SolaX Power AELIO-P50B200 Installation Manual page 40

• Meter connection diagram
* The meter in the connection
diagram is taken as an
example with DTSU666.
RS485 on DTSU666
2425
A B
RS485
L1
L2
L3
N
Grid
E-BAR
Power connection on DTSU666
6
1 3 4
L1
L2
L3
N
Grid input
• Meter with CT connection diagram
* The meter in the connection
diagram is taken as an example
with DTSU666-CT.
L1
L2
L3
N
Grid
E-BAR
The arrows direction on the CT must point
to the inverter side.
Grid
In Out
Meter 1
Out
7 10
9
In
Output
Out
Meter
In
CT CT-L1
CT-L2
CT-L3
L line
Meter 2
other power
generatation
equipment
Inverter
3 6 9 10
4
1 7 10
37
