Eaton MX16CELL Installation Instructions

Installation Instructions
P/N P85905
Cellular Gateway and PoE Injector
installation instructions
Description
The (optional) Cellular Gateway is sold as a kit (part
number MX16CELL) and provides an internet connection
for the MX16US panel, allowing 2-way VoIP calls when a
wired Local IT network is not available.
The MX16CELL kit includes a Cellular Gateway (LTE router)
an antenna, antenna cable, a PoE Injector (PoE), and an
ABS enclosure with hardware.
The Cellular Gateway is to be installed in the ABS enclo-
sure; the ABS enclosure must be installed indoors in
the same building as the MX16US. The Cellular Gateway
antenna can be mounted to the enclosure as described in
this manual; alternately, the antenna can be mounted to
a suitable nearby surface, however the antenna must be
indoors and in a location that receives a reliable cellular
network signal.
The PoE Injector is to be installed inside the MX16US
panel, adjacent to the Gateway Dialer on a mounting plate.
The Cellular Gateway is intended to be installed and oper-
ated in the VoCALL 16US system without the need for
programming or additional device management configura-
tion.
The Cellular Gateway requires a data plan activated
through a compatible cellular service provider. The end
customer is responsible for establishing and maintaining
an account and expenses associated with the cellular
service provider. A data plan allowance of 5 GB/month is
recommended. Typical data usage between the Dialer and
the VoIP service provider is approximately 100 MB/day.
N ote: Eaton is a registered trademark. All other brands,
including Microsoft®, Sierra Wireless® and Altronix®,
and product names including, but not limited to, Azure®,
NetWay1X® and AirLink LX40®, are trademarks or regis-
tered trademarks of their respective owners.
N ote: The Sierra Wireless AirLink LX40 is a third party
manufactured device; refer to the manufacturer's Website,
www.sierrawireless.com/router-solutions/lx40/
instructions and a list of compatible providers.
Refer to the AirLink LX40 Hardware User's Guide to
N ote:
resolve any technical concerns when installing and operat-
ing the unit.
N ote: Refer to the AirLink LX40 Hardware User's Guide
for a list of provider certifications, protocols, LED attributes
and other specifications and descriptions.
August 2024
The Altronix® NetWay1X PoE Injector is a third party device;
N ote:
refer to the manufacturer Website,
NetWay1X for additional information to resolve any technical
concerns when installing and operating the unit.
Table 1 provides a list of supporting documents for the VoCALL
16US system.
Table 1. Related VoCALL Documents
Document
VoCALL 16US 2-Way Emergency
Communication System Installation
and Operation Manual
Call Station Installation Instructions
Cellular Gateway:
AirLink® LX40 Hardware User Guide Refer to manufacturer's website
PoE Injector:
Altronix NetWay1X Installation Guide Refer to manufacturer's website
Tables 2 through 5 provide specifications for the components
included in the Gateway Dialer Kit.
Table 2. Cellular Gateway Specifications
Specification
Manufacturer
Environmentals
Dimensions
(including connectors)
Mounting
Connections
Antenna:
Communications:
for
Power
MX16CELL Kit
www.altronix.com/products/
Part Number
P85899
25-1017
Description
Sierra Wireless AirLink LX40
32 ¤ F - 98 ¤ F (0 ¤ C - 37 ¤ C)
0 - 70H, non-condensing
4.4 x 3.1 x 1.0 inches (11.1 x 7.9 x 2.5 cm)
Mounts to the back plane inside the ABS
enclosure
SMA plug
RJ45
Input Voltage: 7 - 36 VDC
PoE: 13W, Type 1 Power Device, IEEE 802.3af
