Binks SG-2 Plus
TM
Pressure Cup is ideal for component spraying and industrial
applications where small batch production spraying is required. The 2 qt. capacity is
sufficient to complete large spray jobs without refilling the cup. Its lightweight and
rugged construction is excellent for portability allowing the operator to make fluid
and air control adjustments quickly and efficiently at the spray station.
The internal construction is designed for waterborne and solvent base materials.
Other features include:
• Stainless steel pick-up tube, fluid fittings and removable
plastic liner makes it corrosion resistant.
• "Wide-mouth" opening allows easy cleaning,
plastic liner removal and quick color change.
• Positive grip carrying handle for operator comfort.
• Wide stainless steel base for stability and corrosion
resistance.
• 0-10 psig fluid pressure range.
• Optional 0-50 psig pressure kit (80-619) available for
high viscosity fluids.
• Fluid agitator on model 80-601 for paints requiring
continuous agitation.
• Silverstone
coating on interior and exterior of lid.
®
SPECIFICATIONS
MAX. WORKING PRESSURE . . . . . . . . . . . . . 50 psig
OVERALL HEIGHT . . . . . . . . . . . . . . . . . . . . . 15 11/16 in.
BASE DIAMETER . . . . . . . . . . . . . . . . . . . . . . 6 in.
DIA. ACROSS CLOSED CLAMPS. . . . . . . . . . . 8 1/16 in.
DIA. ACROSS OPEN CLAMPS . . . . . . . . . . . . 8 1/16 in.
AIR INLET & OUTLET CONNECTION SIZE . . . 1/4 NPS (m)
FLUID OUTLET CONNECTION SIZE . . . . . . . . 3/8 NPS (m)
FLUID CAPACITY . . . . . . . . . . . . . . . . . . . . . . 2 Qts. (U.S.)
WEIGHT
STANDARD UNIT . . . . . . . . . . . . . . . . . . . . 4 lb.14oz.
UNIT WITH AGITATOR . . . . . . . . . . . . . . . 5 lb.7oz.
!
All air and fluid pressure in the system must be relieved
before servicing the cup and before cup is filled or cleaned.
Attempting to service the cup while pressurized could
result in damage to components or personal injury.
77-2841-R6 (6/2018)
All manuals and user guides at all-guides.com
SG-2 PLUS
MODEL NO. 80-600 (STANDARD)
MODEL NO. 80-601 (WITH OSCILLATING AGITATOR)
INTRODUCTION
3.5 KG/cm
39.88 cm
15.24 cm
20.47 cm
20.47 cm
1.9 Liters
2.21 kg.
2.47 kg.
WARNING
2 QT. PRESSURE CUPS
TM
2
--
--
1 / 12
MODEL NO. 80-600 (Standard)
www.carlisleft.com
Advertisement
Table of Contents
Related Manuals for Carlisle SG-2 PLUS 80-600
Summary of Contents for Carlisle SG-2 PLUS 80-600
- Page 1 All manuals and user guides at all-guides.com SERVICE MANUAL SG-2 PLUS 2 QT. PRESSURE CUPS MODEL NO. 80-600 (STANDARD) MODEL NO. 80-601 (WITH OSCILLATING AGITATOR) INTRODUCTION Binks SG-2 Plus Pressure Cup is ideal for component spraying and industrial applications where small batch production spraying is required. The 2 qt. capacity is sufficient to complete large spray jobs without refilling the cup.
- Page 2 All manuals and user guides at all-guides.com In this part sheet, the words WARNING, CAUTION and NOTE are used to emphasize important safety information as follows: WARNING NOTE CAUTION Hazards or unsafe practices which Hazards or unsafe practices which could result in severe personal Important installation, operation or could result in minor personal injury, injury, death or substantial property...
-
Page 3: Typical Installation
All manuals and user guides at all-guides.com SETUP AND OPERATION Refer to “TYPICAL INSTALLATION” drawing below WARNING Set up the SG-2 Plus with the CONVENTIONAL or HVLP gun along with at least 5 ft. of air and fluid hose. Chlorinated solvents and aluminum are incompatible and will Attach air hose from extractor to air inlet on handle of steadi- cause an adverse chemical reaction, possibly resulting in bodi- ly injury. - Page 4 All manuals and user guides at all-guides.com MODEL 80-600 SG-2 PLUS PRESSURE CUP (Standard) • Items NOT available separately. www.carlisleft.com 4 / 12 77-2841-R6 (6/2018)
-
Page 5: Parts List
All manuals and user guides at all-guides.com MODEL 80-600 SG-2 PLUS PRESSURE CUP (Standard) PARTS LIST (When ordering, please specify Part No.) ITEM PART ITEM PART DESCRIPTION QTY. DESCRIPTION QTY. 80-375 2 QT CANISTER ASM ....1 54-308 AIR CONNECTION ......1 80-376+ 2 QT CANISTER SUB-ASM .... - Page 6 All manuals and user guides at all-guides.com MODEL 80-601 SG-2 PLUS PRESSURE CUP WITH OSCILLATING AGITATOR • Items NOT available separately. www.carlisleft.com 6 / 12 77-2841-R6 (6/2018)
- Page 7 All manuals and user guides at all-guides.com MODEL 80-601 SG-2 PLUS PRESSURE CUP WITH OSCILLATING AGITATOR PARTS LIST (When ordering, please specify Part No.) ITEM PART ITEM PART DESCRIPTION QTY. DESCRIPTION QTY. 80-375 2 QT CANISTER ASM ......1 81-307 BARBED CONNECTOR ......
- Page 8 All manuals and user guides at all-guides.com PRESSURE CONVERSION KITS CONVERSION KIT 80-619 – Allows conversion from low (0-10 PSI) to high pressure operation. WARNING Attempting to install the conversion kit while the system is pressurized could result in damage to components or bodily injury. INSTRUCTIONS: 1.
- Page 9 All manuals and user guides at all-guides.com NOTES 77-2841-R6 (6/2018) 9 / 12 www.carlisleft.com...
- Page 10 All manuals and user guides at all-guides.com NOTES www.carlisleft.com 10 / 12 77-2841-R6 (6/2018)
- Page 11 All manuals and user guides at all-guides.com NOTES 77-2841-R6 (6/2018) 11 / 12 www.carlisleft.com...
-
Page 12: Warranty Policy
This product is covered by Carlisle Fluid Technologies’ materials and workmanship limited warranty. The use of any parts or accessories, from a source other than Carlisle Fluid Technologies, will void all warranties. Failure to reasonably follow any maintenance guidance provided may invalidate any warranty.
