创造现实，成就梦想
Create reality，achieve dreams
CR-10 Smart Pro
CR-10 Smart Pro
3D Printer User Manual
3D打印机用户使用手册
V1.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CR-10 Smart Pro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Creality CR-10 Smart Pro

Summary of Contents for Creality CR-10 Smart Pro

  • Page 1 创造现实，成就梦想 Create reality，achieve dreams CR-10 Smart Pro CR-10 Smart Pro 3D Printer User Manual 3D打印机用户使用手册 V1.2...
  • Page 2 随机使用说明：您可以在存储卡内找到相关使用说明及视频。 您还可以登陆创想三维官网(www.cxsw3d.com)寻找相关软硬件、 联系方式、 设备操作、 设备保养等信息。 Firmware Upgrade Please login the o cial website https://www.creality.com/download, switch the language and select the relevant printer and model and download the required firmware, you can use it after the installation is finished. 固件升级 请您登录官网https://www.cxsw3d.com，点击首页→服务支持→下载所需固件，安装完成后即可使用。...
  • Page 3 Users should comply with the laws and regulations of the corresponding countries and regions where the equipment is located (used), abide by professional ethics, pay attention to safety obligations, and strictly prohibit the use of our products or equipment for any illegal purposes. Creality will not be responsible for any violators' legal liability under any circustance.

  • Page 4: Table Of Contents

    Contents目录 Introduction 设备简介 01-01 Parameters 设备参数 02-02 Parts List 零部件清单 03-03 Assemble the 3D Printer 组装3D打印机 04-09 Use the 3D Printer 使用3D打印机 10-17 创想云配网方式1 18-19 创想云配网方式2 20-21 Off-line print 脱机打印 22-23 Start print 开始打印 24-24 25-25 Network reset 网络复位 Printer maintenance 打印机维护 26-26 27-27 Wiring Connection电路接线...

  • Page 5: Introduction 设备简介

    1. Introduction 设备简介 工具盒 拉杆 Feeding holder components Tool Box Pull rod 料架组件 卡槽 丝杆 Storage Card Slot 存储 Screw rod LED灯 触摸屏 联轴器 LED Light Touch screen Coupling 断料检测 WiFi二维码 Z轴电机 Filament Detector WiFi QR code Z-axis motor X Limit Switch X轴限位开关...

  • Page 6: Parameters 设备参数

    2. Equipment parameters 设备参数 Basic Parameters 基本参数 Model | 型号 CR-10 Smart Pro Printing Size | 成型尺寸 300*300*400mm Molding Tech | 成型技术 Nozzle Number | 喷头数量 Slice Thickness | 切片层厚 0.1mm-0.4mm Nozzle Diameter | 喷嘴直径 Standard 0.4mm | 标配0.4mm Precision | 打印精度...

  • Page 7: Parts List 零部件清单

    3. Package Content 零件清单 Spool｜ 料管 Base Frame｜底座 Gantry Frame｜龙门架 Touch screen ｜ 触摸屏 Power Cord｜电源线 Rack｜料架 M5×12 Hexagon flat round M5x20 Hexagon flat round M5 Large Flat gasket ×2 M5x45 Sems Screw ×4 Pull rods｜ 拉杆 Filament ｜ 耗材 head screws x2 head screw x2 M5加大平垫...

  • Page 8: Assemble The 3D Printer 组装3D打印机

    4. Install the Gantry Frame 安装龙门架 Base Frame｜底座 X axis X轴 Two Z-axis profiles, installed on the inner step of the Y-axis bottom profile. Gantry Frame｜龙门架 两根Z轴型材，靠Y轴底部型材内侧台阶安装。 Twist the coupling to raise the X axis M5x45 Sems Screw ×4 to the position shown in Figure 16. M5x45组合螺丝...
  • Page 9 5. Pull Rod Installation 拉杆安装 Adjust the proper length of assembled pull rod and install in the position shown in the figure 拉杆组装调节到合适的长度， 安装在图示位置 M5×12 Hexagon flat round head screw x2 M5x12 内六角平圆头螺丝 M5x20 Hexagon flat round head screws x2 M5x20 内六角平圆头螺丝...
  • Page 10 6. Nozzle Kit Installation 喷头组件安装 ｜ 喷头组件 Nozzle Kit 螺丝已固定在喷头组件上，用户需自行拆装...
  • Page 11 7. Install the Rack 安装料架 When you wait for the temperature to rise,hang the filament over the Filament Holder. 安装图示将料架装配到机器上方 Rack｜料架 Spool｜料管...
  • Page 12 8.Install the touch screen 安装触摸屏 Touch screen ｜ 触摸屏 1. Connect the FFC on the base with the touch screen. 1、把底座的排线与触摸屏连接起来 mounting disassembly 安装 拆卸 2. Correctly put 3 mounting holes in the back of the touch screen onto 3 studs in the housing, and carefully complete assembly in a direction as indicated by the arrow.
  • Page 13 9. Cable Connection 设备接线 Loosen the screws before connecting the nozzle Power Cord｜ 电源线 assembly, and then tighten the screws. 连接喷头组件之前先将螺丝拧松， 连接完成后拧紧螺丝。 Get the middle range of the black positioning label of the Flexible Flat Cable (FFC) stuck at the line claw. 将排线上黑色定位标签中间范围卡在线夹处...

  • Page 14: Use The 3D Printer 使用3D打印机

    10. Bed Leveling 调平平台 1. Slelct“Level”to automatically level 选择首页调平，进入调平模式。 >> -2.6 >> -2.6 During the leveling process,please do not touch the nozzle cable. 调平过程中 ， 请不要触碰喷头排线。...
  • Page 15 10. Bed Leveling 调平平台 使其与喷嘴处于刚好贴合状态， 标准调平卡一张，或者用A4纸...
  • Page 16 10. Bed Leveling 调平平台 （标准调平卡一张，或者用A4纸）...
  • Page 17 10. Bed Leveling 调平平台 进入自动调平，电机启动，等待自动调平完成。 2. After the leveling is completed,adjust the Z-axis compensation value according to the adhesion of the printing consumables and the glass 调平完成后，依据打印耗材与玻璃平台的粘附情况，适当调节Z轴补偿值 >> >> During the leveling process,please do not touch the nozzle cable. 调平过程中 ， 请不要触碰喷头排线。...
  • Page 18 11. Preheating Method 预热方法 To avoid extended pre-heating time, you can warm up the machine before selecting the model or setting some parameters. 为了避免打印预热时间较长，可以先对机器进行预热，再选择模型或者设置其他参数，节省预热时间。 Method 1 方法1 Notes:The interface of the manual of instruction is only for reference, and the actual interface shall be subject to the display of the machine.
  • Page 19 11. Preheating Method 预热方法 Method 2 >> 方法2 >> Notes: 1、The print preheating standard is adjusted at the factory, PLA preheating standard: nozzle temperature 200 °, hot bed temperature 60 °, ABS preheating standard: nozzle temperature 240 °, hot bed temperature 70 °.If you need to adjust it due to printing materials or other reasons, you can adjust the parameters on the interface home page control →...
  • Page 20 12. Load Filament 装料 When you wait for the temperature to rise,hang the filament over the Filament Holder. 当您等待温度上升时，把耗材挂在料架上。 For loading filament smoothly,the end of the filament should be placed as shown above. 为了顺利完成装料，耗材的末端位置应如图所示。...
  • Page 21 12. Load Filament 装料 When it reaches the target temperature, insert the filament into the small hole of the Extruder until it reaches the nozzle through the filament cutting detection module. If the filament flows out from the nozzle, it presents that the filament is properly loaded. 当前温度达到目标温度时，将耗材通过断料检测模块，插入挤出机小孔直至喷嘴位置，看到喷嘴处有耗材流出即表示耗材已经装载完成。...
  • Page 22 创想云配网方式1 >> >> >> >> 1.Scan and download 2.Register 3.Log in 4. Select bluetooth 5.Add equipment CR-10 Smart Pro >> >> >> >> >> CR-10 Smart Pro 6. Connect to local WiFi 7. Select model 8. Select machine 9. Printing 10.

  • Page 23: 创想云配网方式1

    创想云配网方式1 >> >> >> >> 1.下载创想云 2.注册 3.登录 4.选择蓝牙 5.连接本机蓝牙 CR-10 Smart Pro >> >> >> >> >> CR-10 Smart Pro 6.连接WiFi 7.选择模型 8.选择机型 9.打印 10.选择设备 11.开始打印...

  • Page 24: 创想云配网方式2

    >> >> >> 1.Scan and download 2.Register 3.Log in 4. Scan QR Code 5. Network settings 6. Connect machine WiFi CR-10 Smart Pro >> >> >> >> >> CR-10 Smart Pro 7. Connect to local WiFi 8. Select model 9. Select machine 10.
  • Page 25 创想云配网方式2 >> >> >> >> >> 1.下载创想云 2.注册 3.登录 4.扫一扫 5.网络设置 6.连接本机WiFi CR-10 Smart Pro >> >> >> >> >> CR-10 Smart Pro 7.连接用户WiFi 8.选择模型 9.选择机型 10.打印 11.选择设备 12.开始打印...

  • Page 26: Off-Line Print 脱机打印

    15. Off-line print 脱机打印 3. Select language→Next→Select your machine→Next→Finish. >> >> 1. Download the software from official website 4.Open Creality 3D slicer → Load （Read file) → Select file. (www.cxsw3d.com) or find the software in storage card 打开创想三维切片软件→Load （读取文件） →选择文件。 for installation. 登录官网下载(www.cxsw3d.com)或者...
  • Page 27 15. Off-line print 脱机打印 >> 5.Generate G-code， and save the gcode file to storage card. 6.Insert the storage card 生成 G 代码文件→保存到存储卡 插入存储卡 Notes: 1、For details on the software instructions, please refer File names must be Latin letters or numbers, not Chinese to the slicing software manual in the storage card.

  • Page 28: Start Print 开始打印

    16. Start Printing 开始打印 Inspect the machine before printing: Turned off: 1. The nozzle is tight and moves left and right smoothly; 2. X-axis is tightly horizontal and runs smoothly up and down; 3. Y-axis is tight. The platform board does not shake around, and moves back and forth smoothly; 4. The filament rack is tight, the roller works smoothly with uninterrupted materials, and the material comes out smoothly.

  • Page 29: Network Reset 网络复位

    17. Network reset 网络复位 11. Start Printing 开始打印 >> >> Note: 注意： 1. In the first use or if you need to clear the owner information, you can click “Restore network” button on the screen, wait for 1-2 minutes and then try to scan the code again or connect the network via Bluetooth. 在首次使用或需要清除机主信息时，可点击屏幕‘恢复网络设置’后，等待1-2min尝试重新扫码或蓝牙连接配网。...

  • Page 30: Printer Maintenance 打印机维护

    18. Printer maintenance 打印机维护 1. Manually adjust the tightness as needed by turning the knob left and right (clockwise to tighten and counterclockwise to loosen.) Avoid over tightening, which may break the belt and cause damage to the machine. (As shown in A) 1.手动将旋钮左右拧到适合松紧度（顺时针调紧，逆时针调松。）...

  • Page 31: Wiring Connection电路接线

    19. Circuit Wiring 电路接线 Y axis motor limit switch Z1 axis motor Z2 axis motor Y 轴电机加限位 Z1 轴电机 Z2 轴电机 Cable Port1 排线接口1 Storage Card Slot 存储卡卡槽 Cable Port2 排线接口2 WIFI Port WIFI 接口 Screen Interface 屏幕接口 Fuse 保险丝 Power Input Hot Bed Power Output Bed Thermistor...

  • Page 32: Troubleshooting 故障检修

    20. Trouble-shooting Play by menory storage card motor Extrusion gear loose motor...
  • Page 33 21. 故障检修...

  • Page 34: After-Sales Service Card 售后服务卡

    Please read the user manual and warranty card carefully before the use. For any service, Please priorly contact local seller or contact us via Email: cs@creality.com for support. See www.creality.com/after-service-policy/ for specific warranty information about your product and procedures to act on a warranty claim.
  • Page 35 售后服务卡...
  • Page 36 售后服务卡 微信公众号：深圳市创想三维科技股份有限公司...
  • Page 37 Statement FCC Caution: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 38 IC Caution: This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. To maintain compliance with RF exposure guidelines, this equipment should be installed and operated with a minimum distance of 20cm between the radiator and your body.
  • Page 39 Warning For pluggable equipment, the socket-outlet shall be easily accessible. Pour l'équipement pluggable, la prise de prise doit être facilement accessible. Do not use this apparatus near water. Ne pas utiliser cet appareil à proximité des sources d'eau. Clean only with dry cloth. Nettoyer seulement avec un chiffon doux sec.
  • Page 40 Notes 笔记...
  • Page 41 Notes 笔记...
  • Page 45 最终解释归深圳市创想三维科技股份有限公司所有。 SHENZHEN CREALITY 3D TECHNOLOGY CO., LTD. Add:18F,JinXiuHongDu Building, Meilong Blvd., Longhua Dist., Shenzhen, China 518131 cial Website: www.creality.com Tel：+86 755-8523 4565 E-mail: info@creality.com cs@creality.com 深圳市创想三维科技股份有限公司 深圳市龙华区民治街道新牛社区梅龙大道锦绣鸿都大厦18F Scan To Learn More 公司网站：www.cxsw3d.com 扫 码 了 解 更 多 服务热线：400 6133 882...
