OUTGAS
In the option, the user is allowed to set the outgas speed
in range of 1000 rpm to 3200 rpm and outgas interval
from 10 seconds to 240 seconds�
This function can be used when filling external devices
such as laboratory reactors�
SAFETY
Password:
In the "Password" menu, the menu settings can be
locked by a 3-digit password�
Safe Temp. Confirmation:
This menu can confirm (safety temperature of the station)
at start-up of the set "Safe Temp"� A check mark (√) indi-
cates that the function is activated�
SETTING
Languages:
The "Languages" option allows the user to select the
desired language�
The device can be operated in "Remote" mode via the RS 232
interface (10) or the USB interface (11) connected to a PC and
with the laboratory software Labworldsoft
ware can also be updated with a PC via the USB or RS 232
interface�
Note: Please comply with the system requirements togeth-
er with the operating instructions and help section included
with the software�
USB interface:
The Universal Serial Bus (USB) is a serial bus for connecting
the device to the PC� Equipped with USB devices can be con-
nected to a PC during operation (hot plugging)� Connected
devices and their properties are automatically recognized�
USB device drivers:
First, download the latest driver for IKA devices with USB
interface from:
http://www.ika.com/ika/lws/download/usb-driver.zip.
Install the driver by running the setup file� Then connect the
IKA device through the USB data cable to the PC�
The data communication is via a virtual COM port� Configu-
ration, command syntax and commands of the virtual COM
ports are as described in RS 232 interface�
Note: the USB driver is unnecessary for Windows 10 system�
Don't install it for Windows 10 system!
Display:
The "Display" option allows the user to change the
background color of the working screen�
You can also activate the "Firmware Update Info" screen
in this menu�
Sound:
The "Sound" option allows the user to activate/deacti-
vate the key tone�
Factory Settings:
Select the "Factory settings" option with "OK/Pump"
button� The system requests confirmation to restore the
factory settings� Pressing the "OK" button resets all the
system settings to the original standard values set at dis-
patch from the factory (see "Menu structure")�
Communication:
The "Device name" menu option allows you to edit the de-
vice name�
Information:
The "Information" option offers the user an overview of
the most important system settings of the device�

Interface and output

RS 232 interface:
Configuration
� The device soft- - The functions of the interface connections between the
®
device and the automation system are chosen from the
signals specified in EIA standard RS 232 in accordance
with DIN 66 020 Part 1�
- For the electrical characteristics of the interface and the al-
location of signal status, standard RS 232 applies in accor-
dance with DIN 66 259 Part 1�
- Transmission procedure: asynchronous character transmis-
sion in start-stop mode�
- Type of transmission: full duplex�
- Character format: character representation in accordance
with data format in DIN 66 022 for start-stop mode� 1
start bit; 7 character bits; 1 parity bit (even); 1 stop bit�
- Transmission speed: 9600 bit/s�
- Data flow control: none
- Access procedure: data transfer from the device to the com-
puter takes place only at the computer's request�
Command syntax and format:
The following applies to the command set:
- Commands are generally sent from the computer (Master)
to the device (Slave)�
- The device sends only at the computer's request� Even
fault indications cannot be sent spontaneously from the
device to the computer (automation system)�
- Commands are transmitted in capital letters�
16
