Midland Twin over Full Bunk Bed
Model # MLTOFBB
ADULT ASSEMBLY REQUIRED
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll-free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
®
Bayside Furnishings
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday to Friday
Or visit our website www.baysidefurnishings.com
Or e-mail your request to parts@baysidefurnishings.com
877-494-2536
Page 1
LOT NUMBER:
DATE OF PURCHASE: / /
Factory # 96-15197
Advertisement
Related Manuals for Whalen Midland Twin over Full Bunk Bed
Summary of Contents for Whalen Midland Twin over Full Bunk Bed
- Page 1 LOT NUMBER: DATE OF PURCHASE: / / Midland Twin over Full Bunk Bed Model # MLTOFBB ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our toll-free customer service number and have your...
-
Page 2: Quality Guarantee
Model # MLTOFBB QUALITY GUARANTEE ® We are confident that you will be delighted with your Bayside Furnishings purchase. Should this product be defective in workmanship or materials or fail under normal use, we will repair ® or replace it for up to one (1) year from date of purchase. Every Bayside Furnishings product is designed to meet your highest expectations. - Page 3 Model # MLTOFBB TO HELP PREVENT SERIOUS OR FATAL INJURIES FROM ENTRAPMENT OR FALLS • Follow the information on the warnings appearing on the upper bunk end structure and on the carton. Do not remove warning label from bed. • Always use the recommended size mattress or mattress support, or both, to help prevent the likelihood of entrapment or falls.
- Page 4 Model # MLTOFBB Parts and Hardware List Please read completely through the instructions and verify that all parts listed are present before beginning assembly. A- Lower Headboard (1) B- Lower Footboard (1) C- Upper Headboard (1) D- Upper Footboard (1) E- Mattress Side Rail (3) F- Ladder Side Rail (1) G- Long Guardrail (2)
- Page 5 Model # MLTOFBB Parts and Hardware List Please read completely through the instructions and verify that all parts listed are present before beginning assembly. ① Ø5/16” x 110 mm Bolt (32+1 extra) ② Ø1/4” x 35 mm Bolt (2+1 extra) ③...
- Page 6 Model # MLTOFBB ASSEMBLING LOWER BUNK NOTE: Please follow the instructions carefully to insure a safe and sturdy bed. Do not fully tighten the bolts until all rails and guardrails are attached. 1. Unpack the unit and confirm that you have all hardware and parts required. 2.
- Page 7 Model # MLTOFBB ASSEMBLING LOWER BUNK 5. Now, lay out the Lower Mattress Support Slats (J) in place between the wood stoppers on both Mattress Side Rails (E). Make sure that every slot has a slat. Insert and screw the 1” Wood Screws ④ into the pre-drilled counter sunk holes in each end of the slats, as shown.
- Page 8 Model # MLTOFBB ASSEMBLING UPPER BUNK WARNING LABEL ON HEADBOARD MUST ALWAYS FACE INWARD. 6. Attach the remaining Mattress Side Rail (E) to the bottom two holes of the Upper Headboard (C) using two Ø5/16” x 110 mm Bolts ① and Barrel Nuts ③ . Make sure the wood stoppers for slats attached on side rail are up and face inward.
- Page 9 Model # MLTOFBB ASSEMBLING UPPER BUNK 10. Lay out the Upper Mattress Support Slats (K) between the wood stoppers on the Mattress Side Rail (E) and Ladder Side Rail (F), ensuring that every slot has a slat. Insert and screw the 1” Wood Screws ④ into the pre-drilled counter sunk holes in each end of the slats, as shown.
- Page 10 Model # MLTOFBB ASSEMBLING UPPER BUNK 11.Now, attach the Front Guardrail Post (I) to the front side of the Ladder Side Rail (F) using two Ø1/4” x 35 mm Bolts ② through the pre-drilled holes on the Post into the inserted nuts on the Side Rail.
- Page 11 Model # MLTOFBB ASSEMBLING UPPER BUNK 12.Attach two Short Guardrails (H) between the Front Guardrail Post (I) and the Upper Headboard (C) using the Barrel Nuts ③ and Ø5/16” x 110 mm Bolts ① , as shown. Tighten all the bolts with the Allen Wrench provided. Ø5/16”...
- Page 12 Model # MLTOFBB ASSEMBLY OF THE BUNK BED 13.Now, place the Lower Bunk in the desired location in the room where the bunk bed will sit. 14.Insert four Bed Connector Pins ⑥ into the top holes of the Lower Bunk as shown. 15.Ask for assistance to place the Upper Bunk on the top of the Lower Bunk using the pins as a guide.
- Page 13 Model # MLTOFBB ASSEMBLY OF THE LADDER 16.Hook the Ladder (L) securely over the top of the Ladder Side Rail (F), between the Front Guardrail Post (I) and the Upper Footboard (D) in the opening provided. Screw the two hooks, pre-attached on the top of Ladder, to the Ladder Side Rail (F) using two 3/4”...
- Page 14 Model # MLTOFBB DISASSEMBLING THE BUNK BED NOTE: The Bunk Bed can be separated into a Twin Bed and a Full Size Bed. In this case, attach four Floor Protectors ⑦ onto the bottom of the posts of the Upper Headboard (C) and the Upper Footboard (D).
-
Page 15: Care And Maintenance
Model # MLTOFBB Care and Maintenance Use a soft, clean cloth that will not scratch the surface when dusting. Use of furniture polish is not necessary. Should you choose to use polish, test first in an inconspicuous area. Using solvents of any kind on your furniture may damage your furniture’s finish. Never use water to clean your furniture as it may cause damage to the finish.
