IKA ICC control Operating Instructions Manual page 8

Fluid (Standard information for IKA fluid):
IKA Operating temperature
Designation
range for open bath
CF�EG28�N10�80�8
CF�EG39�N20�80�16
CF�EG44�N25�80�19
CF�EG48�N30�80�22
UF�Si�N30�150�10LV
HF�Si�20�200�50
HF�Si�20�250�50A
H O (Water) 
2
Customized 1 
Customized 2 
Check the suitability of the fluid according to your application�
Nomenclature for IKA fluid:
CF�EG28�N10�80�8 --
(5) Addition information
(4) Kinematic viscosity (8 mm²/s)
(3) Temperature range (- 10–80 °C)
(2) Chemical composition (Ethylene Glycol 28 %)
(1) Classification (Cooling fluid)
(1) Classification:
HF: Heating Fluid
CF: Cooling Fluid
UF: Universal Fluid
(2) Chemical composition:
Si: Silicone oil
EG: Ethylene Glycol
(3) Temperature range: (Minimum temperature� Maximum temperature)
N: Negative Temperature
(4) Viscosiy:
Viscosiy at 25 °C for Heating Fluid (HF)
Viscosity at -20 °C for Cooling Fluid (CF)
Viscosity at 25 °C for Universal Fluid (UF)
Dynamic viscosity [mPa•s] is a product of kinematic viscosity [mm²/s] and density [kg/m³] of the fluid divided by 1000�
(5) Additional information:
A: Oil Additives
LV: Low Viscosity
 Note: for open bath application!
 Note: Tap water may be unsuitable for operation because the calcium carbonate content may cause calcification�
High purity water (from icon exchangers) and distilled or bi-distilled water are unsuitable for operation due to corrosive
properties of these media� High purity water and distillates are suitable as a medium after adding 0�1 g soda (Na
sodium carbonate) per liter of water�
Note: The limits can be adjusted according to the fluid used�

Operating temperature
range for closed bath
application
(°C)
-10 ��� 80
-20 ... 80
-25 ... 80
-30 ... 80
-30 ... 130
20 ... 200
20 ... 200
5 ... 95
Safety temperature
applications
(°C)
-10 ... 80
-20 ... 80
-25 ... 80
-30 ... 80
-30 ... 150
20 ... 200
20 ... 250
5 ... 95
Flash point
(°C)
90
90
90
90
>170
145 
255 >280
255 >280
-
(°C)
115
115
115
115
-
CO ,
2 3
8
