BLINDS2GO MaxShade Blackout Pleated Blinds Installation Manual

Download this manual

Attach the side channels

Blind end cap

Blind

Tension cord

Bottom bar

Side channels

When you first unpack the blind you'll find that the side channels are packed separately and that the blind and its bottom bar are

connected by the tension cords, with the cords wrapped around the bottom bar. Put the channels to one side, then unwrap the cord

Slot the side channels onto the caps at either end of the blind, so that the blind runs down the insides of the channels.

Page 1 of 4

and spread out the blind and bottom bar.

Top Tip

Ensure that the cords hanging from the blind's end caps also runs down the insides of the

channels and are not trapped or caught when you slot the channels in place.

Installation Guide

MaxShade Blackout Pleated Blinds

Need help?

Do you have a question about the MaxShade Blackout Pleated Blinds and is the answer not in the manual?

Page 1 Installation Guide MaxShade Blackout Pleated Blinds Attach the side channels Blind end cap Blind Tension cord Bottom bar Side channels When you first unpack the blind you’ll find that the side channels are packed separately and that the blind and its bottom bar are connected by the tension cords, with the cords wrapped around the bottom bar.
Page 2 Installation Guide MaxShade Blackout Pleated Blinds Next slot the bottom bar into the bottoms of the side channels in the same way as you did at the top. Set the cord tension Lay the blind down on its back, on a flat surface. Inside the bottom bar are two clips, to which the ends of the tension cords are tied.
Page 3 Installation Guide MaxShade Blackout Pleated Blinds Install the blind Raise the blind into the window recess. Position it so that it’s close to the front of the recess, with a gap of at least 50mm between the back of the blind and the window.
Page 4 Installation Guide MaxShade Blackout Pleated Blinds Holding the blind in position, use a pencil to mark through the pre-drilled holes in the side channels, onto the walls of the recess. Take the blind down from the window. Drill holes and insert Rawl plugs where you made your pencil marks.
