- Page 1 Power Xpert Insight Gateway Quick Start Guide Version 3.1...
-
Page 2: Table Of Contents
Power Xpert Insight Gateway Quick Start Guide Contents Preface ..................1 Safety Information ................1 PXG900 Kit Contents ..............2 Requirements for Installation ............2 Requirements for Configuration ...........2 Mounting ...................3 Grounding .................4 Connecting the Power Supply ............5 Connecting a PC via the USB Cable ..........6 Connecting Devices ................9 Connecting a PXG900 to the Ethernet LAN ........9 Configuring the Gateway ............10... -
Page 3: Preface
WARNING For technical support, please contact the Eaton Customer Suc- cess Team. You can reach them by: The safety message that follows has WARNING level haz- ards. -
Page 4: Pxg900 Kit Contents
Power Xpert Insight Gateway Quick Start Guide • Twisted pair cabling for communications between the Mod- CAUTION bus RTU and INCOM networks and the PXG900 communica- THE PXG900 CONTAINS A LITHIUM BATTERY. THERE IS A tions ports. RISK OF EXPLOSION IF THE BATTERY IS REPLACED BY AN •... -
Page 5: Mounting
Power Xpert Insight Gateway Quick Start Guide Mounting The PXG900 can be panel-mounted vertically or horizontally, and fastens via four user-supplied screws on the rear plate. It can also be attached via a DIN rail (the adapter is shipped with the gateway, along with appropriate mounting machine screws). You can adjust the DIN rail adapter to allow vertical or horizontal mounting (default) by removing the two Phillips screws to the left and right of the center pivot bolt and rotating the DIN mounting clip. -
Page 6: Grounding
Power Xpert Insight Gateway Quick Start Guide Remove and then reattach these screws to rotate for vertical mounting 2.023 1.97 (51.402) (50) 2.56 (65) 5.04 (128) Top View 0.556 6 (152.4) (14.12) Front View Side View DIN Rail Adapter Mounting Dimensions Grounding The GND of the 24 VDC;... -
Page 7: Connecting The Power Supply
Power Xpert Insight Gateway Quick Start Guide 24 VDC Supply Power Xpert Gateway Power Xpert Gateway Grounding the PXG900 Wiring Connections Connecting the Power Supply Connect the two power supply leads from a 24 VDC; 0.3 A minimum, class 2 power supply to the two-pin Phoenix connector shipped with the unit. -
Page 8: Connecting A Pc Via The Usb Cable
You can connect a PXG900 to a PC via the USB A to USB Mini-B cable shipped with the gateway. Before your PC can connect to the gateway, you’ll need to first install the USB driver from Eaton. You will need administrative privilege on the PC in order to install the driver. - Page 9 Power Xpert Insight Gateway Quick Start Guide Update Driver Locate and select the folder containing the powerxpert.inf file. Software Choose Open. The folder displays in the Search for driver software in this location box. Folder Selected Select Browse my computer for driver software. Choose Next.
- Page 10 Power Xpert Insight Gateway Quick Start Guide 10. If the message “Windows can't verify the publisher of this driver software” displays, select Install this driver software anyway. Select Install this driver anyway Success! 11. To verify that the device is installed: •...
-
Page 11: Connecting Devices
Power Xpert Insight Gateway Quick Start Guide Connecting Devices INCOM USB to PC Linux USD Ethernet/RNDIS Gadget 12. From the Start menu, go to All Programs > Accessories > Command Prompt to open a Command Prompt window. 13. Enter ipconfig /all. Power Xpert Insight™... -
Page 12: Configuring The Gateway
DHCP server or router. If you choose this You’ll be prompted to enter a user ID and password. The approach, Eaton recommends that you use DHCP Reser- vations so that you can ensure that the PXG900 is always default for both is “admin.”... - Page 13 To edit the Ethernet settings: On the network tab, click the Edit button. Sidebar Choose the gear icon at the right of the Eaton Power Xpert bar. Configuration is done in the sidebar, shown to the right.
-
Page 14: Settings
Power Xpert Insight Gateway Quick Start Guide Settings To specify a static IP address: Enter the IP Address for the PXG900. Under Settings, you can configure: Enter the IP address information for your network, including • Date and Time the Subnet Mask, Gateway, and one or more DNS servers. Separate the DNS server addresses with a comma. - Page 15 Power Xpert Insight Gateway Quick Start Guide Note: Make sure you set the time zone under Locale as well. Locale Settings Date Network Access Tab & Time Access Control Ethernet communications supports the usual ports for HTTP, Settings HTTPS, and Modbus TCP: 80, 443, and 502 respectively. You can disable, enable, or change these ports.
-
Page 16: Configuring Device Communications
Power Xpert Insight Gateway Quick Start Guide Select Trusted Only for the appropriate selection. Configuring Modbus TCP/IP Save your changes. You enable the server under the Access control group (Modbus TCP must be enabled to see Modbus TCP Server Configuration). You can also change the TCP port. -
Page 17: Incom Port
Power Xpert Insight Gateway Quick Start Guide INCOM Port Choose the gear icon to access the INCOM port serial settings. Com 2 Modbus INCOM Port Port settings settings Before connecting the PXG900 to either a twisted pair Modbus or a twisted pair INCOM cable, make sure that you observe the proper polarity when wiring the cable to one of the three-pin Phoenix connectors provided. -
Page 18: Adding Devices
Adding devices, like port configuration, is done on the Network tab. For more information on wiring an INCOM network, see the Eaton Electrical Field Devices Communication Wiring Specification The PXG900 helps you when adding devices, guiding you through (TD 17513) available at www.eaton.com/pxg. - Page 19 Power Xpert Insight Gateway Quick Start Guide Examples Sidebar, The following examples assume that you have the devices on the appropriate networks and that the ports are properly configured. showing Example 1: Adding An IQ 250 Meter settings Connect the IQ 250 Meter to either Com1 or Com2. to add an Choose the Network tab.
- Page 20 Power Xpert Insight Gateway Quick Start Guide Sidebar, Example 2: Adding a Digitrip 1150 Breaker showing Choose the Network tab. settings Choose Edit. to add a Choose Add Device under INCOM. Select Protection under Family. Digitrip Select Digitrip Breaker under Model Series 1150 Select Digitrip 1150 under Model.
-
Page 21: Pxg900 Indicators
Power Xpert Insight Gateway Quick Start Guide PXG900 Indicators The following figure details what the function of the various PXG900 indicator lights. Com2 Com1 INCOM DHCP Bridge Power Status Power Xpert Insight™ Gateway... -
Page 22: Ethernet Status Leds
Power Xpert Insight Gateway Quick Start Guide Power: Lights green when power is supplied to the gateway. Web: Lights red when one or more browsers are currently ac- cessing the gateway’s web server. Com2/Com1: Transmit (green) and receive (yellow) flash during data transfer between the gateway and Modbus devices. -
Page 23: Reset Switch
Power Xpert Insight Gateway Quick Start Guide Activity: blinks green during network activity. If the activity indicator is blinking but the link speed indicator is off, the connection speed is 10Mb. Reset Switch If it becomes necessary to reboot the PXG900 or reset the gate- way to its default settings, you can use the Reset switch. - Page 24 If further information is required, an Eaton sales office should be con- sulted. Sale of the product shown in this literature is subject to the terms and conditions outlined in appropriate Eaton selling policies or other contractual agreement between Eaton and the purchaser. THERE ARE NO UNDERSTANDINGS, AGREEMENTS, WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE OR MERCHANTABILITY, OTHER THAN THOSE SPECIFICALLY SET OUT IN ANY EXISTING CONTRACT BETWEEN THE PARTIES.
- Page 25 Eaton Corporation Electrical Sector 1000 Cherrington Parkway Moon Township, PA 15108 United States 877-ETN-CARE (877-386-2273) Eaton.com/pxg © 2015 Eaton Corporation All Rights Reserved Printed in USA March, 2015 MN152004EN...
