5925 W 71st St, Indianapolis, IN, U.S.A. Toronto Store 39 Haist Ave # 2, Woodbridge, ON, Canada support@bellsofsteel.com | 1-888-718-7997 PAGE 16 OF 16...
