Creone Keybox 9000 Basic Instruction Manual page 31

1. Compartments and keyhooks
NO. doors
NO. keyhooks in each compartment
2. Technical data
Lock:
Material cabinet:
Surface finish:
External dimensions: 350x280x85 mm (BxHxD)
Weight (kg):
9001 E
1
32
Electron magnet 12V, 1A
Steel plate 1.5 mm
Galvanized sheet metal,
powder coated.
(Model 9001, 9002, 9006)
746x730x140 (model 9500)
745x460x270 mm (model 7000)
5,3 kg (model 9001, 9002)
6,0 kg (model 9006)
28 kg (model 9500)
20 kg (model 7000)
9000 E
9002 E 9006 E
2
8
3 Printed circuit diagram
1
2
3
4
5
6
Circuit board drawing Keybox 9000 E
31
9500 E
6 1
– 216
Nr.
9000 E series
