Whalen Vernon MNFP62VN23HLA Manual

62” fireplace console
Hide thumbs

Advertisement

Quick Links

Download this manual
Vernon 62" Fireplace Console
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll-free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
Or visit our web site 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
Model # MNFP62VN23HLA
ADULT ASSEMBLY REQUIRED
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
www.whalenfurniture.com
Or e-mail your request to parts@whalenfurniture.com
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date: 2024-07-15
OR
1-866-942-5362
Rev. 0001-A
LOT NUMBER:
DATE PURCHASED: /
/

Advertisement

loading
Need help?

Need help?

Do you have a question about the Vernon MNFP62VN23HLA and is the answer not in the manual?

Questions and answers

Related Manuals for Whalen Vernon MNFP62VN23HLA

Summary of Contents for Whalen Vernon MNFP62VN23HLA

  • Page 1 LOT NUMBER: DATE PURCHASED: / Vernon 62” Fireplace Console Model # MNFP62VN23HLA ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our toll-free customer service number and have your instructions and parts list ready to provide the model name, part name or factory number: 1-866-942-5362 Pacific Standard Time: 8:30 a.m.
  • Page 2 IMPORTANT Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non-abrasive surface. You will need the parts identified on page 3, 4 and 5 of this instruction manuals. NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH THE DOWELS. EXCESS GLUE CAN BE WIPED OFF WITH A DAMP CLOTH.
  • Page 3 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Heater B- Left Upright Arm C- Right Upright Arm (Qty. 1) (Qty. 1) (Qty. 1) D- Connector Strap E- Ember Bed F- Left Log (Qty.
  • Page 4 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. S- Firebox Bottom Support T- Adjustable Shelf U- Left Door (Qty. 2) (Qty. 2) (Qty. 1) V- Right Door W- Glass Insert X- Side Back Panel (Qty.
  • Page 5 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. (7) M4 x 50 mm Pan Head Screw (8) 1/4” x 25 mm Bolt (9) Lock Washer (Qty.
  • Page 6 Assembly Instructions 1. Unpack the unit and confirm that you have all the hardware and required parts. Assemble the unit on a carpeted floor or the empty carton to avoid any scratch. 2. Securely screw twenty-two Cam Bolts (3) into the designated small holes on both Panels (K and L) and Partitions (N and P) with a Phillips screwdriver.
  • Page 7 Assembly Instructions 4. Glue sixteen Wood Dowels (4) into the designated holes on both Middle Crossbars (Q), Middle Trims (R) and Firebox Bottom Supports (S). 5. Using the wood dowels as a guide, attach the Middle Trims (R) to the Partition (N and P) respectively with six 28 mm Pan Head Screws (6).
  • Page 8 Assembly Instructions The cam lock housings face inward. 6. Orient and attach two Middle Crossbars (Q) between the Partition Panels (N and P) by engaging and tightening four Cam Locks (2) with a Phillips Screwdriver. (Refer to page 2 on Cam Lock system operation supplement).
  • Page 9 Assembly Instructions The hinge face inward and are located at front 8. Using the wood dowels as a guide, orient and attach the Side Panels (M and O) to the Top Panel (K) by engaging and tightening four Cam Locks (2). Turn the Cam Locks (2) with a Phillips screwdriver until loked onto the Cam bolts.
  • Page 10 Assembly Instructions 10. Insert four 50 mm Pan Head Screws (7) through the mounting holes on the Bottom Panel (L) and securely screw into the Partitions (N and P). 11. Align the wood dowels inserted under the Firebox Bottom Supports (S) with the holes on the Bottom Panel L), and then press them together.
  • Page 11 Assembly Instructions 8 9 10 90° mounting holes 12. Align and attached the Metal Legs (Z) to the Bottom Panel (L) and both Side Panels (M and O) using two 25 mm Bolts (8), two Lock Washers (9) and two Flat Washers (10) per leg. 13.
  • Page 12 Assembly Instructions 90° 14. Now, go back and securely tighten all the cam locks and screws. Make sure that all the parts are tight and there are no gaps between the parts. This will help keep the unit square. 15. Ask for assistance to flip around the previous assembly at its front edges. 16.
  • Page 13 Assembly Instructions 19. Using pilot holes as a guide, attach one Handle (B1) to the front of each Door (U and V) with two 22 mm Bolts (13). Tighten with a Phillips screwdriver. Depth Horizontal Vertical Adjustment Adjustment Adjustment 20. Pick up the Doors (U and V) and attach the extended hinge arms to the hinge bases pre-installed on the Side Panels (M and O).
  • Page 14 Assembly Instructions 23. Plug Cam Lock Covers (15) onto the visible Cams Locks to conceal the cams. 24. Stick two Rubber Bumpers (17) onto the Partitions (N and P) as shown.
  • Page 15 Assembly Instructions Figure A Figure B IMPORTANT NOTE: Use hand screwdriver, not power driver to assemble fireplace insert. See BILT for video instructions. 25. See figure A: Fasten upper 2 Insert Screws (1) through the Upright Arm (C) into the Heater (A) until tight.
  • Page 16 Assembly Instructions USB cable 32. Set the Ember Bed (E) onto the Heater (A) as shown. 33. Push ember bed forward against the front flange of heater. 34. Position the USB cable as shown. U-channels 35. Fold the Wall Panel (H) as shown. Then position yourself at back side of Heater (A). 36.
  • Page 17 Assembly Instructions 39. Fully plug the USB connector of the Ember Bed (E) into the back port of Heater (A). The warning labels on glass should face outward. 40. Slide the Glass Screen (I) into the inner U-channels on both Upright Arms (B and C) until the glass sits onto the Heater (A).
  • Page 18 Assembly Instructions The bevel edge faces inside the unit. 41. Position Top Connector Strap (D) over the Glass Screen (I) and Upright Arms (B and C). Follow orientation shown above. 42. Fasten Connector Strap (D) to both Upright Arms (B and C) using two Insert Screws (1) as shown above. Holes must be in line for screw to pass through.
  • Page 19 Assembly Instructions 43. The firebox is now ready for the next assemble step. 44. Lift the fireplace insert carefully into the back of the assembled mantel and centre it on the bottom panel in the opening. 45. Use the pilot holes as a guide, fasten two L-Shaped Metal Brackets (11) onto the Firebox Back Support (Y) with four 12 mm Pan Head Screws (12).
  • Page 20 Assembly Instructions NOTE: To prevent your TV from tipping, you must install the acrylic TV stopper if you place a flat panel television on the top panel. Otherwise, skip to next step. 47. Remove the paper backing of Acrylic Stopper (16), then properly align the acrylic stopper into the cutout on the acrylic stopper template on the front of the Top Panel (K).
  • Page 21 Assembly Instructions Wooden stud Wall Long screw Wall Wall Metal bracket Short screw Connector Wall Floor leveler Steel cable Tools required (not provided): Phillips screwdriver, stud finder, tape measure, pencil, power drill and 1/8” drill bit. 51. Ask for assistance to position the assembled fireplace at the desired location against a wall. If necessary, adjust the floor levelers to correct the tilting and level the doors.

  • Page 22: Care And Maintenance

    Care and Maintenance  Use a soft, clean cloth that will not scratch the surface when dusting.  Use of furniture polishes is not necessary. Should you choose to use polishes, test first in an inconspicuous area.  Using solvents of any kind on your furniture may damage the finish. ...

  • Page 23: Quality Guarantee

    Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
