Capital
600
Code / Codice
Power consumption
Consumo di energia
Nominal current
Corrente nominale
Power supply
Alimentazione elettrica
Inrush current / Corrente di spunto
Power factor / Fattore di potenza
Electrical class / Classe elettrica
Weight / Peso
Operating temperature
Temperatura di funzionamento
IP rating / Grado IP
IK rating / Grado IK
Aerodynamic surface
Superficie massima esposta al vento
Dimensions / Dimensioni
Griven S.r.l. - Via Bulgaria, 16
46042 Castel Goffredo
Mantova - Italy
User Manual
551090 Rev.5.0
Date: 14/12/2023
Capital 600
AL5020 - AL5022 (PE)
517mm
20.4in
Tel. +39.0376.779483
E-mail: sales@griven.com
Web: www.griven.com
Capital 600 US
AL5024 (US) - AL5025 (
US PE)
2x 256 W(RN), 2x 285 W (W) 2x 240 (MC)
2x 1.6 A (RN), 2x 1.29 A(W), 2x1.1(MC)
100-277VAC 50-60Hz
2x 70 A@240VAC, cold start
cos.φ= 0.96 (RN&W), 0.94(US)
32.8 Kg
-40°C to +50°C ( -40°F to 122°F )
IK09
Front = 0.39 m2
Side = 0.11 m2
© Copyright Griven 2020 - GRIVEN S.r.l. is continuously
developing and improving all its products.
We reserve the right to change specifications without
prior notification
AL5021 - AL5023 (PE)
I
IP67
Capital 600 MC
150mm
5.9in
page 1 of 9
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Griven Capital 600
Summary of Contents for Griven Capital 600
- Page 1 Dimensions / Dimensioni 517mm 150mm 20.4in 5.9in page 1 of 9 © Copyright Griven 2020 - GRIVEN S.r.l. is continuously Griven S.r.l. - Via Bulgaria, 16 Tel. +39.0376.779483 developing and improving all its products. E-mail: sales@griven.com 46042 Castel Goffredo We reserve the right to change specifications without Web: www.griven.com...
- Page 2 Replaceable (LED only) light source by a professional professionista This product contains a light source of energy efficiency Questo prodotto contiene una sorgente luminosa di classe class: di efficienza energetica: page 2 of 9 3000K 4000K Dynamic White RGBW 4000K Capital 600...
-
Page 3: Installation - Installazione
175mm 6.9in 6.9in Vertical beam-aiming - Orientamento both screws +100° -30° both screws +100° -30° both screws A=size 13 (ISO) Wrench, Tightening torque 24.1 Nm page 3 of 9 A=Chiave inglese 13 (ISO), Coppia di serraggio 24 Nm Capital 600... - Page 4 Blue= N (Neutral) MAINS: 100-277VAC 50/60Hz Yellow/Green=GND Brown=L (Live) RED= DALI bus + BLACK= DALI bus - DALI IN/OUT RED= DALI bus + BLACK= DALI bus - Blue= N (Neutral) MAINS: 100-277VAC 50/60Hz Yellow/Green=GND Brown=L (Live) page 4 of 9 Capital 600...
- Page 5 Seguire le istruzioni fornite insieme al kit di connessione. EN: The connections of the cables type “S” and “M” must be made using the connection kit to be ordered separately. Follow the instructions provided with the connection kit. page 5 of 9 Capital 600...
-
Page 6: Fixture Configuration
0-100% Green fine tuning 0-255 • Temperature: it displays the LEDs operating temperature IR=8 value. 0-100% Blue 0-255 0-100% Blue fine tuning 0-255 0-100% White 0-255 page 6 of 9 0-100% White fine tuning 0-255 Capital 600... - Page 7 Query Fade Time/Fade Rate 176...191 Query Scene level Query Groups 0...7 Query Groups 8...15 Query Random Address High Query Random Address Middle Query Random Address Low DALI version: 1, Device Type: 6(LED), Physical Min Level: 1 (0.1%) page 7 of 9 Capital 600...
- Page 8 C - Start Line Box - AL5058C with connectors / AL5058M without connectors D - Capital 600 E - Connection Cable - AL8264 L=1m (3 ft) AL8265 L=2m (6 ft) AL8266 L=3m ( 10 ft) AL8267 L=5m ( 16 ft) AL8268 L=10m ( 32 ft)
-
Page 9: Dmx Mode
ATTENZIONE ! in questa modalità non deve essere presente lungo la linea nessun altro dispositivo di controllo DMX. Polar features (only on Polar Edition fixtures ) Caratteristiche Polar (solo su dispositivi Polar Edition) Std. Capital 600 Polar AL5022 AL5025 AL5023 The POLAR Edition is fitted with a frontal thermal glass which is particularly useful for outdoor applications.
