BLINDS2GO SmartView Electric Pleated Blinds Installation Manual page 2

If you upgraded to a Click2Go™ rail
The brackets will be attached to the Click2Go™ rail for you already; you'll simply need to fit the rail into the recess, then fit the blind
Hold the Click2Go™ rail up against the top of the recess, then push the lever firmly upwards until the rail snaps into place. If the rail is
Top Tip
Make sure that the lever is loose and hanging down from the rail, and that the grip pad is flush with the end of the rail, before
trying to place the rail into the recess. If the lever is pushed in and the pad extended, the rail will be too tight to fit in the recess.
At the end of the rail opposite to the lever there is an adjustment block that allows you to fine-tune the fitting of the rail. Use a
flat-head screwdriver to twist the small red plugs in toward the centre of the rail. Slide the block out of the rail by a few millimetres,
then twist the red plugs back into thaeir original position to fix the block in place. Make small adjustments only, repeating as
Friction plates are provided with the fittings, but these are
only necessary if you find that the Click2Go™ rail slips against
the wall of your recess once the blind is fitted.
Page 2 of 4
Cordless / SmartView Electric Pleated Blinds
into the pre-attached brackets.
not quite tight enough then this can be easily adjusted:
OPTIONAL
necessary for a tight fit.
OPTIONAL
Installation Guide
To fit them, peel the covers from the sticky pads on the back,
then stick one to each end of the Click2Go™ rail, as shown.
