Whalen Sedona MNFP54BF23-5 Instruction Booklet
  1. Manuals
  2. Brands
  3. Whalen Manuals
  4. Indoor Furnishing
  5. Sedona MNFP54BF23-5
  6. Instruction booklet

Whalen Sedona MNFP54BF23-5 Instruction Booklet

54" fireplace console
Hide thumbs

Advertisement

Quick Links

Download this manual
Sedona 54" Fireplace Console
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll-free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
Or visit our website 24 Hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
Model # MNFP54BF23-5
ADULT ASSEMBLY REQUIRED
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
www.whalenfurniture.com
Or e-mail your request to:
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2022-03-21
1-866-942-5362
parts@whalenfurniture.com
Rev. 0001-A
LOT NUMBER:
DATE PURCHASED: /
/

Advertisement

loading

Related Manuals for Whalen Sedona MNFP54BF23-5

Summary of Contents for Whalen Sedona MNFP54BF23-5

  • Page 1 LOT NUMBER: DATE PURCHASED: / Sedona 54" Fireplace Console Model # MNFP54BF23-5 ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our toll-free customer service number and have your instructions and parts list ready to provide the model name, part name or factory number: 1-866-942-5362 Pacific Standard Time: 8:30 a.m.
  • Page 2 How to adjust the European adjustable hinges on doors Shipping may cause doors to go out of alignment. If you find that the doors need to be adjusted slightly, turn the appropriate screw, as illustrated. 1. TO ADJUST DOOR FORWARD OR BACKWARD. 2.
  • Page 3 IMPORTANT Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non- abrasive surface. You will need the parts identified on page 4 and 5 of this instruction manual. NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH THE DOWELS. EXCESS GLUE CAN BE WIPED OFF WITH A DAMP CLOTH.
  • Page 4 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Top Panel (Qty. 1) B- Center Shelf (Qty. 1) C- Bottom Panel (Qty. 1) D- Lower Side Panel E- Left Lower Partition Panel F- Right Lower Partition Panel (Qty.
  • Page 5 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. (1) Cam Lock (2) Cam Bolt (3) M8 x 30 mm Wood Dowel (Qty. 55+2 extra) (Qty. 55+2 extra) (Qty.
  • Page 6 Assembly Instructions 1. Unpack the unit and confirm that you have all the hardware and required parts. Assemble the unit on a carpeted floor or the empty carton to avoid any scratches. 2. Securely screw the Cam Bolts (2) into the designated small holes on the Bottom Panel (C) and the Bottom Stretchers (O, P and Q) using a Phillips screwdriver.
  • Page 7 Assembly Instructions 4. Attach the Bottom Back Stretcher (S) between the Bottom Side Stretchers (P and Q) by engaging two Cam Locks (1). 5. Align and attach the Bottom Middle Stretcher (R) to the Bottom Front Stretcher (O) by engaging one Cam Lock (1).
  • Page 8 Assembly Instructions 6. Attach the Bottom Front Stretcher (O) to Bottom Side Stretchers (P and Q) by engaging two Cam Locks (1). 7. Fasten the Bottom Back Stretcher (S) to the Bottom Middle Stretcher (R) with two 50 mm Wood Screws (6).
  • Page 9 Assembly Instructions 9. Securely screw the Cam Bolts (2) into the designated small holes on the Center Shelf (B), Bottom Panel (C) and Lower Partition Panels (E and F) using a Phillips screwdriver. NOTE: DO NOT over tighten the cam bolts.
  • Page 10 Assembly Instructions 11. Attach the Left Middle Stile (M) to the Left Lower Partition Panel (E) by engaging two Cam Locks (1). 12. Attach the Right Middle Stile (N) to the Right Lower Partition Panel (F) by engaging two Cam Locks (1).
  • Page 11 Assembly Instructions 13. Attach the Middle Crossbar (L) between the Lower Partition Panels (E and F) by engaging two Cam Locks (1). 14. Attach the previous assembly to the Bottom Panel (C) with four 50 mm Screws (6).
  • Page 12 Assembly Instructions 15. Attach the Lower Side Panels (D) to the Bottom Panel (C) by engaging the Cam Locks (1). 16. Ask for assistance to place the Center Shelf (B) onto the inserted wood dowels on the vertical panels properly and fasten it in place with the Cam Locks (1).
  • Page 13 Assembly Instructions 17. Stand the assembled unit upright. 18. Securely screw the Cam Bolts (2) into the designated small holes on the Center Shelf (B) and Moldings (H and J) using a Phillips screwdriver. NOTE: DO NOT over tighten the cam bolts. 19.
  • Page 14 Assembly Instructions 20. Attach the Upper Partition Molding (J) to the Upper Partition Panel (I) by engaging two cam locks (1) as shown. 21. Attach one Upper Side Panel Molding (H) to one Upper Side Panel (G) by engaging two cam locks (1). 22.
  • Page 15 Assembly Instructions 24. Securely screw the Cam Bolts (2) into the designated small holes on the Top Panel (A) using a Phillips screwdriver. NOTE: DO NOT over tighten the cam bolts. 25. Attach the Top Reinforcement (K) to the Top Panel (A) with four 50 mm Screws (6).
  • Page 16 Assembly Instructions 26. Position the Top Panel (A) onto the inserted Wood Dowels (3) and fasten it in place by engaging six Cam Locks (1). 27. Ask for assistance to lay down the assembled unit at its front edges. 28. Fasten the Middle Crossbar (L) to the Center Shelf (B) by engaging three Cam Locks (1).
  • Page 17 Assembly Instructions 29. Using the pilot holes as a guide, attach two Metal Brackets (7) at the joints where the Middle Crossbar (L) meets the Middle Stiles (M and N) with four 12 mm Screws (4). 30. Now, go back and tighten all Cam Locks and Screws, make sure that all the parts are tight and there are no gaps between the parts, this will help keep the unit square.
  • Page 18 Assembly Instructions 33. Attach one Handle (8) to the front side of each Door (T) with the Handle Bolts (9). 34. Stand the assembled unit upright. 35. Pick up one Door (T) and attach the extended hinge arms to the hinge bases installed on the Left Side Panel (D).
  • Page 19 Assembly Instructions 38. Insert eight Shelf Pins (10) into the holes at your desired height inside each compartment. Make sure you place the four Shelf Pins (10) at the same level so the shelf is not tilted. Tilt and rest the Adjustable Shelves (U) onto the Shelf Pins (10).
  • Page 20 Assembly Instructions 41. Unpack the fireplace insert from the inner box and follow the instructions to install the Top Trim and Side Trims to the fireplace insert. 42. Lift the fireplace insert carefully into the back of the assembled mantel and center it in the opening. DO NOT drag the insert across the Bottom Panel (C) as it may scratch the unit.
  • Page 21 Assembly Instructions Tools required: Phillips screwdriver, stud finder, power drill and 1/8” drill bit. 46. Ask for assistance to position the assembled fireplace at the desired location against a wall. If necessary, adjust the installed Floor Levelers at the bottom of the Base to level the unit. Now, follow the instructions printed on the plastic bag containing the Tipping Restraint Hardware to attach the tip-over restraints to the unit and the wall.
  • Page 22 WARNING Please use your furniture correctly and safely. Improper use can cause safety hazards, or damage to your furniture or household items. Carefully read the following safety information. This unit is not intended for use with CRT TVs. The top surface maximum weight capacity is 80 lbs. (36.3 kg) and maximum load 65in.

  • Page 23: Quality Guarantee

    Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
  • Page 24 Care and Maintenance  Use a soft, clean cloth that will not scratch the surface when dusting.  Use of furniture polishes is not necessary. Should you choose to use polishes, test first in an inconspicuous area.  Using solvents of any kind on your furniture may damage the finish. ...
