Installation Guide

Cordless / SmartView Electric Pleated Blinds

If you upgraded to a Click2Go rail, please skip to page 2.

Locating the brackets

Ensure that the back of the bracket sits clear of any protruding items such as window handles or vents. This will allow the blind to

hang correctly once installed.

5cm

The position that you place the outermost brackets must be 5cm away from the end of the rail. Any additional brackets (supplied for

wider blinds) can then be evenly distributed across the window space. Use a pencil to mark the window area where the brackets will

be positioned.

Fitting the brackets

The brackets offer two methods of installation:

Top-Fixing

Face-Fixing

Use the single hole in the top of the bracket to fix to

Use two screws through the back plate to mount

the lintel (the 'ceiling' of the recess).

onto a facing surface (a wall or window frame)

Page 1 of 4

Need help?

Do you have a question about the SmartView Electric Pleated Blinds and is the answer not in the manual?

Page 1 Installation Guide Cordless / SmartView Electric Pleated Blinds If you upgraded to a Click2Go rail, please skip to page 2. Locating the brackets Ensure that the back of the bracket sits clear of any protruding items such as window handles or vents. This will allow the blind to hang correctly once installed.
Page 2 Installation Guide Cordless / SmartView Electric Pleated Blinds If you upgraded to a Click2Go™ rail The brackets will be attached to the Click2Go™ rail for you already; you’ll simply need to fit the rail into the recess, then fit the blind into the pre-attached brackets.
Page 3 Installation Guide Cordless / SmartView Electric Pleated Blinds Fitting the blind Model shown is a Cordless Pleated Blind with SmartView Electric upgrade Situate the front lip of the headrail into Push the back of the headrail upwards the front hook of the bracket.
Page 4 Installation Guide Cordless / SmartView Electric Pleated Blinds Additional Information SmartView Electric Blinds We recommend plugging in the motor to allow it to fully On the front of the swing tag that comes with your blind, you’ll charge before use. Plug the charging cable (included) into the find a handy QR code you can scan with your phone.
