If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll-free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
Or visit our web site 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Whalen Furniture Manufacturing
Montreal Laptop Desk
Model # ODUS-MLD
ADULT ASSEMBLY REQUIRED
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
www.whalenfurniture.com
Or e-mail your request to parts@whalenfurniture.com
Date 2015-03-16 Rev. 1 Factory: WUHIND
1-866-942-5362
Page 1
LOT NUMBER:
DATE PURCHASED: /
Factory No. 17074
/

Advertisement

loading
Need help?

Need help?

Do you have a question about the Montreal Laptop Desk and is the answer not in the manual?

Questions and answers

Summary of Contents for Whalen Montreal Laptop Desk

  • Page 1 LOT NUMBER: DATE PURCHASED: / Montreal Laptop Desk Model # ODUS-MLD ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our toll-free customer service number and have your...
  • Page 2: Quality Guarantee

    Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
  • Page 3 (4) 1-3/4” Bolt (2+1 extra) (5) Lock Washer (12+1 extra) (6) Flat Washer (12+1 extra) (7) M8 x 30 mm Wood Dowel (4+1 extra) Allen Wrench (2) Touch-up Pen (1) Tools required: Allen wrench (provided). Whalen Furniture Manufacturing Page 3 Factory No. 17074...
  • Page 4 2. Fasten 2 Top Supports (H) to the side rails of Metal Top Frame (B) using the 1” Bolts (2). As shown. Make sure that the stand-off of Top Support (H) points towards the back rail of Metal Frame (B) that has two threaded sockets for the Metal Bars (G). Whalen Furniture Manufacturing Page 4 Factory No. 17074...
  • Page 5 Make sure that the stand-off of Top Supports (H) point towards the back of the Wood Top Frame (A). NOTE: the rail included the threaded sockets for Wood Legs (C and D) is back rail. Whalen Furniture Manufacturing Page 5...
  • Page 6 (2), four Lock Washers (5) and four Flat Washers (6). As shown. Make sure that the metal trim on both Wood Legs face inward. DO NOT tighten the bolts in this step. Whalen Furniture Manufacturing Page 6 Factory No. 17074...
  • Page 7 (2 used in this step) ③ 7. Insert one 1” Bolt (3) through the stand-off of each Top Support (H) and screw into the metal trim of Wood Leg (C and D). As shown. Whalen Furniture Manufacturing Page 7 Factory No. 17074...
  • Page 8 8. Align and attach 2 Metal Legs (E) to the Wood Legs (C and D) by using the 5/8" Bolts (1) with the Lock Washers (5) and Flat Washers (6) through the end metal brackets and screw into place. As shown. Whalen Furniture Manufacturing Page 8...
  • Page 9 9. Fit the Bottom Stretcher (F) between the drilled holes on the Metal Legs (E) making sure the threaded sockets face backward. Attach the Bottom Stretcher (F) in place using two 1-3/4” Bolts (4) through the drilled holes on Metal Legs (E) and screw into the threaded nuts. As shown. Whalen Furniture Manufacturing Page 9 Factory No. 17074...
  • Page 10 11. Align and attach 2 Metal Bars (G) between the Bottom Stretcher (F) and the Metal Top Frame (B) for extra support, using the 5/8” Bolts (1). As shown. 12. Go back and securely tighten all bolts with the enclosed Allen wrench. Whalen Furniture Manufacturing Page 10 Factory No. 17074...
  • Page 11 14. If necessary, adjust the pre-attached floor levelers at the bottom of Legs (C, D and E) to level the unit. When adjusting the height and tilting the unit make sure that you ask the help of a friend to prevent the glass from falling. Whalen Furniture Manufacturing Page 11 Factory No. 17074...
  • Page 12: Care And Maintenance

    A Touch-up Pen has been provided to repair any small nicks or scratches that may occur during assembly or shipping. We hope you enjoy your purchase for many years. Thank you for purchasing! Whalen Furniture Manufacturing Page 12 Factory No. 17074...
