Remove the blind from the brackets
Push the control end of the blind up to disengage the locking
peg on the end of the mechanism.
Fit the motor
Page 1 of 2
Lay the blind down and gently pull the sidewinder mechanism out of the
roller tube. You won't need this mechanism after you've installed the
motor, but we'd recommend keeping it safe somewhere for future use,
just in case.
Unpack the roller motor - you'll find a label containing a QR code secured
to the motor with an elastic band. Remove the label and set it aside for
later.
Top-Tip:
If you are fitting multiple motors, keep the label from each motor
with the blind you're fitting the motor into. The QR code on the
label is unique to the motor, so you'll want to keep track of which is
which.
Slide the roller motor into the roller tube until it's fully inserted.
Installation Guide
SmartView Roller Blind Retrofit
Then, push the blind toward the opposite end to release the
control end from its bracket entirely.
Advertisement
Related Manuals for BLINDS2GO SmartView Roller Blind Retrofit
Summary of Contents for BLINDS2GO SmartView Roller Blind Retrofit
- Page 1 Installation Guide SmartView Roller Blind Retrofit Remove the blind from the brackets Push the control end of the blind up to disengage the locking Then, push the blind toward the opposite end to release the peg on the end of the mechanism. control end from its bracket entirely.
- Page 2 Installation Guide SmartView Roller Blind Retrofit Reinstall the blind and charge the motor Locate the depression end (the opposite end to the controls) of the blind into the circular hole in the corresponding bracket. Lift the control end of the blind and slot the locking pegs into the corresponding slots on the bracket. Once your blind is installed we recommend plugging in the motor to allow it to fully charge before use.
