IKA ICC control Operating Instructions Manual page 10

Check whether the voltage given on the type plate corre-
sponds to the available mains voltage�
The socket used must be earthed
(fitted with earth contact)�
If these conditions have been met, the machine is ready for
operation when the mains plug is plugged in�
If these conditions are not met, safe operation is not guaran-
teed and the machine could be damaged�
Observe the ambient conditions (temperature, humidity,
etc�) listed under "Technical Data"�
After switch on the mains switch (2) at the back of the de-
vice or pressing the power key (A), the screen displays the
device designation and the software version after a beep�
IKA
Circulator
ICC control
Version 1.4.004
Fig. 4
After several seconds, screen display the information of
device�
Information
Internal Max:
Internal Min:
External Max:
External Min:
Fluid:
Fig. 5
Commissioning
95 °C
5 °C
95 °C
5 °C
H O (Water)
2
Then the working screen in standby status appears and the
device is ready for operation�
A
0.00
int °C
ext °C
int 5.00
set °C
Fig. 6
Change the temperature setting with "Temp (+)" button
(E) or "Temp (-)" button (F)�
Change the pump speed setting with "Pump (+)" button
(H) or "Pump (-)" button (I)�
In standby status, activate the heating function by pressing
the "Temp" button (D)� The device start heating function,
meanwhile the pump start to run�
In working status, stop the pump function by pressing the
"OK/Pump" button (G)� The heating function and pump
stops�
In standby status, press the "OK/Pump" button (G) to start
the pump function� The heating function will not be activated�
In running status, press the "Temp" button (D) to stop the
heating function, the pump keep running�
The control elements of the device allow to be locked by
pressing the key button (O), so no accidental changes during
operation are possible (key symbol appears in the display)�
By pressing the key button (O) again, the controls are re-
leased (key symbol disappears from the display)�
Safe Temp °C
1000
Pump rpm
10
