Summary of Contents for Creality CFS
- Page 1 User Manual CFS Filament Management System V 1.2_EN...
- Page 2 Creality is always ready to provide you with high-quality services. If you encounter any issues or have any questions when using our products, please use the contact information at the end of this manual to contact us. To further improve your user experience, you can find more about our devices via the following methods: Visit our official website (https://www.creality.com) to find information regarding software, hardware,...
- Page 3 (used), abide by professional ethics, pay attention to safety obligations, and strictly prohibit the use of our products or equipment for any illegal purposes. Creality will not be responsible for any violators' legal liability under any circumstance.
-
Page 4: Table Of Contents
03-03 ······················································································ 1.4 Equipment Size 04-04 ····························································································· 05-05 2. Unboxing ···································································· 05-05 2.1 Unpack the desiccant and put it into CFS ···························································································· 06-07 3. CFS Usage ············································································· 3.1 Loading Filament From CFS 06-06 ········································································· 3.2 Connecting Multiple CFSs for Use... -
Page 5: Equipment Information
Scan the code to know more E-mail: cs@creality.com V2.2 V2.2 E-mail: cs@creality.com Pyc. PT-BR V1.1 Creality 485 cable 45cm Creality 485 cable 100cm Quick Guide After-sales service card Tips: the above accessories are for reference only. Please refer to the physical accessories. -
Page 6: About The Equipment
1. Equipment Information 1.2 About the Equipment CFS 485 port Power adapter socket Filament compression block CFS hub outlet Desiccant storage location Filament intlet Left buckle Filament status light Screen Right buckle... -
Page 7: Equipment Specifications
1. Equipment Information 1.3 Equipment Specifications Basic Parameters Model Number of silos Rated Power Rated Voltage DC 24V Expandable number ≤4 Product size 379*314*276mm Net weight 4.56kg Filament status multi-function indicator light Four [one for each channel] Multi-color printing Automatic refilling RFID identification Filament detection Buffer... -
Page 8: Equipment Size
1. Equipment Information 1.4 Equipment Size 488mm 105° 450mm... -
Page 9: Unboxing
Find the desiccant storage location, open the top cover and put the unlock and open the top cover; desiccant in, and then put the top cover back. Tear off the film on the surface of the desiccant first, and then put the desiccant into the CFS. -
Page 10: Cfs Usage
The desiccant may need to be replaced. Introduction to the filament management interface: The filament management page is divided into two parts: the spool holder [left] and the CFS [right]. The code above the filament in the CFS, such as 1A, indicates the slot number;... -
Page 11: Connecting Multiple Cfss For Use
3.2 Connecting Multiple CFSs for Use One to one Power supply + Data Filament Buffer Printer PTFE tube PTFE tube One to four 4 CFS power supplies + Data CFS 1 PTFE tube CFS 2 Filament Buffer PTFE tube Printer CFS 3... -
Page 12: Fcc Warning
FCC WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 13 Due to the differences between different machine models, the actual objects and the images can differ. Please refer to the actual machine. The final explanation rights shall be reserved by Shenzhen Creality 3D Technology Co., Ltd. SHENZHEN CREALITY 3D TECHNOLOGY CO., LTD.
