• Menu navigation and structure:

Menu navigation:
I
Fig. 10
Note: When the tempering or pump functions are active, the menu is locked� On the display, the active menu option is high-
lighted in yellow� The active status of a menu item is marked with a check (√)�
Menu navigation:  Press the "Menu" button (J), "OK/Pump" button (G) and "Pump (+)" button (H) or "Pump (-)" button (I)
 Press the "Back" button (K) or the "Menu" button (J)�
A
0.00 Menu
int °C
ext °C Safe Temp °C
Back
int 5.00 1000
set °C Pump rpm
Note: If you press the "Menu" button (J), the system skips directly back to the working screen�
If you press the "Back" button (K), the system skips back to the previous screen�
Fig. 11
Press the "Menu" key (J)�

Select the menu option by pressing the "Pump (+)" button (H) or "Pump (-)"

button (I)�
J
Open the menu item by pressing the "OK/Pump" button (G)�

Press the "Pump (+)" button (H) or "Pump (-)" button (I) to select the desired

K
menu option and edit the values or settings�
Press the the "OK/Pump" button (G) to get into sub menu items to active/inac-

tive to switch settings or to confirm settings ("OK")�
Press the "Back" button (K) to a setting or cancel to return to the previous menu�

Press the "Menu" button (J) to return directly to the working screen�

H G
MENU
Back
TEMPERING
Menu
Tempering > Tempering
Control
Control Control Mode
Limits Control Parameters
Temperature Sensor Fluids
Back
> Tempering > Control
Control Mode
Internal (int)
External (ext)
Back
12
