Attach the side channels
Slot the side channels onto the caps at either end of the blind, so that the blind runs down the insides of the channels.
Page 1 of 3
Left channel
Slot the rubber caps onto the bottoms of the side channels.
Top Tip
Ensure that the locking lever arm is loose, and the grip pad at the end of the headrail is flush
with the rail, before moving on to the next step.
Installation Guide
Click2Shade Blackout Pleated Blinds
Right channel

Advertisement

loading
Need help?

Need help?

Do you have a question about the Click2Shade Blackout Pleated Blinds and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for BLINDS2GO Click2Shade Blackout Pleated Blinds

  • Page 1 Installation Guide Click2Shade Blackout Pleated Blinds Attach the side channels Slot the side channels onto the caps at either end of the blind, so that the blind runs down the insides of the channels. Left channel Right channel Slot the rubber caps onto the bottoms of the side channels.
  • Page 2 Installation Guide Click2Shade Blackout Pleated Blinds Fit the blind into the recess Raise the blind into the window recess. Leave a space of around 10mm between the front of the blind and the edge of the recess, so that there’s space to fit the pelmet on the front later.
  • Page 3 Installation Guide Click2Shade Blackout Pleated Blinds Fit the bottom bar and pelmet Insert the bottom bar into one of the side channels, with the bar angled up at the other end. Top Tip Again, ensure that the locking arm is raised and loose when you insert the bottom bar into the side channels.
  • Page 4 Installation Guide Click2Shade Blackout Pleated Blinds Using the light-sealing strip (optional) If you find that there are light gaps around the edges of the blind once it’s fitted, and you’ve checked that it’s level, then usually this is because the recess is uneven in some way. To help with this, light-sealing rubber seal is provided with your order. A double-length of sealing strip is provided on a roll with its two halves joined together.
