Whalen Crestwood MNFP68CW30MB Instruction Booklet

68in. fireplace console
Hide thumbs

Advertisement

Quick Links

Download this manual
Crestwood 68in. Fireplace Console
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll-free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
Or visit our web site 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
Model # MNFP68CW30MB
ADULT ASSEMBLY REQUIRED
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
www.whalenfurniture.com
Or e-mail your request to parts@whalenfurniture.com
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2021-04-30
1-866-942-5362
Rev. 0001-A
LOT NUMBER:
DATE PURCHASED: /
/

Advertisement

loading
Need help?

Need help?

Do you have a question about the Crestwood MNFP68CW30MB and is the answer not in the manual?

Questions and answers

Related Manuals for Whalen Crestwood MNFP68CW30MB

Summary of Contents for Whalen Crestwood MNFP68CW30MB

  • Page 1 LOT NUMBER: DATE PURCHASED: / Crestwood 68in. Fireplace Console Model # MNFP68CW30MB ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our toll-free customer service number and have your instructions and parts list ready to provide the model name, part name or factory number: 1-866-942-5362 Pacific Standard Time: 8:30 a.m.

  • Page 2: Special Note

    G E N E R A L I N F O R M A T I O N , T I P S A N D T R I C K S 1. Please read the Assembly Instructions prior to assembling this product. 2.
  • Page 3 IMPORTANT Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non- abrasive surface. You will need the parts identified on page 4 and 5 of this instruction manuals. NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH THE DOWELS. EXCESS GLUE CAN BE WIPED OFF WITH A DAMP CLOTH.
  • Page 4 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Top Panel (Qty. 1) B- Media Shelf (Qty. 1) C- Bottom Panel (Qty. 1) D- Left Side Panel (Qty. 1) E- Right Side Panel (Qty.
  • Page 5 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. W- Middle Back Panel (Qty. 1) Fireplace Insert (Qty. 1) Remote Control with Battery (Qty. 1) (1) Cam Lock (2) Cam Bolt (3) M8 x 30 mm Wood Dowel (4) M3.5 x 12 mm Flat Head Screw...
  • Page 6 Assembly Instructions NOTE: Please do not fully tighten all bolts until you finish assembling all parts. Once assembled, go back and fully tighten all bolts. This will make it easier during assembly of unit. 1. Unpack the unit and confirm that you have all the hardware and required parts. Assemble the unit on a carpeted floor or the empty carton to avoid any scratch.
  • Page 7 Assembly Instructions 4. Insert Wood Dowels (3) into the inner holes on the Media Shelf (B), Partition Panels (F and G) and Upper Stile Moldings (J). Tap in with a rubber mallet, if necessary. Make sure that you use a small amount of glue with both ends of all dowels.
  • Page 8 Assembly Instructions 7. Align and attach the (K) to the Media Shelf (B) by engaging three Cam Locks (1). Middle Crossbar 8. Attach the assembled Media Shelf (B) between the Partition Panels (F and G) by engaging four Cam Locks (1).
  • Page 9 Assembly Instructions 9. Stand the previous assembly unit upright. 10. Fasten the Upper Stile Moldings (J) to the Left and Right Stiles (H and I) with four 25mm Screws (7). 11. Lay down the assembled unit. 12. Glue and insert eight Wood Dowels (3) into the inner holes of the Partition Panels (F and G) at both ends.
  • Page 10 Assembly Instructions 13. Securely screw the Cam Bolts (2) into the designated small holes on the Top Panel (A) and Bottom Panel (C) using a Phillips screwdriver. 14. Securely screw the Cam Bolts (2) into the designated small holes on Left and Right Skirtings (O and P) and Front Skirting (R) using a Phillips screwdriver.
  • Page 11 Assembly Instructions 15. Glue the Wood Dowels (3) into the indicated holes on Side Skirtings (O and P), Back Skirting (Q) and Skirting Bottom Support (N). 16. Glue the Wood Dowels (3) into the indicated holes on the Firebox Supports (L and M) and Front Skirting (R).
  • Page 12 Assembly Instructions Cam Bolt holes must face in 17. Attach Back Skirting (Q) between the Left and Right Skirtings (O and P) by engaging two Cam Locks (1). 18. Attach Skirting Bottom Support (N) to the Front Skirting (R) by engaging one Cam Lock (1).
  • Page 13 Assembly Instructions 19. Attach the Front Skirting (R) to the Side Skirtings (O and P) by engaging two Cam Locks (1). 20. Fasten the Skirting Bottom Support (N) to the Back Skirting (Q) with two 38 mm Screws (8). Threaded hole for floor leveler Pilot holes for Long Firebox Support...
  • Page 14 Assembly Instructions 22. Securely screw the Cam Bolts (2) into the designated small holes on the top surface of Bottom Panel (C) using a Phillips screwdriver. 23. Attach the Short Firebox Supports (M) to the Bottom Panel (C) by engaging four Cam Locks (1).
  • Page 15 Assembly Instructions 24. Align and attach the Long Firebox Support (L) to the Bottom Panel (C) using four 50 mm Screws (9). 25. Align the drilled holes on the Bottom Panel (C) with the inserted Wood Dowels on both Partition Panels (F and G), then press them together.
  • Page 16 Assembly Instructions 27. Glue four Wood Dowels (3) into the inner holes on each Side Panels (D and E) at both ends. Door hinge mounting bases point towards the front of the unit 28. Attach the Side Panels (D and E) to the Bottom Panel (C) by engaging four Cam Locks (1).
  • Page 17 Assembly Instructions 29. Attach the Top Panel (A) to the Side Panels (D and E) and Partition Panels (F and G) by engaging eight Cam Locks (1). 30. Screw in two Floor Levelers (11) into the threaded holes in the Front Skirting (R).
  • Page 18 Assembly Instructions 31. Turn the assembled unit over so that its back is facing up. 32. Fasten the Long Firebox Support (L) to the Left and Right Stiles (H and I) by attaching two Mending Plates (12) at the joints, using two 12 mm Screws (4) per plate. 33.
  • Page 19 Assembly Instructions 37. Stand the assembled unit upright. 38. Pick up one Door (T) and attach the extended hinge arms to the hinge bases installed on the Left Side Panel (D). Loosen the bolt on the back of the hinge base for an easy fit. Align and insert the “U” slot on the hinge arm under the bolt head on the back of the hinge base.
  • Page 20 Assembly Instructions 42. Insert eight Shelf Supports (15) into the holes at your desired height on each compartment. Make sure that you place the four shelf supports at the same level so the shelves are not tilted. 43. Tilt and rest the Adjustable Shelves (S) onto the Shelf Supports (15). 44.
  • Page 21 Assembly Instructions Electric Fireplace 45. Lift the fireplace insert carefully into the back of the assembled mantel and center it in the opening. drag the insert across the firebox supports (L and M) as it may scratch the unit. 46. Using the pilot holes as a guide, fit two Metal Brackets (18) to the side plates of the fireplace insert and fasten them to the Left and Right Stiles (H and I) with four 12 mm Pan Head Screws (5).
  • Page 22 Assembly Instructions Clip Glass Door Panel (Pre-attached) Wood Door Panel Note: The doors are shipped with Glass Door Insert. You can keep the doors as they are or interchange with the Wood Door Insert (U) depending on your configuration. 49. To change the configuration, loosen the screws on the inside of Doors (T) and rotate the clips to remove the door insert panel.
  • Page 23 Assembly Instructions Tools required (not provided): Phillips screwdriver, stud finder, tape measure, pencil, power drill and 1/8” drill bit. 50. Ask for assistance to position the assemble fireplace console at the desired location against a wall. If necessary, adjust the pre-attached Floor Levelers at the bottom of the Front Skirting (R) to level the unit. Now, follow the instructions printed on the plastic bag containing the Tipping Restraint Hardware to attach the tip-over restraints to the unit and the wall.

  • Page 24: Care And Maintenance

    Care and Maintenance  Use a soft, clean cloth that will not scratch the surface when dusting.  Use of furniture polishes is not necessary. Should you choose to use polishes, test first in an inconspicuous area.  Using solvents of any kind on your furniture may damage the finish. ...

  • Page 25: Quality Guarantee

    Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
